Gas Grill
LPG Gas Grill Owner's Guide
210/310
register your barbecue online at www.weber.com
You must read this owners Guide
before operatinG Your Gas barbeCue.
m danGer
if you smell gas:
1. shut off gas to the appliance.
2. extinguish any open flames.
3. open lid.
4. if odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
m warninG:
1. do not store spare LpG cylinder within 10
feet (3m) of this appliance.
2. do not store or use petrol or other
flammable liquids or vapors within
25 feet (8m) of this appliance.
#90817
®
m warninG: follow all leak-check
procedures carefully in this manual prior
to barbecue operation. do this even if the
barbecue was dealer-assembled.
notiCe to instaLLer: these instructions
must be left with the owner and the owner
should keep them for future use.
this Gas appLianCe is desiGned for
outdoor use onLY.
m warninG: do not try to light this
appliance without reading the ignition
instructions section of this manual.
90817 12/19/11 lP
aU - aUsTraliaN
ClOsED CarT ClassiC

Advertisement

Table of Contents
loading

Summary of Contents for Weber Spirit Series

  • Page 1 Gas Grill LPG Gas Grill Owner’s Guide 210/310 #90817 register your barbecue online at www.weber.com ® You must read this owners Guide m warninG: follow all leak-check before operatinG Your Gas barbeCue. procedures carefully in this manual prior to barbecue operation. do this even if the barbecue was dealer-assembled.
  • Page 2: Warnings

    LpG cylinder may appear to be empty, attempting to relight, using the lighting instructions. gas may still be present, and the LpG cylinder should be m do not use charcoal or lava rock in your weber ® transported and stored accordingly.
  • Page 3: Table Of Contents

    CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 WEBER SPIDER/INSECT SCREENS .
  • Page 4: Exploded View 210

    EXPlODED ViEW 210 Spirit Classic Closed Cart 210 LP AU 122011...
  • Page 5: Exploded View List 210

    12. Left front trim assembly arm 27. rear panel 42. bottom shelf 13. Left Condiment basket 28. burner tubes assembly 43. right door assembly 14. front panel 29. manifold, hose and regulator 44. matchlight holder 15. Left frame panel 30. disposable drip pan WWW.WEbEr.COm ®...
  • Page 6: Exploded View 310

    EXPlODED ViEW 310 Spirit Classic Closed Cart 310 LP AU 122011...
  • Page 7: Exploded View List 310

    12. Left front trim assembly arm 27. rear panel 42. bottom shelf 13. Left Condiment basket 28. burner tubes assembly 43. right door assembly 14. front panel 29. manifold, hose and regulator 44. matchlight holder 15. Left frame panel 30. disposable drip pan WWW.WEbEr.COm ®...
  • Page 8: Warranty

    25-years (2-years on paint; excludes fading) Stainless steel Shroud: 25-years Weber is not liable for any special, indirect or consequential damages . Some regions do not allow the Porcelain-enamelled shroud: 25-years exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not...
  • Page 9: Gas Instructions

    HOsE, rEGUlaTOr aND ValVE assEmblY m important notiCe: we recommend that you replace the gas hose assembly on your weber gas barbecue every 5 years. some countries may have requirements that the gas hose be replaced within less than 5 years, in which case that country’s requirement would take precedence.
  • Page 10: Connecting The Lpg Cylinder

    . m warninG: never store an extra (spare) LpG cylinder under Regulator vent hole or near the weber gas barbecue. ® A) Turn the LPG cylinder so the opening of the valve is to the front or side of the Weber gas barbecue .
  • Page 11: Leak-Check Preparation

    Note: All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber® gas barbecue. Shipping and handling may loosen or damage a gas fitting.
  • Page 12: Refilling The Lpg Cylinder

    GriLL. Contact the Customer service representative in your area using the contact information on our web site. Log onto www.weber.com ® B) Regulator-to-cylinder connection (2) . C) The hose-to-regulator connection (3) .
  • Page 13: Before Using The Grill

    Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. if the hose is found to be damaged in any way, do not use the barbecue. replace using only weber authorized replacement hose. Contact ®...
  • Page 14: Main Burner Ignition & Usage

    maiN bUrNEr iGNiTiON & UsaGE main burner iGnition m danGer failure to open the lid while igniting the barbecue’s burners, or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up, which can cause serious bodily injury or death.
  • Page 15: Main Burner Manual Ignition

    Note - Always light BURNER 1 first. The other burners ignite from BURNER 1. ◆ to eXtinGuish Push down and turn each burner control knob clockwise to the OFF position . Turn gas supply OFF at the source . ◆ WWW.WEbEr.COm ®...
  • Page 16: Grilling Tips & Helpful Hints

    Note: If barbecue loses heat while cooking refer to the troubleshooting section of this • The temperature of your gas barbecue may run hotter than normal for the first few uses. manual. • Grilling conditions may require the adjustment of the burner controls to attain the m warninG: do not move the weber gas barbecue when ® correct cooking temperatures . operating or while barbecue is hot.
  • Page 17: Maintenance

    ® Your Weber gas barbecue, as well as any outdoor gas appliance, is a target for spiders m warninG: turn your weber gas barbecue off and wait for ® ® and other insects . They can nest in the venturi section (1) of the burner tubes . This it to cool before cleaning.
  • Page 18: Burner Tubes Cleaning Or Replacement

    CLeaninG or repLaCement You will need: Phillips screwdriver and 7/16" wrench . A) Your Weber gas barbecue must be OFF and cool . ® B) Turn gas OFF at source . C) Remove cookbox components - warming rack, grates and Flavorizer bars .
  • Page 19: Crossover Ignition System Operations

    Insect screens and burners are clean, replace the burners . If the Spider/Insect screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web site . Log onto www .weber .com ® burner flame pattern The Weber ®...
  • Page 20 These parts may be gas carrying or gas burning components . Please contact Weber-Stephen Products LLC Customer Service Department for genuine Weber-Stephen Products LLC replacement part(s) information .
