Section 3 - Configuration
QoS classes are subfilters that feed into the larger QoS Queues.
Class Name:
Indicates the name of the queue. This is for user reference only,
and does not affect functionality.
Status:
Indicates the current status of the class.
Queue:
Indicates which the queue to which the class forwards packets..
DSCP Mark:
Indicates the Differentiated Services Code Point (DSCP) mark
used in the class
VlanID Tag:
Indicates the VLAN ID of the class.
Policy Name:
Indicate the policy or algorithm used in the class.
Action:
Click the pencil ( ) icon to edit the queue, click the trash can icon
( ) to delete the queue. Select the C icon to clone the queue.
Add:
Click Add to add a new QoS class, described on QoS
Classification - Add on page <OV>.
D-Link DWR-961 User Manual
QoS Classification
96
