- Page 1 EDIA IXED ITE DISPLAY NSTALLATION MANUAL For I6, I6 XP, I8, I10 & I12 tiles 05042004 R5976522/02...
- Page 2 Barco nv Media Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: media@barco.com Visit us at the web: www.barco.com Printed in Belgium...
- Page 3 The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.
-
Page 5: Table Of Contents
Table of contents TABLE OF CONTENTS 1. Safety ........................3 Safety guidelines . - Page 6 Table of contents R5976522 FIXED ILITE DISPLAY 05042004...
-
Page 7: Safety
Structural & mounting components should be kept dry, clean, lubricated (only if recommended), coated properly, and otherwise maintained in a manner consistent with part design. Barco products must be used in a manner consistent with their design and inspected on a routine basis for security, wear, deformation, corrosion and any other circumstances that may affect the load handling capability of the part. -
Page 8: Important Safety Instructions
1. Safety 1.2 Important safety instructions Instructions: • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Clean only with materials or chemicals that are inert, nonabrasive, noncorrosive and non-marking. Consult the manufacturer for further advice should any doubts exist regarding any cleaning procedure. -
Page 9: Important Warnings
1. Safety 1.3 Important Warnings Important Warnings: • Risk of electric shock: Image 1-5 Risk of electrical shock Risk of electric shock. Do not open. To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. - Page 10 1. Safety R5976522 FIXED ILITE DISPLAY 05042004...
-
Page 11: System Overview
2. System Overview 2. SYSTEM OVERVIEW Overview • Introduction • Support structure • Assembly blocks for an ILite display system • ILite display tiles • Cables for ILite displays • Power boxes • Digitizer • Fiberlink system • Control software 2.1 Introduction The fundamental elements of a ILite display system are: •... -
Page 12: Support Structure
Support structures must be assessed on an individual basis. Never construct a wall if there is uncertainty regarding the stability of an installation or the load holding capabilities. If there are doubts on a systems viability, consult Barco for advise on professional rigging organizations. -
Page 13: Order Info Ilite Assembly Blocks
2. System Overview Image 2-3 ILite assembly blocks. 2.3.2 Order info ILite assembly blocks Order info: Article No. Description R9850780 ILite assembly block H2 x V2 R9850781 ILite assembly block H2 x V3 R9851630 ILite assembly block H2 x V4 R9850782 ILite assembly block H3 x V2 R9850783... -
Page 14: Order Info Ilite Tiles
2. System Overview Image 2-4 ILite tile. 2.4.2 Order info ILite tiles Order info: Article No. Description R9004040 ILite 6 tile R9010250 ILite 6 XP tile R9004060 ILite 8 tile R9004050 ILite 10 tile R9004111 ILite 12 tile 2.4.3 Technical summary ILite tiles 2.4.3.1 Specifications ILite 6 tile Specifications Contrast Ratio... -
Page 15: Specifications Ilite 6 Xp Tile
2. System Overview Temperature range operating: 0°C <> 40°C storage: -20°C <> 60°C Brightness 2.500 NIT Calibrated Brightness 2.000+ NIT Lifetime 45.000h [half brightness] Processing + 10 bit Source compatibility S-Video - Composite - YUV - RGB - SDI - HDSDI - Data DVI up to UXGA 2.4.3.2 Specifications ILite 6 XP tile Specifications Pixel pitch... -
Page 16: Specifications Ilite 8 Tile
2. System Overview Tile dimensions Width: 448mm (17.7") Height: 448mm (17.7") Depth: 149,5mm (5.89") Source compatibility S-Video / Composite / YUV / RGB / SDI / HDSDI / Data DVI up to SXGA 2.4.3.3 Specifications ILite 8 tile Specifications Contrast Ratio 950 : 1 (500 lux) 1625 : 1 (225 lux) Screen size... -
Page 17: Specifications Ilite 12 Tile
2. System Overview Tile dimensions Width: 0,448 m Height: 0,448 m Depth: 0,1495 m Visual Resolution 10 mm Temperature range operating: 0°C <> 40°C storage: -20°C <> 60°C Brightness 2.500 NIT Calibrated Brightness 2.000+ NIT Lifetime 45.000h [half brightness] Processing + 10 bit Source compatibility S-Video - Composite - YUV - RGB - SDI - HDSDI - Data DVI up to UXGA... -
Page 18: Ilite Tile Dimensions
2. System Overview 2.4.4 ILite tile dimensions Dimensions: 101,9 M6 max 15mm deep Image 2-5 Dimensions given in millimeters. 2.5 Cables for ILite displays 2.5.1 Power cables General Depending on the size and configuration of the ILite display several sizes and types of power cables are needed. The picture below (image 2-6) illustrates the available power connector types for an ILite Display. - Page 19 2. System Overview The power cords delivered with the ILite display system have special properties for safety. They are not user serviceable. If the power cords are damaged, replace only with new ones. Never try to repair a power cord. Order info: Article No.
