Page 1 Generic 1005 Practices Index...
Page 2 1005 Generic Practices Index NOTICE The information contained in this document is believed to be accurate in all respects but is not warranted by Mite1 Corporation (MITELB). The information is subject to change without notice and should not be construed in any way as a commitment by assume no responsibility for any errors or omissions in this document.
Page 3 Generic 1004, Generic 1005, Generic 1005 FPKGI , and Generic 1005 LIT96. Documentation Index The SX-200 DIGITAL PABX documentation is contained in 2 volumes as follows: Volume 1 - Features and Services, Hardware (9109-096001-NA) contains a system description, feature operation information and hardware descriptions of circuit cards and peripheral equipment.
Page 4 Generic 1005 Practices Index Table l-l Generic 1005 FDl Practices Index Features and Ssrvices, Hardware Practice Number Title Generic 1005 Practices Index General Description 3109-096-l OO-NA Features Description 3109-096-l 05-NA Automatic Route Selection and Toll Control Station Message Detail Recording Tenanting Traffic Measurement Hotel / Motel Feature Package Description...
Page 5 -General Description All rlghls msewed.
Page 6 General Description Revision 0...
Page 7 IMPORTANT SAFETY INSTRUCTIONS Failure to follow all instructions may result In improper equlpment operation and/or the risk of electric shock. Only qualified personnel should install and service this product. Read all instructions before attempting to install or use this product. Install all assemblies using the procedures described in this Practice.
Page 8 General Description Revision 0 9109-096-l OO-NA Issue 1...
Page 9: Table Of Contents
SX-200 FD System configuration ........
Page 10 Figure 3-7 SX-200 FD Peripheral Cabinet ........
Page 11: General
Practice 9109-096-I 80-NA, Engineering Information Practice 910949~200-NA, Installation Information Reason for issue This practice describes the SX-200 DIGITAL PABX with seven Generic software loads. This is the first issue with Generic 1005 FPKG 1 software, Generic 1005 LIT 96 software, and Generic 1005 software.
Page 12 General Description Revision 0 9109-096-l OO-NA Issue 1 100 1-2...
Page 13: System Overview
The 456 and 480-port configurations are hybrid systems, using digital control circuits with a mixture of digital and analog peripheral cards. Customers with installed SX-200 analog systems may upgrade to the latest in digital switching technology (456-pat-t) while retaining their investment in cabinets, power supplies, line cards, and trunk cards.
Page 14 Note: The 456-part configuration is available only as an upgrade. Customers can upgrade their installed SX-200 PABX to an SX-200 DIGITAL PABX by adding a digital Control cabinet to the existing analog cabinet. The 480-port configuration is similar to the 456port configuration in that it combines a digital control cabinet with an analog peripheral cabinet.
Page 15: Physical Characteristics
Depth Per Cabinet 151 kg 333 pounds Weight Fuliy Loaded System Requirements The environmental and electrical requirements for the SX-200 DIGITAL PABX are shown in Table 2-2 and Table 2-3 respectively. Table 2-2 Environmental Requirements Operating Temperature 10 to40° c...
Page 16: Software Configurations And Supported Peripheral Devices
Description Software Configurations and Supported Peripheral Devices Seven software configurations are available for the SX-200 DIGITAL PABX: Generic 1001 ,I 002, 1003, 1004, 1005 FPKG 1, 1005 LIT 96, and 1005. The following subsections outline the features offered and the hardware configurations supported...
Page 17: Generic1004
Applications Platform Package (includes HCI” and CCM) Automatic Call Distribution Generic 1005 FPKG 1 and Generic 1005 LIT 96 software are only available for SX-200 FD system configurations. Generic 1005 LIT 96 software supports only one peripheral cabinet (96 ports).
Page 18: Voicecapabilities
General Description Capabilities Voice The SX-200 DIGITAL PABX interfaces to analog and digital peripheral devices using standard twisted-pair office wiring. Peripheral devices include, but are not limited to, the following: Standard Telephones: Industry-standard rotary dial and DTMF telephones are supported; ONS lines provide an interface for these sets.
Page 19: Data Capabilities
SX-200 DIGITAL PABX through a Digital Line Card. The DATASET 2100 series support asynchronous and synchronous data communications at rates up to1 9.2 kbps and interface with the SX-200 DIGITAL PABX through a Digital Line Card. Data capabilities are not available with Generic 1001.
Page 20: Customer Data Entry (Cde)
General Description between a host computer and DATASET 1101 Cartridges or DATASET 1103 Standalone datasets connected to the PABX. DATASET 1102 Dual Rack Mounted card is not available with Generic 1001. case which can be placed under a standard desk telephone set. It is functionally the same as the DATASET 1101 Cartridge or one-half of the DATASET 1102 Dual Rack Mounted card.
Page 21 System Overview TRUNK ONS / DLC 6 C C T D I R E C T I N W A R D Figure 2-l SX-200 DIGITAL PABX Bay and Slot Assignment - 336-Port Configuration Revision 0 100 2-9 9109-096-l Issue 1...
Page 22 V O I C E / D A T A C A R D S : VOICE CAFftS: 6 CCTKARD COV OR REGvv\R LINE 4 CCTKARD CO. T R U N K 2 CCT;CAPD Figure 2-2 SX-200 DIGITAL PABX Bay and Slot Assignment - 455-Port Configuration Revision 0 Issue 1 100 2-10 9109-096-l OO-NA...
Page 23 System Overview IF NO CARDS PRESENT IN MY 1 Figure 2-3 SX-200 DIGITAL PABX Bay and Slot Assignment - Revision 0 100 2-11...
Page 24: Figure 24 Sx-200 Digital Pabx Bay And Slot Assignment - 672-Part Configuration
General Description Figure 2-4 SX-200 DIGITAL PABX Bay and Slot Assignment - 100 2-12 Revision 0 9109-096-l OO-NA Issue 1...
Page 25 E A C H P E R I P H E R A L CABIN!3 H O L D S U P T O E I G H T I N T E R F A C E C A R D S (95 POWS/CASlNt-r) Figure 2-S SX-200 FD Control Cabinet and Peripheral Cabinet - Bay and Slot Assignments...
Page 26 General Description Revision 0 Issue 1 100 2-14...
