NCR Verifone UX100 Kit Instructions

Mount without trackball
Hide thumbs Also See for Verifone UX100:

Advertisement

Quick Links

Download this manual
Kit Instructions
Verifone UX100, UX300, and UX400 Mount
without Trackball
7705-K055
Issue C

Advertisement

loading

Related Manuals for NCR Verifone UX100

Summary of Contents for NCR Verifone UX100

  • Page 1 Kit Instructions Verifone UX100, UX300, and UX400 Mount without Trackball 7705-K055 Issue C...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.

  • Page 3: Revision Record

    Revision Record Issue Date Remarks Jul 2018 First Issue Nov 2018 Added a screw for UX100 Ground Harness and a Gas Spring Updated installation procedures Feb 2019 Added notes on installation of screws and other devices Added images for cabling and tie downs...
  • Page 4 Verifone UX100, UX300, and UX400 Mount without Trackball Introduction This kit provides components to support installation of the following Verifone® devices to an NCR SelfServ™ 75 (7705) Kiosk: • UX100 Personal Identification Number (PIN) Pad with Ground Harness • UX300 Magnetic Stripe Reader (MSR) •...

  • Page 5: Tools Required

    • #2 Phillips screwdriver with torque limiter • #7mm nut driver with torque limiter • Flat Head screwdriver Note: NCR recommends to use a Long Thin Wall 7mm Nut Driver with torque limiter to facilitate the installation of Verifone devices on the kiosk.

  • Page 6: Kit Contents

    Verifone UX100, UX300, and UX400 Mount without Trackball Kit Contents Note: Depending on the kiosk configuration, some parts shown in the following image may not be needed.