- Page 20 2. System Overview Article No. Description Image R9851671 ILite Spider connector with 6 power outputs (C19) with same lengths. Spider support bracket included. Used to distribute power from a multi power cable to the ILite tiles. Maximum six ILite tiles per Spider output cable. R9851672 ILite Spider connector with 6 power outputs (C19) with custom lengths.
-
Page 21: Data Cables
2. System Overview Image 2-17 Image 2-18 Image 2-19 2.5.2 Data cables General Depending on the size and configuration of the ILite display several sizes and types of data cables are needed. Order info: Article No. Description Image R9851211 DVI-DVI data cable of 0,9 meter (screw type plugs). image 2-20 Used to link data from ILite tile to ILite tile. -
Page 22: Power Boxes
The control software is designed as a graphic user interface (GUI) and can be used to control and configure the digitizer as well as the Barco LED wall via a PC (e.g. XLite Toolset). Refer to the manual of the control software for more information about the control software. -
Page 23: Physical Installation
3. Physical installation 3. PHYSICAL INSTALLATION Overview • Installation of the support structure • Preparation of the ILite assembly blocks • Correct alignment of the ILite assembly blocks • Attach the ILite assembly blocks • ILite tile mounting • Cabling of the ILite display 3.1 Installation of the support structure Follow the important Safety Guidelines. -
Page 24: Removing Sides From Ilite Assembly Blocks
3. Physical installation 3.2.2 Removing sides from ILite assembly blocks 3.2.2.1 Removing sides Why removing sides? For transport reasons all the assembly blocks are delivered with all the sides attached. To join two assembly blocks together one of the two sides at the adjoining edge, has to be removed. Which sides to remove? Either none, one or two sides of each assembly block will have to be removed, dependent on its location in the complete wall assembly. -
Page 25: Removing The Left Side From An Ilite Assembly Block
3. Physical installation 3.2.2.2 Removing the left side from an ILite assembly block Necessary tools • Allen key 4 mm. • Side cutter. How to remove the left side ? 1. Undo and remove only the hexagon bolts in the aluminium corner brackets that secure the left side of the frame. 2. -
Page 26: Correct Alignment Of The Ilite Assembly Blocks
3. Physical installation Image 3-7 3.3 Correct alignment of the ILite assembly blocks How to align assembly blocks correctly ? For correct alignment of the assembly blocks is it important that the basic connection joint between the assembly blocks is properly done. -
Page 27: Attach The Ilite Assembly Blocks
3. Physical installation Image 3-8 Nut. ILite aluminium corner bracket. Hexagon bolt. Aluminium profile. 90º Image 3-9 Making a basic connection joint between two profiles. 3.4 Attach the ILite assembly blocks What has to be done ? The assembly blocks of the wall have to be attached to the support structure in succession and interconnected with one another. Starting in the lower left corner of the ILite display, with the first assembly block (coded x.1.1), from left to right and from bottom row to top row. - Page 28 3. Physical installation A.2.3 A.2.2 A.2.1 A.1.3 A.1.2 A.1.1 Image 3-10 Example of assemble sequence for an ILite display H7xV5. ILite fixation clamp Per attachment point an ILite fixation clamp is required (article no. for 2 pieces : R9851450). Image 3-11 ILite fixation clamp: Mounting plate.
- Page 29 3. Physical installation There are other attachment possibilities then described in this chapter. Contact Barco NV for more informa- tion. Necessary tools • Allen key 4 mm. • Wrench 17 mm. • Wrench 13 mm. • Laser level. Necessary parts •...
