Huffy Folding Trike Owner's Manual
  1. Manuals
  2. Brands
  3. Huffy Manuals
  4. Bicycle
  5. Folding Trike
  6. Owner's manual

Huffy Folding Trike Owner's Manual

Children bike
Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual
Folding Trike
THIS MANUAL CONTAINS IMPORTANT SAFETY, ASSEMBLY,
OPERATION AND MAINTENANCE INFORMATION.
PLEASE READ AND FULLY UNDERSTAND THIS MANUAL
BEFORE OPERATION.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
m0063
HF-L&S Trike EN 101613
Copyright Huffy Corporation 2013

Advertisement

loading

Related Manuals for Huffy Folding Trike

Summary of Contents for Huffy Folding Trike

  • Page 1 Owner’s Manual Folding Trike THIS MANUAL CONTAINS IMPORTANT SAFETY, ASSEMBLY, OPERATION AND MAINTENANCE INFORMATION. PLEASE READ AND FULLY UNDERSTAND THIS MANUAL BEFORE OPERATION. SAVE THIS MANUAL FOR FUTURE REFERENCE. m0063 HF-L&S Trike EN 101613 Copyright Huffy Corporation 2013...

  • Page 2: Table Of Contents

    Manual Index ENGLISH • Safety Information ................2/3 • Maintenance ..................3 • Trike Assembly ..................4/5 • Parts View.....................6/7 • Folding / Unfolding Trike ................ 8 • Lights and Sounds Operation (if equipped) .........9/10 • Warranty ....................11 Safety Information Trikes, like all wheeled vehicles, will provide safe, enjoyable transportation and rec- reation when used and maintained properly.

  • Page 3: Safety Information

    Safety Information - continued • Do not allow a child to ride off road, on grass or wet surfaces. • Do not allow a child to ride on sloped driveways or hills. • Do not allow a child to ride near steps. •...

  • Page 4: Trike Assembly

    Trike Assembly The Trike comes either fully or partially assembled. Follow the instructions below for Trike Assembly. If equipped, the Lights and Sound unit will be installed on the Handlebars. Fork, Handlebars and Lights and Sounds unit (if equipped): 1. Place the Fender (16) over the fork (13) as shown.

  • Page 5: Trike Assembly

    Trike Assembly - continued 20 19 Rear Wheels: 1. Install Rear Wheels (10) over Axle Cups (9). 2. Install Axle Cap (11) with screw (7). Ensure Axle Cap is seated all the way in. 3. Repeat for opposite side. 4. Tighten Screws (7) securely but Do Not overtighten. WARNING: •...

  • Page 6: Parts View

    Parts View...
  • Page 7 Parts List...

  • Page 8: Folding / Unfolding Trike

    Folding / Unfolding the Trike To Unfold the Product: • Gently push down on Seat (A) and pull back on Rear Assembly (B) until the unit locks into place. • Make sure Locking Button (C) snaps into Seat Pivot Hole (D) - an audible CLICK will be heard.

  • Page 9: Lights And Sounds Operation (If Equipped)

    Lights and Sounds Unit Setup (if equipped) For initial operation remove Pull Tab Battery Replacement (For initial operation remove Pull Tab): Batteries: DC 1.5V, AAA (included). The unit requires 3 batteries. 1. Loosen the battery compartment cover Screw (A) to remove the Cover (B). 2.
  • Page 10 Lights and Sounds Unit Operation (if equipped) The various Lights and sounds are activated by pressing and releasing Buttons A, B, C, L and R. Specifi c button combinations will activate special Lights and Sounds sequences. • Game Mode #1 Sing-A-Long: Push and Hold Button (C) for 1 second: •...

  • Page 11: Warranty

    Huffy Corporation Limited Warranty Part or model specifi cations are subject to change without notice. This Limited Warranty is the only warranty for this product. There are no express warranties. The only uses for this product are described in this manual. Warranty reg- istration is not required.
  • Page 12 • Always read the user manual that comes with your helmet to make sure it is fi tted and attached properly to the wearer’s head according to the fi tting instructions described in the user manual. Check www.Huffy.com for the current contact information H Helmet EN 100212 i0027...
