Ryobi ECS1400K Owner's Operating Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
SPECIFICATIONS :
Power Input
Max No Load Speed
Blade Diameter
Blade Bore Diameter
Depth of Cut @90˚
@45˚
Weight
THANK YOU FOR BUYING A RYOBI CIRCULAR SAW
Your new saw has been engineered and manufactured to Ryobi's high standard for dependability,
ease of operation, and operator safety. Properly cared for, it will give you years of rugged,
trouble free performance.
CAUTION: Carefully read through this entire owner's manual before using your
Pay close attention to the Rules for Safe Operation, Warnings and Cautions.
If you use your saw properly and only for what it is intended, you will enjoy years of safe, reliable
service.
Thank You again for buying Ryobi tools.
1400 watt
5100 rpm
190 mm
16 mm
66 mm
50 mm
5.1kg
circular saw
SAVE THIS MANUAL FOR FUTURE REFERENCE.
D O U B L E
I N S U L A T E D
N197

Advertisement

loading

Related Manuals for Ryobi ECS1400K

Summary of Contents for Ryobi ECS1400K

  • Page 1 N197 THANK YOU FOR BUYING A RYOBI CIRCULAR SAW Your new saw has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble free performance.
  • Page 2 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7A Fig. 7B...
  • Page 3 Fig. 8 Fig. 9 Fig. 10A Fig. 10B Fig. 11 Fig. 12 Fig. 13A Fig. 13B...
  • Page 4 DESCRIPTION 1. Spindle lock button 12. Depth lock knob 2. Hex - head bolt 13. Base plate 3. Spanner 14. Depth of cut 4. Outer blade washer 15. Depth scale 5. Lower guard 16. Bevel adjustment knob 6. Lower guard lever 17.

  • Page 5: Rules For Safe Operation

    RULES FOR SAFE OPERATION INSTRUCTIONS FOR SAFE HANDLING CAUTION Make sure that the voltage used corresponds to the voltage marked on the tool's identification plate. The blade coasts a little while after the trigger is released. The maximum permissible system impedance: Zmax for SUPPORT LARGE PANELS.

  • Page 6: Standard Accessories

    RULES FOR SAFE OPERATION Ensure that the diameter, thickness and other Use safety glasses. Always use a face or dust mask if characteristics of the saw blade are suitable for the tool. the cutting operation is dusty. Keep work area clean. Cluttered areas and workbenches Connect dust extraction equipment.

  • Page 7: Maintenance

    OPERATION ADJUSTING THE DEPTH OF CUT (Fig. 7A, 7B, 8, 9) OPERATING INSTRUCTIONS (Fig. 12) To adjust the depth of cut, loosen the depth adjustment knob(12). (See Fig. 7A) DANGER Slide the base plate(13) to the desired depth using the Keep hands away from the cutting area when operating depth adjustment lug(21) and retighten the knob securely.
  • Page 8 AUCKLAND: 27 Clemow Drive, Mt Wellington, N.Z. Tel: (09) 573 0230 - Free Call: 0800 279 624 - Fax: (09) 573 0231 - www.ryobi.co.nz Contact during normal business hours. This Guarantee Form Should Be Retained By The Customer At All Times For your record and to assist in establishing date of purchase (necessary for in-guarantee service) please keep your purchase docket and this form completed with the following particulars.
