- Page 1 Rear Camera System Owner’s Manual...
- Page 2 Special Messages • We provide many important safety messages in this manual. For your safety and safety of others, pay special attention to all warnings preceded by this alert symbol Failure to follow the warnings contained in this manual can result in serious injury or accident. DANGER •...
-
Page 3: Table Of Contents
Contents Introduction ... 4 Warnings and Advice ... 5 Reading Picture Taken by Rear Camera System ... Installation of CCD Camera (Example) ... 10 Dimensional Drawing ... 11 Specifications ... 12 Troubleshooting... 13 Warranty Card ... 14 © 2005 American Honda Motor Co., Inc. - All Rights Reserved. -
Page 4: Introduction
Please read this Owner’s Manual carefully before using the rear camera, and keep this manual in the glove box for future reference. This product is designed to be used exclusively on an Acura RL. Acura is not responsible if the unit is used for any other intended purpose. -
Page 5: Warnings And Advice
DANGER Not applicable WARNING Not applicable CAUTION Use this rear camera system as a Supplementary System to check the obstructions. Avoid rain drops on the camera as it can cause poor photographing performance of the camera. When you reverse the vehicle, use extreme care and check for safety behind the vehicle with your eyes. - Page 6 ADVICE • Do not disassemble or modify this rear camera system. It can cause malfunction of the system. • The camera of this system is structured as the drip-proof sealed type for prevention of dew condensation on the lens. Do not loosen the screws on the camera and do not disassemble the camera, either.
- Page 7 The system failure can occur and/or the system can give out smoke causing unrepairable serious Smear band damage to the system. When either of these Strong symptoms occurs, stop the system immediately light point and consult with your authorized Acura dealer. Bumper...
- Page 8 INFORMATION • The picture reflected in the monitor screen is the mirror image. The mirror image represents the bilaterally symmetric image just like the picture you look in the rear view mirror or door mirror of a vehicle. The picture that you directly look at with your eyes is referred to as the normal image.
-
Page 9: Reading Picture Taken By Rear Camera System
Turn the ignition switch key to the ON (II) position. Move the gearshift lever to the “R” (Reverse) position. The monitor screen automatically switches to the CCD camera’s picture. © 2005 American Honda Motor Co., Inc. - All Rights Reserved. Reading Picture Taken By Rear Camera System ADVICE The rear camera’s picture can be different from the... -
Page 10: Installation Of Ccd Camera (Example)
Installation Of CCD Camera (Example) CCD CAMERA 5628080H CAUTION Note that the area where is reflected to the monitor screen is limited. When you reverse the vehicle, use extreme care and check for safety behind the vehicle with your eyes. ©... -
Page 11: Dimensional Drawing
Color CCD camera 1-1/4" (32 mm) 1-1/2" (38.2 mm)* Dimension changes in the range of ±1/64" (0.5 mm) depending on the focus position of the lens. © 2005 American Honda Motor Co., Inc. - All Rights Reserved. 15/16" (24 mm) 4219030M Dimensional Drawing... -
Page 12: Specifications
Specifications Color CCD camera Image pickup element: 1/4-inch interline transfer type CCD (Picture element: approx. 250,000) Lens: Angle of view: Horizontal Approx. 126° Vertical Approx. 83° Image pickup performance: Resolution: Horizontal 300 min. (Around the center of the picture) Vertical 300 min. (Around the center of the picture) Minimum illuminance of subject: 1.5 Lux max. -
Page 13: Troubleshooting
Drive the vehicle carefully while checking for safety according to the vehicle condition behind the vehicle with your eyes. (number of passengers and load) and environmental condition. Camera out of the installation Consult with your authorized Acura dealer. position or out of the angle. Troubleshooting Remedy... -
Page 14: Warranty Card
• If the rear camera system is still out of order: The rear camera system will be repaired according to the provisions on the Warranty Card. Have your authorized Acura dealer repair the rear camera system. • Repair during the period covered by warranty: The rear camera system will be repaired according to the provisions on the Warranty Card. - Page 15 08B21-SJA-2000-81 © 2005 American Honda Motor Co., Inc - All Rights Reserved. Printed in Japan...