  • Page 7: Installation Procedure

    To install the 7705-K055 kit to a NCR Selferv™ 75 Kiosk, power down the kiosk, unplug the power cord, and then perform the following steps: 1.
  • Page 8 5. Install the new Fascia Panel included in this kit. For more information, see Installing the New Fascia Panel Assembly on page 47. 6. Install the Verifone UX100 PIN Pad. For more information, see Installing the UX100 PIN Pad on page 51. 7. In the Top Box, remove the I/O Panel Cover. For more information,see...
  • Page 9 Verifone UX100, UX300, and UX400 Mount without Trackball 10. Install the I/O Panel Cover. For more information,see Installing the I/O Panel Cover page 68. 11. Validate installation of Verifone UX devices. For more information, Validating Installation of Verifone UX Devices on page 69. Turning OFF the Kiosk The kiosk should be switched OFF using the power switch located in the top-box, power switch in the Sidecar if present, and the UPS power switch if present.
  • Page 10 Verifone UX100, UX300, and UX400 Mount without Trackball 4. If a Sidecar is present, push the Sidecar PSU switch to to the "0" position. 5. If a UPS is present, push the power switch to shut it down. 6. Unplug the AC Power Cable from the AC power source.
  • Page 11 Verifone UX100, UX300, and UX400 Mount without Trackball Removing MSRs from the Front Panel The Front Panel can either have a Sankyo MSR or a Verifone UX300 MSR. Refer to sections below as appropriate for the present device in the kiosk: •...
  • Page 12 Verifone UX100, UX300, and UX400 Mount without Trackball Removing the Sankyo MSR from the Front Panel 1. Inside the top box, disconnect the Private Audio Cable from the Private Audio Extension Cable. Note: This step is only applicable if the unit is configured with the Private Audio feature.
  • Page 13 2-10 Verifone UX100, UX300, and UX400 Mount without Trackball 4. Slide out the Front Panel from the Kiosk. Push the two orange latches outwards and pull the Front Panel towards you until it is out from the Kiosk. 5. Carefully place the Front Panel assembly face down on the Top Box. Note that the Speaker Harness and Proximity Detector USB Cable are still secured to the Front...
  • Page 14 Verifone UX100, UX300, and UX400 Mount without Trackball 2-11 6. Take note of the routing and disconnect the Speaker Harness and Proximity Detector USB Cable, cut off the cable ties securing them to the panel. Note: Keep the cables safe and secured in the Top Box while working on the Front Panel.
  • Page 15 2-12 Verifone UX100, UX300, and UX400 Mount without Trackball 8. Remove the two screws securing the Proximity Detector Cover then remove the cover from the Front Panel. 9. Remove the four screws securing the card reader and bezel assembly to the Front...
  • Page 16 Verifone UX100, UX300, and UX400 Mount without Trackball 2-13 10. Remove the screws (two on each speaker) securing the Speakers to the Front Panel then remove the Speakers. 11. Remove the eight screws securing the Panel Frame to the Front Panel then remove...
  • Page 17 2-14 Verifone UX100, UX300, and UX400 Mount without Trackball 12. Remove the MSR MEI Ring from the Front Panel. 13. Mount and secure the Panel Frame to the Front Panel using seven screws.
  • Page 18 Verifone UX100, UX300, and UX400 Mount without Trackball 2-15 14. Mount and secure the Speakers to the Front Panel using two screws on each speaker. 15. Mount and secure the Blank Plate to the Fascia Panel using three screws. Use the...
  • Page 19 2-16 Verifone UX100, UX300, and UX400 Mount without Trackball 16. Mount and partially tighten two screws for the Proximity Detector Cover. 17. Insert and slide the Proximity Detector Cover under the partially tightened screws, then fully tighten the two screws to secure the cover.
  • Page 20 Verifone UX100, UX300, and UX400 Mount without Trackball 2-17 18. Connect the Speaker Cables to the Speakers. Note: Make sure that the correct cable wire is connected to the appropriate speaker connection terminal. • Connect "-" cable wire to "-" speaker terminal •...
  • Page 21 2-18 Verifone UX100, UX300, and UX400 Mount without Trackball 21. Route the Proximity Detector USB Cable towards the left-hand side of the Front Panel. 22. Align the Front Panel latches to the slots in the Top Box, then push the Front Panel into the Top Box.
  • Page 22 Verifone UX100, UX300, and UX400 Mount without Trackball 2-19 24. Remove and discard the Sankyo DIP Reader USB and DC cables. Note: The Sankyo cables will be replaced with the following cables included in this kit: • Sankyo USB cable — will be replaced with the 2m UX300 USB cable (009–0021027) •...
