Even though the network interfaces into the service processors are encrypted for the Secure Sockets
v
Layer (SSL) Protocol and password-protected, having a separate dedicated network can provide a
higher level of security for these interfaces.
v An open network interface would typically be used for the network connection between the HMC and
the logical partitions on the managed systems, for the HMC-to-logical partition communications. You
can also use this open network interface to manage the HMC remotely.
v Optionally, you can use a third interface to connect to logical partitions and manage the HMC
remotely. This interface can also be used as a separate HMC connection to different groups of logical
partitions. For example, you might want to have an administrative LAN that is separate from the LAN
on which all the usual business transactions are running. Remote administrators could access HMCs
and other managed units using this method. Sometimes the logical partitions are in different network
security domains, perhaps behind a firewall, and you might want to have different HMC network
connections into each of those two domains.
Web browser requirements for HMC
The Hardware Management Console (HMC) is supported by Microsoft Internet Explorer (IE) version 6.0
and 7.0, Firefox version 1.5.0.7 and 2.0.
If your browser is configured to use an Internet proxy, a local IP addresses should be included in the
exception list. Consult your network administrator for more information on the exception list. If you still
need to use the proxy to get to the HMC, enable Use HTTP 1.1 through proxy connections under the
Advanced tab in your Internet Options window.
Note: For Firefox version 2.0, ensure that you enable the JavaScript options to raise or lower windows
and move or resize existing windows. This feature allows you to switch easily between HMC tasks.
Perform the steps to enable the Javascript options:
1. Select Tools and Click Options
2. Select Content and Click Advanced
3. Select Move or resize existing windows and Raise or lower windows
4. Click OK
Session cookies need to be enabled in order for ASMI to work when connected to HMC remotely. The
asm proxy code saves session information and uses it. Follow the steps to enable the session cookies.
Enabling session cookies in Internet Explorer.
1. Select Tools and Click Internet Options
2. Select Privacy and Click Advanced
3. Ensure that the Always allow session cookies is checked. If not, select the Override automatic cookie
handling and select Always allow session cookies.
4. Select Prompt under First-party Cookies and Third-party Cookies
5. Click OK.
Enabling session cookies in Firefox.
1. Select Tools and click Options
2. Click Cookies
3. Select Allow sites to set cookies.
4. Select Exceptions and add HMC.
5. Click OK.