-
Page 30: Ilite Tile Mounting
3. Physical installation Image 3-13 Attached mounting plate on the support structure. Shim plate. Assembly block. Support bracket. M8 bolt. M8 nut. Vertical adjoining edge Vertical adjoining edge Horizontal adjoining edge Image 3-14 Example 1: Mounting assembly block A.1.2 into a ILite H7 x V5 display. Vertical adjoining edge. - Page 31 3. Physical installation Image 3-16 ILite tiles pallet. Necessary tools • Wrench 13 mm. • Wrench 10 mm. Necessary parts • ILite tiles. • ILite tile positioning bolts. • ILite tile lock nuts. How to place an ILite tile into the wall assembly ? 1.
-
Page 32: Cabling Of The Ilite Display
3. Physical installation Image 3-18 ILite tile top up. ILite tile positioning bolt. ILite tile lock nut. 3.6 Cabling of the ILite display 3.6.1 ILite tile input/output ports Input/output ports There are tree connection ports on the back of each ILite tile. One power input port and two data input/output ports. The data ports consist in two DVI connectors situated on the resync-unit. -
Page 33: Power Cabling
3. Physical installation Image 3-19 Power linking cable. Power input port. Power link to next tile (C19 plug). Power link from previous tile (C20 plug). Data input/output linking cable. DVI input/output connector. G Resync-unit. 3.6.2 Power cabling 3.6.2.1 Connections with a Mono Phase Power Box Necessary parts •... - Page 34 3. Physical installation power linking POWER calble DATA POWER DATA Mono Phase ILite Power Box (A) tile POWER DATA Power source cable (B) Image 3-20 ILite Mono Phase Power Box. Ouput cable. Power Linking Cable. FIrst ILite tile in a column of maximum six. A power branch, consisting in a column of maximum six tiles, may be interrupted to provide a ILite display peripheral from power.
-
Page 35: Connections With A Custom Power Box
3. Physical installation Example of power cabling with a ILite Mono Phase Power Box ILite display rear view (A) POWER POWER POWER POWER POWER POWER POWER DATA DATA DATA DATA DATA DATA DATA POWER POWER POWER POWER POWER POWER POWER DATA DATA DATA... -
Page 36: Data Cabling
3. Physical installation 5. Complete each power branch by connecting maximum six tiles with power linking cables to each other in a daisy chain manner. The female C13 plug of the power linking cable is plugged directly in the tile. The male C20 and the female C19 plugs serve as power loop through. - Page 37 3. Physical installation When using a Fiberlink System the fiberlink data connection is inserted between the digitizer and the first tile. The Fiberlink Receiver is provided with a ’DATA IN’ and ’DATA OUT’ connector (MDR). Adapted data cables delivered with the Fiberlink system are required. Example of data connections for an ILite H7xV5 ILite Display rear view Last tile...
- Page 38 3. Physical installation It’s recommended that the data cable interconnection got a direction at right angles to the power cable inter- connection, because the resync-unit is able to power up the data connection for the next 2 tiles. So, when 1 power branch is disabled, the data source connection is still accurate.
-
Page 39: Servicing
• Do not modify and/or replicate any component. BARCO uses specific materials and manufacturing processes in order to achieve part strength. No other parts then BARCO parts are allowed. 4.2 ILite tile diagnostic Status LED’s resync-unit... -
Page 40: Tile Accessing
4. Servicing Left red Green LED Right red Diagnostic Flashing ILite tile receives start-up signal on the left I/O port but no sync is present on the data signal. Flashing ILite tile receives start-up signal on the right I/O port but no sync is present on the data signal. -
Page 41: Hot Swap Of An Ilite Tile
4. Servicing 4.4 Hot swap of an ILite tile Necessary parts • Flat blade screw driver. • Wrench 10 mm. How to hot swap an ILite tile ? 1. Read an heed the servicing safety instructions. 2. Disconnect the power cord to the tile. Do not remove the power linking cable out of the power branch. 3. - Page 42 4. Servicing R5976522 FIXED ILITE DISPLAY 05042004...
-
Page 43: Index
Index INDEX Power boxes Assembly blocks 8–9, 23 Attachment Introduction Order info Positioning code Power 29, 31 Connections 29, 31 Custom Power Box Mono Phase Power Box Cables 14, 17 Power boxes Data Preparation Power Positioning code Cabling Correct alignment Removing sides 20–21 Bottom side...