  • Page 23 2-20 Verifone UX100, UX300, and UX400 Mount without Trackball c. Slide the 12V Regulator assembly upward and rotate backward to remove the assembly. d. Disconnect the Sankyo MSR DC Cable from the regulator, and then discard the cable.Removing the Fascia Panel on page 34...
  • Page 24 Verifone UX100, UX300, and UX400 Mount without Trackball 2-21 Removing the UX300 MSR from the Front Panel 1. Inside the top box, disconnect the Private Audio Cable from the Private Audio Extension Cable. Note: This step is only applicable if the unit is configured with the Private Audio feature.
  • Page 25 2-22 Verifone UX100, UX300, and UX400 Mount without Trackball 3. Carefully place the Front Panel assembly face down on the Top Box. Note that the Speaker Harness and Proximity Detector USB cable are still secured to the Front Panel. 4. Disconnect the following cables from the UX300 MSR: •...
  • Page 26 Verifone UX100, UX300, and UX400 Mount without Trackball 2-23 5. Remove the cable ties securing the Fascia Cable Bundle, and then remove the MSR cables from the bundle. 6. Take note of the routing and disconnect the Speaker Harness and Proximity Detector USB Cable, cut off the cable ties securing them to the panel.
  • Page 27 2-24 Verifone UX100, UX300, and UX400 Mount without Trackball 8. Remove the four screws securing the UX300 MSR and Bracket assembly from the Front Panel and then remove the assembly. 9. Remove the four nuts securing the UX300 MSR to the bracket.
  • Page 28 Verifone UX100, UX300, and UX400 Mount without Trackball 2-25 10. Remove the screws (2 on each speaker) securing the Speakers to the Front Panel then remove the Speakers. 11. Remove four screws securing the Panel Frame from the Front Panel.
  • Page 29 2-26 Verifone UX100, UX300, and UX400 Mount without Trackball 12. Remove the UX300 MSR Bezel from the Front Panel. 13. Mount and secure the Panel Frame to the Front Panel using seven screws.
  • Page 30 Verifone UX100, UX300, and UX400 Mount without Trackball 2-27 14. Mount and secure the Speakers to the Front Panel using two screws on each speaker. 15. Mount and secure the Blank Plate to the Fascia Panel using 3 screws. Use the screws...
  • Page 31 2-28 Verifone UX100, UX300, and UX400 Mount without Trackball 16. Mount and partially tighten two screws for the Proximity Detector Cover. 17. Insert and slide the Proximity Detector Cover under the partially tightened screws, then fully tighten the two screws to secure the cover.
  • Page 32 Verifone UX100, UX300, and UX400 Mount without Trackball 2-29 18. Connect the Speaker Cables to the Speakers. Note: Make sure that the correct cable wire is connected to the appropriate speaker connection terminal. • Connect "-" cable wire to "-" speaker terminal •...
  • Page 33 2-30 Verifone UX100, UX300, and UX400 Mount without Trackball 21. Route the Proximity Detector USB Cable towards the left-hand side of the Front Panel. 22. Align the Front Panel latches to the slots in the Top Box, then push the Front Panel into the Top Box.
  • Page 34 Verifone UX100, UX300, and UX400 Mount without Trackball 2-31 24. Remove and discard the current UX300 MSR DC Cable. Note: This cable will be replaced with the 2m UX300 DC cable (497–0522036) included in this kit. a. Loosen the screw securing the 12V Regulator to the kiosk.
  • Page 35 2-32 Verifone UX100, UX300, and UX400 Mount without Trackball c. Disconnect the UX300 MSR DC Cable from the regulator, and then discard the cable. 25. Remove the I/O Panel Cover. a. Loosen the screw that secures the I/O Panel Cover. b. Slide the cover upward to unlatch its tabs and hooks from the I/O Panel.
  • Page 36 Verifone UX100, UX300, and UX400 Mount without Trackball 2-33 26. Disconnect the Front Panel UX300 cable from the USB Hub, and then discard the cable. Note: For the next procedure, refer to Installation Procedure on page 4.
  • Page 37 2-34 Verifone UX100, UX300, and UX400 Mount without Trackball Removing the Fascia Panel The Fascia Panel can contain different PIN pads or a blank plate, refer to the sections below as appropriate for the Fascia Panel configuration in the kiosk: •...
  • Page 38 Verifone UX100, UX300, and UX400 Mount without Trackball 2-35 Removing the Fascia Panel with an External PIN Pad The current Fascia Panel may contain an external PIN Pad and a Trackball that will be removed and discarded in order to install this kit.
  • Page 39 2-36 Verifone UX100, UX300, and UX400 Mount without Trackball 2. Disconnect the PIN Pad USB cable from the EBox and cut off the cable ties securing the cable to the Fascia. 3. Remove the four nuts securing the PIN Pad Mounting Plate from the Fascia Panel.
