Varia ™ Remote Instructions
Device Overview
Taillight key. Select to signal a left turn when using two taillights.
NOTE: The turn signal feature is available on the Varia TL 300 only.
Hold to change the taillight operating modes.
Headlight key. Select to switch between low beam and high beam.
Hold to change the headlight operating modes.
Taillight key and power key. Select to signal a right turn when using
two taillights.
Hold to turn all lights on and off.
Status LED.
Status LED
LED Activity Status
Flashing green Searching for a paired device.
Alternating red and green Attempting to pair with a device.
A turn indicator is on.
12 rapid green flashes Successfully paired with a device.
Solid red Pairing failed or the connection was lost.
Flashing red One or more of the paired devices has a low
battery.
Pairing the Remote with Your Varia Device
The first time you connect the Varia remote to your Varia device,
you must pair the remote with your device.
1
Bring the remote within 1 m (3 ft.) of the device.
NOTE: You must stay 10 m (33 ft.) away from other ANT+
sensors while pairing.
2
On the Varia device, hold the device key for 1 second to turn
it on.
3
Select the Varia device key to enter smart mode.
The status LED starts flashing blue.
4
On the Varia remote, hold two keys simultaneously until the
status LED starts alternating green and red, and release the
keys.
The remote searches for your Varia device. After the remote
pairs successfully, the status LED flashes green 12 times.
After the remote is paired, it connects to your device whenever
the device is in range and turned on in smart mode. You may
need to wake the remote by selecting any key.
Using the Mounts
Several mounts are available for your remote, either included
with the product or as an optional accessory. The mounts allow
you to attach the remote to your body, your bike, or other
objects.
• Align two of the notches
press the remote into the mount until it clicks.
2
with the sides of the mount, and
• Press gently on the release tab
the mount.
Replacing the Battery
Do not use a sharp object to remove batteries.
Keep the battery away from children.
Never put batteries in mouth. If swallowed, contact your
physician or local poison control center.
Replaceable coin cell batteries may contain perchlorate
material. Special handling may apply. See
/hazardouswaste/perchlorate.
Contact your local waste disposal department to properly
recycle the batteries.
Before you can replace the battery, you must have a small
Phillips screwdriver, a small flat screwdriver, and a CR2032
lithium coin-cell battery.
1
Using a Phillips screwdriver, remove the three screws from
the back plate
2
Remove the back plate from the remote.
3
Wrap the end of a small flat screwdriver with tape.
®
The tape protects the battery, battery compartment, and
contacts from damage.
4
Carefully pry the battery from the back plate.
5
Install the new battery into the back plate with the positive
side facing down.
6
Verify the gasket
, and lift the remote from
WARNING
www.dtsc.ca.gov
CAUTION
.
is fully seated in the groove.
Installation Instructions
