Sharp HT-DP2500W Service Manual

Hide thumbs Also See for HT-DP2500W:
Table of Contents

Advertisement

Quick Links

Manufactured under license from Dolby Laboratories Licens-
ing Corporation.
DOLBY, the double-D symbol
trademarks of Dolby Laboratories Licensing Corporation.
AC POWER SUPPLY CORD AND AC PLUG ADAPTOR ...................................................................................................... 1
VOLTAGE SELECTION .......................................................................................................................................................... 2
SPECIFICATIONS ................................................................................................................................................................. 2
NAMES OF PARTS ............................................................................................................................................................... 3
OPERATION MANUAL .......................................................................................................................................................... 4
DISASSEMBLY ...................................................................................................................................................................... 6
ADJUSTMENT ...................................................................................................................................................................... 8
NOTES ON SCHEMATIC DIAGRAM .................................................................................................................................... 9
BLOCK DIAGRAM ............................................................................................................................................................... 10
SCHEMATIC DIAGRAM/WIRING SIDE OF P.W.BOARD ................................................................................................... 12
TYPES OF TRANSISTOR AND LED.................................................................................................................................... 19
FUNCTION TABLE OF IC.................................................................................................................................................... 24
FL SEGMENT ...................................................................................................................................................................... 28
AC POWER SUPPLY CORD AND AC PLUG ADAPTOR
QACCE0008AW00
QACCL0005AW00
All manuals and user guides at all-guides.com
SERVICE MANUAL
and "PRO LOGIC" are
CONTENTS
SHARP CORPORATION
- 1 -
HT-DP2500W
HT-DP2500W home theater system consisting of
HT-DP2500W home theater system, CP-F2500W,
CP-SW2500W, CP-C2500W and CP-SR2500W.
• In the interests of user-safety the set should be restored to its original
condition and only parts identical to those specified should be used.
OPLGA0250AFZZ
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
HT-DP2500W
No. S0884HTDP2500
Page

Advertisement

Table of Contents
loading

Related Manuals for Sharp HT-DP2500W

Summary of Contents for Sharp HT-DP2500W

  • Page 1: Table Of Contents

    All manuals and user guides at all-guides.com HT-DP2500W SERVICE MANUAL No. S0884HTDP2500 HT-DP2500W HT-DP2500W home theater system consisting of HT-DP2500W home theater system, CP-F2500W, CP-SW2500W, CP-C2500W and CP-SR2500W. Manufactured under license from Dolby Laboratories Licens- ing Corporation. • In the interests of user-safety the set should be restored to its original DOLBY, the double-D symbol and "PRO LOGIC"...