  • Page 40 Verifone UX100, UX300, and UX400 Mount without Trackball 2-37 4. Remove the five screws securing the PIN Pad Bracket from the Fascia Panel. 5. Remove the screw securing the Fascia Panel to the Barcode Reader assembly. 6. Remove the six screws securing the Fascia Panel to the Main Fascia and then remove the panel from the kiosk.
  • Page 41 2-38 Verifone UX100, UX300, and UX400 Mount without Trackball Removing the Fascia Panel with a UX100 PIN Pad The following components in this procedure will be re-used to support installation of this kit: • UX100 PIN Pad and Bracket assembly • PIN Pad Ground Harness •...
  • Page 42 Verifone UX100, UX300, and UX400 Mount without Trackball 2-39 2. Remove the five screws securing the PIN Pad and Bracket assembly to the Fascia Panel and then remove the assembly. 3. Cut off the cable tie securing the PIN Pad cable to the bracket, remove the nut securing the cable lock bracket and then disconnect the cable from the PIN Pad.
  • Page 43 2-40 Verifone UX100, UX300, and UX400 Mount without Trackball 4. Remove the screw securing the Fascia Panel to the Barcode Reader assembly. 5. Remove the six screws securing the Fascia Panel to the Main Fascia and then remove the panel from the kiosk.
  • Page 44 Verifone UX100, UX300, and UX400 Mount without Trackball 2-41 Removing the Fascia Panel with a Blank Plate The current Fascia Panel may contain a Trackball that will be removed and discarded in order to install this kit. 1. If a Trackball is present, disconnect the following Trackball cables: a.
  • Page 45 2-42 Verifone UX100, UX300, and UX400 Mount without Trackball 2. Remove the four nuts securing the PIN Pad Mounting Plate from the Fascia Panel. 3. Remove the five screws securing the Blank Plate Bracket from the Fascia Panel.
  • Page 46 Verifone UX100, UX300, and UX400 Mount without Trackball 2-43 4. Remove the screw securing the Fascia Panel to the Barcode Reader assembly. Note: After removing the screw, the Barcode Assembly will be left hanging. Be careful not to damage the Barcode Reader ribbon cable.
  • Page 47 2-44 Verifone UX100, UX300, and UX400 Mount without Trackball Replacing the Gas Spring Rod Caution: It is recommended that this procedure be performed by at least two persons, one to hold and support the Fascia Assembly and another to remove and install the Gas Spring Rod.
  • Page 48 Verifone UX100, UX300, and UX400 Mount without Trackball 2-45 b. Pull out the end cap of the rod from the ball head joint of the bracket. c. At the Top Box side, use the tip of a flat-head screwdriver to pry the metal circlet off of the end cap of the cylinder.
  • Page 49 2-46 Verifone UX100, UX300, and UX400 Mount without Trackball 2. To install the new Gas Spring Rod, press fit the end caps of the rod to the ball head joints of the Fascia and Top Box brackets. Install the thick cylinder side of the Gas Spring Rod to the Top Box ball jointand install the thin side to the Fascia ball joint.
  • Page 50 Verifone UX100, UX300, and UX400 Mount without Trackball 2-47 Installing the New Fascia Panel Assembly 1. Install the UX300 MSR to the Fascia Panel. a. If the UX300 MSR is new, remove the protective cover over its black weather seal.
  • Page 51 2-48 Verifone UX100, UX300, and UX400 Mount without Trackball 2. Install the UX400 NFC Reader to the Fascia Panel. a. If the UX400 NFC Reader is new, remove the protective cover over its black weather seal. b. Mount the UX400 NFC Reader to the Fascia Panel, and then carefully tighten the four M4 keps nuts to secure the UX400.
  • Page 52 Verifone UX100, UX300, and UX400 Mount without Trackball 2-49 3. In the Kiosk Fascia, secure one end of the PIN Pad Ground Harness to the right- hand side of the Fascia Frame Bracket using an M4x6 M/C Combi Pozi screw (009-0006582), and then bundle the harness and secure it to the bracket using a cable tie as shown below.
  • Page 53 2-50 Verifone UX100, UX300, and UX400 Mount without Trackball 4. Mount and secure the Fascia Panel assembly to the main kiosk fascia using six M4.2x8 P/Tite PH Pozi screws. Caution: Do NOT over tighten the plastite screws to avoid stripping the threads of the plastic mounting holes.
  • Page 54 Verifone UX100, UX300, and UX400 Mount without Trackball 2-51 Installing the UX100 PIN Pad 1. If the UX100 PIN Pad is new, remove the protective cover over its black weather seal. 2. Mount and secure the UX100 PIN Pad to the fascia panel bracket using two M4 keps nuts.
  • Page 55 2-52 Verifone UX100, UX300, and UX400 Mount without Trackball 3. Connect the UX100 USB cable (497-0441898) to the UX100 PIN Pad. 4. Secure the cable to the PIN Pad using the cable lock bar and a M4 keps nut. Note: Take note of the following: •...
