JVC LT-32N386A User Manual

32" class
Hide thumbs
Table of Contents

Advertisement

Quick Links

LED Display Users Guide
Class
LT-32N386A
32
SOURCE

Advertisement

Table of Contents
loading

Related Manuals for JVC LT-32N386A

Summary of Contents for JVC LT-32N386A

  • Page 1 LED Display Users Guide Class LT-32N386A SOURCE...

  • Page 2: Table Of Contents

    CONTENTS 1. Warning and Precautions ................2. Important Safety Instructions ..............3. Connection and Preparation of TV............... 3.1 Accessories ................... 3.2 Installation of Stand ................3.3 Keys and Interfaces ................3.4 Remote Control ..................3.5 Installation of Batteries ................. 4. Basic Operation ..................4.1 Power ON/OFF(Optional) ..............
  • Page 6 Place the TV on a firm and flat surface, leaving a space of at least 10cm around the set and 30cm from the top of the set to the wall or cabinet. Ensure the TV is positioned close to the wall to avoid it falling if pushed. 10cm 30cm 10cm...

  • Page 7: Connection And Preparation Of Tv

    3.Connection and Preparation of TV 3.1 Accessories User Manual Remote Control Battery(2 x AAA) 2 x Legs 4 x Leg Screws 3.2 Installation of Stand Screw Size: BM4x10 (DTV) (Smatr) (Big Head Machine Screw) Screw Qty: 4PCS Place a soft cloth on a table and place the TV face down on it. This is to prevent the panel from being damaged.

  • Page 8: Keys And Interfaces

    3.3 Keys and Interfaces ITEM BUTTON NAME FUNCTION DESCRIPTION MENU Press to bring up the main menu to the screen. CH+/- Press to scan through channels. VOL+/- Press to increase or decrease the sound level. SOURCE Press to select the input source. STANDBY Press to switch the TV on during Standby mode or vice versa.
  • Page 9 AV IN PC(VGA) PC AUDIO RF IN HDMI VIDEO ITEM BUTTON NAME FUNCTION DESCRIPTION PC(VGA) Connect to the VGA output on your Comuter. PC AUDIO Connect to the Audio output jack of your Computer. AV IN Composite input. RF IN Connect antenna here to get TV signal.

  • Page 10: Remote Control

    3.4 Remote Control STANDBY: Press to enter or exit Standby mode. SLEEP: Press to select the sleep time. MUTE: Press to mute sound. SUB.T/CC: Press to select subtitle. TV/RADIO: Press to select TV or Radio mode. AUDIO/MTS: Press to select TV audio mode. T.SHIFT: Press to activate Timeshift function in DTV mode for delayed viewing.

  • Page 11: Installation Of Batteries

    3.5 Installation of Batteries 1 Open the back lid of the remote control. 2 Install two (AAA)1.5V batteries(included). Ensure the correct polarity of the batteries. 3 Replace the back lid. Note: Please remove the batteries, if the remote control will not be in use for a long time. If the remote control doesn't work properly, please carry out the following checks: - Check if the TV is turned on.

  • Page 12: Menu Option Adjustment

    When selecting the signal source, the screen will display the information. TV mode _ _:_ _ PAL DK Mono When there is no signal from the selected source, a warning message will be displayed per below. Either change the channel i n TV mode or press source.

  • Page 13: Auto Installation

    4.5 Auto Installation If this is the first time you are turning on the TV and there are no channels in the TV memory, the “Auto Installation” menu will appear on the screen.There are 5 setup options as below: Setup 1: Set up the Country Setup 2: Set up the Language Setup 4: Set up the Auto Search Air/Cable Type Setup 3: Set up the Auto Power Off...

  • Page 14: Menu Functions

    4.6 Menu Functions 4.6.1 PICTURE Menu This chapter will describe the function of Picture in the main menu. 1.1 Picture Menu Open the main menu by pressing 'Menu' button on the remote control. The focus will move to the sub items in the Picture menu by pressing down the button “RIGHT”...

  • Page 15: Picture Function

    4.6.2 Sound Menu This chapter will describe the function of Sound in the main menu. 2.1 Sound Menu Open the main menu by pressing 'Menu' button on the remote control. Now press the button “down” on the remote. The focus will move to the sub items in the Sound menu by pressing down the button “RIGHT” and then functions in the Sound can be set.

  • Page 16: Tv Channel

    4.6.3 TV Channel 3.1 Channel User Interface Press Menu button on the remote control and press Down button two times until the Channel User Interface is highlighted. Now press Right arrow to enter the sub-options as below: There are following functions in this page: Channel Management: To manage (Delete//Swap/Lock/Skip) all channels;...
  • Page 17 3.2.1.1 Delete/Skip/Lock Channel 1) Press “UP (▲)” and “DOWN (▼)” key to select the programs to be deleted and press “RED”, “GREEN” or “YELLOW” key to mark them as below: 2) After marking press “MENU” key to save the result. 3.2.1.2 Swap Channel Select the program to be swapped and press “BLUE”...
  • Page 18 3.2.3 Country 1) Select the country. 3.2.4 Auto Search 3.2.4.1 Air signal mode Select “Auto Search” item to enter auto search user operation interface as below: All Mode: Select “All” item to scan all digital channels carried by current signal mode firstly and then switch to scan all analog channels in selected country automatically.
  • Page 19 3.2.5 Digital Manual Search 3.2.5.1 Air signal mode Select “Digital Manual Search” item to enter air channel manual search in DTV source: Select channel number by “RIGHT” key or entering number directly. The strength and the quality shows at the bottom. Press “ENTER” key on “Start” item to start current channel search. The manual searching UI and auto searching UI are the same.

