SEC-H-600 Security Controller
This document covers the mounting and wiring of the WEBs-AX
It assumes that you are an engineer, technician, or service person who is performing
access system design or installation. Instructions apply to the following models:
Models
Description
SEC-H-600
Security Controller base unit controller, referred to in this
document as a "Security Controller."
NOTE: Another Security Controller model is available (SEC-H-201), which has the same form factor and onboard security I/O.
However, it supports fewer expansion modules. It has a separate mounting & wiring document. See "Related Documen-
tation," page 6. Separate documents also cover the mounting and wiring of Expansion Modules, and also the software
configuration required for a functioning system.

Table of Contents

SECURITY
See "Certifications," page 38.
3TBZ
3TBZ
INSTALLATION INSTRUCTIONS
®
Security Controller.
APPENDIXES
95-7759-07
