Operation Instruction ® VARIODYN D1 Comprio 798666.HO.GB0 Technical changes reserved. 07.2013 / AA © 2013 Honeywell International Inc. - Page 2 ® Operation Instruction VARIODYN D1 Comprio Intended use This product may only be used for the applications outlined in the catalogue and the technical description and in combination with external devices and components which have been recommended or approved by us. Warning To ensure correct and safe operation of the product, all instructions concerning its proper transport, storage, installation and mounting must be observed and it must be operated with care.
-
Page 3: Table Of Contents
Responsibility of the Operator ..........................5 Associated Documents ............................5 Display and Operating Elements ..........................6 ® VARIODYN D1 Comprio ........................... 6 Power Amplifiers (PA) 4XD Series ........................17 Maintenance and Installation ........................... 19 Service / Maintenance Contact Information ......................20... -
Page 4: General / Application
® Operation Instruction VARIODYN D1 Comprio General / Application ® Thank you very much for choosing VARIODYN An emergency audio warning system or a voice alarm system as defined by the standards DIN VDE 0833-4 and TRVB S 158 must consist of components that satisfy the standards of the series DIN EN 54. It must be ensured that these components interact together in a manner appropriate to the function. -
Page 5: Responsibility Of The Operator
Operation Instruction VARIODYN ® D1 Comprio Responsibility of the Operator In addition to the standard-compliant design, a definition of the minimum requirements and functions between the operator of the system and the responsible authorities is needed for the setup and operation of a voice alarm system. -
Page 6: Display And Operating Elements
® Operation Instruction VARIODYN D1 Comprio Display and Operating Elements ® VARIODYN D1 Comprio ® The functions of the VARIODYN D1 individual components are collected together in the compact control unit. A control unit consists of a digital output module (DOM), a universal interface module (UIM) with a reduced number of control contacts, a view control module (VCM) and an integrated voice input station with 12 programmable buttons. - Page 7 ® Operation Instruction VARIODYN D1 Comprio Voice input station The buttons of the terminal are freely programmable. The desired function is programmed in the system configuration by the installer with features specific to the building and customer. The buttons of the terminal can be used to start announcements or execute system functions.
- Page 8 Operation Instruction VARIODYN ® D1 Comprio Example of function key assignment Pre-selection of circuit 1 (button with toggle function) Selects circuit 1 (or multiple circuits, if programmed), which can be used as the target of an Circuit 1 announcement. Pre-selection of circuit 2 (button with toggle function) Circuit 2 As described above, except circuit 2 Announcement / speak (keep button held pressed)
- Page 9 ® Operation Instruction VARIODYN D1 Comprio Display and operation of collective messages The display and operation of standards-compliant collective messages is possible. These are displayed audibly via the integrated buzzer and visibly via the LEDs. Using the 4 operating buttons, it is possible to switch off or mute messages or perform a lamp test of the system.
- Page 10 ® Operation Instruction VARIODYN D1 Comprio Interface module ® Interface module for connecting external analogue audio signals. The VARIODYN D1 Comprio has 12 control contacts, 2 audio line ins, 1 audio line out for activating external devices, such as analogue call stations (DIGIM) and fire alarm systems.
- Page 11 ® Operation Instruction VARIODYN D1 Comprio Control unit LED indicators of control contacts 1-8 LED indicators of the audio outputs 1-4 (amplifier channels), LINE RELAY and LINE ERROR LED indicators of the DAL connections Collective LED indicators for : Power Error Stand-alone operation Powersave...
- Page 12 ® Operation Instruction VARIODYN D1 Comprio LED indicators – Status of an amplifier channel The functioning of the amplifiers is constantly monitored. The result of this check is indicated by the LEDs of the amplifier channels CHANNEL 1 and 2 (see Fig. 4). The following status indications are possible: CHANNEL 1 Fig.4: LED of amplifier CHANNEL 1 (example) 100 V amplifier channel not in use...
- Page 13 ® Operation Instruction VARIODYN D1 Comprio LED indicators of the LINE RELAY If a loudspeaker circuit is currently in use by e.g. an announcement, this is indicated by the corresponding LED. A separate relay (LINE RELAY) for each loudspeaker line is used for this with object-specific programming. The LINE RELAY LEDs indicate which loudspeaker lines are active.
- Page 14 ® Operation Instruction VARIODYN D1 Comprio LED indicator for the DAL BUS Digital call stations (DCS) or Universal Interface Modules (UIM) can be connected to the three digital audio links (DAL). The 4th DAL is used for internal connections. The modules are controlled via the DAL BUS and are supplied with 24 V operating voltage.
- Page 15 ® Operation Instruction VARIODYN D1 Comprio Collective LED indicators These LED indicators show the general status of the control module. ERROR POWER STANDALONE POWERFAIL MONITOR Fig. 9: Common displays ERROR / Acknowledge error message Normal operation The integrated buzzer can be acknowledged by pressing the >Monitor< Flashing yellow, button.
- Page 16 ® Operation Instruction VARIODYN D1 Comprio STANDALONE Networking ON, yellow No networking = Stand-alone operation POWERFAIL Normal operation ON, yellow One of the energy supplies (power supply or emergency power) is faulty Monitor button The buzzer can be switched off by pressing the button. To check whether an audio signal is currently present on an amplifier or DAL channel, the audio inputs and outputs on the control unit can be prelistened to via the integrated speaker using the monitor button.
-
Page 17: Power Amplifiers (Pa) 4Xd Series
® Operation Instruction VARIODYN D1 Comprio Power Amplifiers (PA) 4XD Series The power amplifiers (PA) serve to amplify the voice/audio signal. Amplifiers are connected to the control module and also controlled via the control module. The amplifier as well as the cabling is constantly monitored depending on the configuration. - Page 18 ® Operation Instruction VARIODYN D1 Comprio POWER CHANNEL 1 - 4 Amplifier final stages switched off ON, green Normal operation SYS FAULT No error present ON, yellow System fault of the amplifier BATT POWER Normal operation ON, yellow Emergency power operation (amplifier is supplied by the battery) MAINS POWER No 230 V operating voltage present ON, green...
-
Page 19: Maintenance And Installation
® Operation Instruction VARIODYN D1 Comprio Maintenance and Installation Operation and maintenance of hazard warning systems (HWS) Requirements as per VdS guidelines and VDE 0833-1 and 2: The operator of the HWS must have received proper training or must have the work performed by someone who has received proper training. -
Page 20: Service / Maintenance Contact Information
® Operation Instruction VARIODYN D1 Comprio Service / Maintenance Contact Information The following service / maintenance contract information as well as important contact persons should be recorded. Service / maintenance personnel Maintenance contract :______________________(No.) ________________________from:________________ Company : ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ Contact person : ______________________________________________________________________ Address... - Page 21 ® Operation Instruction VARIODYN D1 Comprio Notes FB 798666.HO.GB0 / 07.13...
- Page 22 ® Operation Instruction VARIODYN D1 Comprio Notes FB 798666.HO.GB0 / 07.13...
- Page 23 ® Operation Instruction VARIODYN D1 Comprio Notes FB 798666.HO.GB0 / 07.13...
