TEFAL Instant Steam IT21 Series Manual

TEFAL Instant Steam IT21 Series Manual

Hide thumbs Also See for Instant Steam IT21 Series:

Advertisement

Quick Links

Download this manual
INST NT STE M
IT21XX
www.tefal.com

Advertisement

loading

Related Manuals for TEFAL Instant Steam IT21 Series

Summary of Contents for TEFAL Instant Steam IT21 Series

  • Page 1 INST NT STE M IT21XX www.tefal.com...
  • Page 2 * Depending on model...
  • Page 3 PRODUCT DESCRIPTION Steam Head Pole Fastener 2 *. Fabric Brush Hose Connector & Lock 2B*. Crease attachment On/Off Indicator 2C*. Pant Clips On/Off Pedal 2D*. Lint Pad Pole Locks Steam head craddle Power cord Foldable Hanger Water tank Woven fabric steam hose Wheels Power Cord Hook * Depending on model...
  • Page 4 IMPORT NT S FETY INSTRUCTIONS • When using your appliance, basic precautions should always be followed, including the following: • Read all instructions before using this product. • This product has been designed for indoor, domestic use only. Any commercial use, inappropriate use or failure to comply with the instructions, the manufacturer accepts no responsibility and the guarantee will not apply.
  • Page 5 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 electrical shock or injury to persons when the appliance is used. • Close supervision is necessary for any appliance being used by or near children. • Never leave the appliance unattended when it is connected to the mains. Before storing the appliance, once it is unplugged, please wait until it has cooled down (around 1 hour).
  • Page 7 supervised to ensure that they do not play with the appliance. • The use of accessory attachments other than those provided by the manufacturer is not recommended and may result in fire, electric shock or personal injury. • The appliance must be rested on a stable surface. When placing the appliance on its base, ensure that the surface on which the base is placed is stable.
  • Page 8 1. SSEMBLY Insert the pole in the housing & then screw until lock. Open the two pole locks. Extend the pole fully. Close the two locks.
  • Page 9 Fully insert the hanger vertically on top of the pole. Click Position the steam head on its craddle. Fully insert the hose and then turn clockwise until full locking by click sound. Please pay attention to fully lock the hose to its base to avoid hot water spitting.

  • Page 10: Before Use

    2. BEFORE USE Remove the water tank. Remove the cap then fill in the water tank. 1,8L 60OZ Fully screw the water tank cap and insert tank back in appliance. Extend both sides of hanger.
  • Page 11 Add the clothe of your choice on the hanger. 3. CCESSORIES Accessories must be settled when appliance is cold and not running. The fabric brush opens the weaves of the fabrics for better steam penetration. Attach the fabric brush to the steam head when appliance is unplugged.
  • Page 12 The crease attachment allows you to create crease either on your pants or jackets. Position the steam head on its craddle. Use the lint pad to remove hair, lint and animal fur the lint pad must not be used when attached to the appliance. If your appliance is featured with removable pant clips, you can use them by inserting and pushing down.
  • Page 13 4. USE Appliance has to remain horizontally set on ground floor. Plug in the appliance. Press once the ON/OFF pedal and check that light is switching on. Wait for 60 seconds before steaming. After 60 seconds approximately, steam will come out.

  • Page 14: During Use

    For optimal use, pass the steam jets on your garment from top to bottom. Never steam directly on people. 5. DURING USE If steam is not coming out anymore, this can be due to low water level in tank.
  • Page 15 Remove the water tank. Remove the cap then fill in the water tank. Fully screw the water tank cap and insert tank back in appliance. Press the ON/OFF pedal and check that light is switching on. Wait for 60 seconds before steaming.
  • Page 16 6. FTER USE Press the On/Off Pedal and check that light is switched Off. Unplug the appliance. Remove the water tank. Unscrew the cap and then empty the water tank completely in a sink.
  • Page 17 Screw back the cap and place the water tank back to its appliance. Press on the button located on the hanger to bring down the arms. Roll up the power cord and place it on its hook. Wait for an hour for your appliance to cool before storing.
  • Page 18 7. DESC LING PROCEDURE W RNING! Wait for an hour that appliance completely cools down. Ensure that hose is cold and Unlock anti- clockwise. Disconnect the hose it from its base and remove the steam head from its craddle. Unscrew the locker and pull out the pole. Remove the water tank.
  • Page 19 Never fill inside pole connection. 0.5 L Fill in 0,5l of water in the appliance hose 17OZ connection. Water 0.5 L Fill in 0,5l of water in the appliance tank 17OZ inlet. Water Shake Gently the appliance to remove the main particles.
  • Page 20 Vertically tilt the appliance to empty water in a sink. Prepare a 1L mix of 0,5L of water & O,5l Water Water Water 0.5 L of white vinegar only. Fill in 0,5l of mix in 17OZ the appliance hose connection. White White White...
  • Page 21 Vertically tilt the appliance to empty mix in a sink. 0.5 L Fill in 0,5l of water in the appliance hose 17OZ connection. Water 0.5 L Fill in 0,5l of water in the appliance tank 17OZ inlet. Water Vertically tilt the appliance to empty water in a sink.
  • Page 22 Insert the pole in the housing & then screw until lock. Fully insert the hose and then turn clockwise until full locking by click sound. Position the steam head on its craddle. Remove the cap then fill in the water tank. 1,8L 60OZ...
  • Page 23 Fully screw the water tank cap and insert tank back in appliance. Plug in the appliance. Let the appliance run until water tank is emptied completely.
  • Page 24 8. CLE NING Wait an hour for complete cool down. only use a sponge with water to clean the basis. Only use a sponge with water to clean the steam head. Never use liquids or detergents when cleaning your appliance.
  • Page 25 Never wash or rinse appliance directly over a sink. Never wash or rince the steam head directly over a sink.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Problems Possible causes Solutions There is no steam. The appliance has not Check that the appliance has been been turned on. plugged in correctly. Next press the On/Off pedal, the power indicator light located at the front of the appliance will come on.
  • Page 27 9100020147-01 - 48/15...
