Swann SR244-BVD Easy Setup Manual

A
Package Contents
Packaging
Monitor
Camera
Hardware
Extension
Cable
C
1
Swann Communications • Toll Free Technical Support: USA - 1-800-627-2799, 1-877-274-3695, Australia - 1300 13 8324 • Email: tech@swannsecurity.com
B&W Video Doorphone - Easy Setup Guide
B
Manual
Speaker
Power
Supply
Microphone
Mounting Bracket
Back
1. Connect small prongs of wire to monitor
2. Connect large prongs to camera
3. Connect power supply to unit
3
Power Supply
Speaker
ALARM Button
UNLOCK Latch Button*
TALK/VIDEO Button
* Door Latch Sold Separately
Front
2
Extension Wire
Getting to Know Your Doorphone
Microphone
CALL
Button
Doorbell Volume
Brightness
Doorphone Connections
Back
A B
SR244-BVD-10005
www.swannsecurity.com
