Barco Visona Specifications

Technical specifications
DISPLAY PROCESSING
General Visualization specifications
Active display area: 503.8 x 503.8 mm • Single X11R6.6 server supporting all graphics outputs
(19.83 x 19.83 inch) • Fast boot (time from power-on to full operation <60s)
Active screen diagonal: 712.4 mm (28.05 inch) • BITE with full SNMP support
Equivalent to 29 inch glass size • Network agents (both secure and non-secure)
Active screen resolution: 2048 x 2048 pixels (4.2 MP) • Multi-layer graphics support for transparent windows
• Anti-aliased line drawing (hardware assisted)
Luminance • Flexible configuration for multi-display cursor travel
Peak brightness: > 240 cd/m 2
Brightness: 150 cd/m 2 calibrated Hardware specifications
Dimming ratio: typically 100:1 • PS/2 or USB interfaces
• USB 2.0 interfaces for optional peripherals
Contrast ratio • RGB output to auxiliary display
200:1 in dark environment • Internal system memory 512 MB (optional 1 GB)
Front glass with high quality, anti-reflective treatment • 10/100BaseT Ethernet
• RS-232
Color performance
Color temperature: 7500°K typical ELECTRICAL
Display colors (without dithering): 16.7 Mio (24bit)
PFC corrected power supply with 110 – 230 VAC Mains, 50 – 60 Hz,
Pixel arrangement: RGB vertical stripe autoswitching
Hor. & vert. pitch 0.246 mm (103 dpi)
MECHANICAL
Viewing angle
Hor. & vert. (min.) +/-80° typical Same outline as ISIS TM
Same versions as ISIS TM : Chassis version
Removable backlight system Panel-mount version
Stabilized using optical feedback system Desktop version
4 trays - field replaceable VESA-mount
Lamp lifetime typically >25,000 hrs Weight chassis version: less than 25kg (55 bs)
Controls OPTIONS
Front control module / On Screen Display
Maintenance keypad • Support for up to three auxiliary displays
• Support for up to three network connections
Control module also available separately to be integrated into • Spare backlight tray
console • Mechanical conversion kits
• C U !™ maintenance software
HECK P
ENVIRONMENTAL • T ™ display recording software
ELLAR
• ODS T Window Manager
OOLBOX ®
Temperature, operating: 10 to 40°C • ILS package
EMI/EMC: designed for FCC Class A Vol II,
EN 5082-2
Safety: designed for UL950, cUL1950,
IEC950, CE, CCC
Noise: designed for <45 dBA
Integrated display server offering full connectivity
Technical specifications are subject to change without prior notice
Barco traffic management
Barco's high-end visualization solutions for Operational Display Systems have been
selected by leading system integrators and air navigation service providers worldwide.
Its complete product range for real-time traffic control, makes Barco a unique one-stop
supplier of advanced components for traffic management applications.
A continued, focused investment in research and development has resulted in a
unique expertise in providing high-performance, state-of-the-art solutions for today's
advanced working positions. Barco's worldwide facilities are fully equipped for
in-house design, development, testing and manufacturing. ISO 9001 certification,
complete control of the production process, extensive environmental testing
programs, worldwide customer support and project-specific customization, confirm
Barco's commitment to technologically advanced, cost-competitive solutions.
Barco's expertise in providing high performance display systems is supported by a
worldwide network of research, development and support services. A global sales
organization, with regional support people who understand your language and
requirements, complements Barco's partnership approach.
Th. Sevenslaan 106 - B-8500 Kortrijk, Belgium
Phone: +32 56 233 413 - Fax: +32 56 233 462
E-mail: sales.commandcontrol.barcoview@barco.com
Hastedter Osterdeich 222 - 28207 Bremen, Germany
Phone: +49-421-20 12 20 - Fax: +49-421-20 12 29 99
E-mail: info.orthogon@barco.com
3059 Premiere Parkway - Duluth, Georgia, 30097-4905, USA
Phone: +1 678 475 8000 - Fax: +1 678 475 8100
E-mail: sales.barcoview-a@barco.com
Ref. TRM 04-002 - Feb '04
Contact one of the above for your local sales office
Technical specifications are subject to change without prior notice
www.barco.com
BarcoView
Barco Orthogon AG
BarcoView, LLC
TM
Isona
Integrated display station
