- Page 1 Si011084 REMOVAL PROCEDURE S E R V I C E M A N U A L 5.0 kW Class Outdoor Unit Non-Inverter Pair Type...
- Page 2 Service Manual Removal Procedure Outdoor Unit Cooling Only RN50HV1A RN50JV1...
-
Page 3: Table Of Contents
Si011084 Table of Contents 1. Removal of Outer Panels ................2 2. Removal of Outdoor Fan / Fan Motor .............5 3. Removal of Sound Blankets..............7 4. Removal of Electrical Components ASSY ..........9 5. Removal of Compressor ASSY.............11 Removal Procedure... -
Page 4: Removal Of Outer Panels
Removal of Outer Panels Si011084 1. Removal of Outer Panels Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 4 screws and remove the top Top panel panel. - Page 5 Si011084 Removal of Outer Panels Step Procedure Points Remove the 6 screws of the front panel. (R5395) Unfasten the center hooks in the order of (1) to (2). (R13614) Lift the left side of the front panel and unfasten the 3 hooks. Hook (R5397) Removal Procedure...
- Page 6 Removal of Outer Panels Si011084 Step Procedure Points Unfasten the hook on the right side and remove the front panel. (R5398) Remove the screw and remove the stop valve cover. (R5399) Stop valve cover The stop valve cover has 6 hooks.
-
Page 7: Removal Of Outdoor Fan / Fan Motor
Si011084 Removal of Outdoor Fan / Fan Motor 2. Removal of Outdoor Fan / Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Disconnect the relay connector for the fan motor. - Page 8 Removal of Outdoor Fan / Fan Motor Si011084 Step Procedure Points Cut the 3 clamps and Put the fan motor lead wire release the fan motor through the back of the fan lead wire. motor when reassembling so as not to be entangled with the outdoor fan.
-
Page 9: Removal Of Sound Blankets
Si011084 Removal of Sound Blankets 3. Removal of Sound Blankets Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the right side panel. Right side Remove the 4 screws. - Page 10 Removal of Sound Blankets Si011084 Step Procedure Points Lift up and remove the right side panel. (R5409) When reassembling, fit the 2 lower hooks. Hook (R5410) 2. Remove the sound blankets. Sound blanket Remove the sound (top) blanket (top). (R5412) Remove the sound blanket (body).
-
Page 11: Removal Of Electrical Components Assy
Si011084 Removal of Electrical Components ASSY 4. Removal of Electrical Components ASSY Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the nut and remove the terminal Terminal cover cover. - Page 12 Removal of Electrical Components ASSY Si011084 Step Procedure Points Remove the gasket. (R5417) Gasket Remove the screw of the electrical components ASSY. Screw (R5418) Lift up the electrical components ASSY and Electrical components ASSY unfasten the guide for the partition plate. Remove the electrical components ASSY.
-
Page 13: Removal Of Compressor Assy
Si011084 Removal of Compressor ASSY 5. Removal of Compressor ASSY Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 3 nuts of the compressor ASSY. Warning Be careful not to get yourself burnt with the pipes and other... - Page 14 Revision History Month / Year Version Revised contents 01 / 2013 Si011084 First edition...
- Page 15 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