  • Page 56 Verifone UX100, UX300, and UX400 Mount without Trackball 2-53 5. Route the USB cable along the right-hand side of the bracket and then mount and secure the PIN Pad assembly to the kiosk Fascia Panel using five screws. • Use two M4x12 CSK screws (007-7022123) to secure the PIN Pad assembly to the upper Frame •...
  • Page 57 2-54 Verifone UX100, UX300, and UX400 Mount without Trackball 6. Route the UX100 USB cable towards the UX300 MSR, securing the cable to the cable clamp on the Fascia Panel, and then connect the cable to the USB-1 port of the UX300 MSR.
  • Page 58 Verifone UX100, UX300, and UX400 Mount without Trackball 2-55 Removing the I/O Panel Cover 1. In the Top Box, loosen the screw that secures the I/O Panel Cover. 2. Slide the cover upward to unlatch its tabs and hooks from the I/O Panel.
  • Page 59 2-56 Verifone UX100, UX300, and UX400 Mount without Trackball Connecting and Routing Device Cables After the UX100 PIN Pad, UX300 MSR, and UX400 NFC Reader have been installed, route and connect the following cables: • UX400 Antenna Cable below (not included in kit, comes with UX400 device) •...
  • Page 60 Verifone UX100, UX300, and UX400 Mount without Trackball 2-57 UX400 Comms Cable The Comms Cable is not included in this kit, it comes together with the UX400 device. 1. Connect the RJ45 connector of the cable to the UX400. 2. Connect the other end of the cable to the UX400 Comm port of the UX300 MSR.
  • Page 61 2-58 Verifone UX100, UX300, and UX400 Mount without Trackball UX300 USB Cable (009-0021027) 1. Connect and route the UX300 USB cable.Connect the USB B connector of the cable to the UX300 MSR and secure the cable to the cable clamp on the Fascia Panel.
  • Page 62 Verifone UX100, UX300, and UX400 Mount without Trackball 2-59 3. Connect the UX300 USB cable to a free USB Hub port in the I/O Panel. If there are two USB Hubs in the I/O Panel, connect the cable to a free port on the upper USB Hub as shown below.
  • Page 63 2-60 Verifone UX100, UX300, and UX400 Mount without Trackball UX300 DC Cable (497-0522036) 1. Connect one connector of the cable to the UX300 MSR 12V DC IN port and secure the cable using the cable clamp on the Fascia Panel. 2. Route the cable along the main fascia cable bundle towards the Top Box. Secure the...
  • Page 64 Verifone UX100, UX300, and UX400 Mount without Trackball 2-61 3. In the Top Box, place the 12V DC Regulator assembly and connect the DC cable to the regulator. Note: If the kiosk previously contained a Sankyo MSR or a UX300 MSR in the Kiosk Front Panel, then the 12V DC Regulator may already be present in the kiosk.
  • Page 65 2-62 Verifone UX100, UX300, and UX400 Mount without Trackball 12V Regulator DC Cable (009-0020734) 1. Connect one end of the DC cable to the 12V Regulator. Note: If the kiosk previously contained a Sankyo MSR or UX300 MSR in the Kiosk Front Panel, then this cable is already installed.
  • Page 66 Verifone UX100, UX300, and UX400 Mount without Trackball 2-63 b. Insert the tab on the bottom side of the cover through the bottom slot on the regulator bracket. c. Insert the Keyhole Slot on the cover through the M4 screw on the regulator bracket.
  • Page 67 2-64 Verifone UX100, UX300, and UX400 Mount without Trackball 4. Tidy up and secure the cables near in the I/O Panel and Top Box as necessary as shown below. Note: For the next procedure, refer to Installation Procedure on page 4.
  • Page 68 Verifone UX100, UX300, and UX400 Mount without Trackball 2-65 Securing the USB, Power, and Antenna Cables 1. Bundle the UX400 Antenna and Comms cables together and secure the bundle to the fascia frames using cable ties. 2. Double–check if all cables are neatly bundled and secure by cable ties or cable clamps.
  • Page 69 2-66 Verifone UX100, UX300, and UX400 Mount without Trackball...
  • Page 70 Verifone UX100, UX300, and UX400 Mount without Trackball 2-67...
  • Page 71 2-68 Verifone UX100, UX300, and UX400 Mount without Trackball Installing the I/O Panel Cover 1. At the bottom part of the I/O Panel, align the tabs on the cover to the slot of the I/O Panel. 2. At the top part, of the I/O assembly, align the slots of the cover to the tabs on the I/O Panel.
  • Page 72 Verifone UX100, UX300, and UX400 Mount without Trackball 2-69 Validating Installation of Verifone UX Devices To validate installation of Verifone devices, follow the procedures depending on your specific implementation.

  • Page 73: Interconnection Diagram

    2-70 Verifone UX100, UX300, and UX400 Mount without Trackball Interconnection Diagram The illustration below shows the UX100 PIN Pad, UX300 MSR, and UX400 NFC Reader connection diagram to the NCR SelfServ 75 (7705) Kiosk.