  • Page 20: Feature Function Description

    Enter these parameters and then select “Search” item to enter analog channel tune. A dialog pops up on the left bottom: Press “Left（ ◄） （► )" key to search higher frequency channels. to search lower frequency channels and “Right Press “MENU” key to return to “Channel-Analogue Manual Search” page and press “RED” key to save the scanned channel to database.
  • Page 21 4.1 Lock The Lock sub page includes three parts:Lock Channel,Parental Lock,Change Pin Code as shown in the following picture. 1) Operations in Lock Menu are shown in the following table Option Value Lock Channel On: turn on Lock Channel. User need to enter password(0000) to watch the channels which locked.
  • Page 22 4.2HDMI Link It is used to control HDMI link. Range of the values of items in Clock Menu Option Value Enable HDMILink On/Off Auto PowerOn On/Off Auto Standby On/Off Speaker Preference TV Speakers/Amplfier Amplifier Support On/Off Note: Audio Return Channel (ARC) returns audio though the same HDMI channel that is used to send video to the TV.

  • Page 23: Setup Menu

    4.6.5 Setup Menu The Setup Menu is shown as follows ： The range and the default values of every sub items in Setup menu are shown in the following table: Setup Menu Items Value OSD Timer ( 5, 10, 15, 20, 25, 30 Seconds,Never) PC Setup “...

  • Page 24: Multimedia

    5.2 PC Setup It is only available in PC source. Mode-Options Value Auto Adjust “OK” H Position -16~16 V Position -16~16 Phase 0~31 Clock -30~30 Auto Adjust Auto Adjust the H Position, V Position, Phase, Clock H Position Manually adjust H Position V Position Manually adjust V Position Phase...

  • Page 25: Usb Function

    . Multimedia 4.7.2 USB Function 1. Photo 1.1 Format Supported Container Max Resolution Type PHOTO JPEG 165370 Progressive JPEG 61648 101439 101439 TIFF 1.2 Function Introduction Highlight the “PHOTO” item in multimedia mainmenu by press “RIGHT” / “LEFT” key, then press “ENTER” key enter photo page, as follow: Key Operation 1) RED:...
  • Page 26 1.2.1 Playback Press "PLAY" key to start playback. Key Operation : Same as "PLAY" key on remote, to start playing pictures in slide show mode : Same as "PAUSE" key on remote, to pause the playing file : Same as "STOP" key on remote, to stop sliding show, and return to the file browser : Same as "|<<"...

  • Page 27: Music

    2. Music 2.1 Format Supported Audio MUSIC File Exit .mp3 .wma .m4a/.aac 2.2 Function Introduction Highlight the “MUSIC” item in multimedia mainmenu by press “RIGHT” / “LEFT” key, then press “ENTER” key enter music page, as follow: Key Operation 1) RED: Delete the focused folder/file.

  • Page 28: Movie

    3.MOVIE Highlight the “MOVIE” item in multimedia mainmenu by press “RIGHT” / “LEFT” key, then press “ENTER” key enter movie page, as follow: Key Operation 1) RED: Delete the focused folder/file. GREEN: Add/Del all photo files to play list. 3) ENTER: Add/Del highlight files to play list.

  • Page 29: Ebook

    4. eBook 4.1 Format Supported Only txt format eBook is supported. 4.2 Function Introduction Highlight the “eBook” item in multimedia mainmenu by press “RIGHT” / “LEFT” key, then press “ENTER” key to enter eBook page, as follow: Key Operation 1) RED: Delete the focused folder/file.

  • Page 30: Epg/Pvr/Timeshift

    4.8 EPG/PVR/Timeshift 4.8.1 1.1 EPG abstract Press the EPG button on the remote control to open the Electronic Program Guide. The EPG shows information about the current and upcoming programs running on each channel. There are three modes - Daily mode, Weekly mode and Extended mode. 1.2 Daily Mode ...
  • Page 31 1.3 Weekly Mode:  Display the information of the programs that start in a scheduled period of time in the current channel. It includes name, start time, end time, short content description, current date/time, etc.  Focusing on different channels on the left, it displays corresponding programs in schedule of time. ...
  • Page 32 1.4 Extended Mode: EPG Extended Mode Key Stroke Action KEY_UP If the information takes more than one page, the current page rolls up a row. KEY_DOWN If the information takes more than one page, the current page rolls down a row. If it entered Extended Mode from daily mode, back to daily mode.
  • Page 33 4.8.2 The PVR (Personal Video Recorder) function allows you to record programs on to a USB memory device. Press the RECORD button on the remote control to activate the PVR function. Note: A USB memory device must be connected in order to record programs. 2.1 PVR involved Menus 1.
  • Page 34 Function list explain： Items Enter Partition Select menu； Partition Select Display partition’ s infomation； Format partition function； Set default partition function； Auto Timeshift：off (Stop auto Timeshift) 、Auto (Start auto Timeshift)； Auto Timeshift Set Timeshift Buffer：auto、30Mins、1hr、2hr； Timeshift Buffer Enter Timer menu； Timer Preengaged programs’...
  • Page 35 2.1.2 Partition List menu Information：Partition List menu manages the partitions connected to system. (Partition List menu) Function： Partitions：The list in the menu shows the partitions connected to system； Partitions’ property：Total size and Free size； Format Partition：Press KEY_RED to format the focus partition. Before format, there is a prompted popup window to confirm；If format successfully there is a message “Format Success!”, otherwise, there is a “Format Fail!”；...
  • Page 36 2.1.3 Timer menu Information： Timer menu manages the programs scheduled for recording. You can add or delete programs from this menu. (Timer menu) Prompted information explain： CH NO. :Channel number； Channel :Channel name； Start : Start recording time； Duration :The total recording time； Date : The date of starting recording；...
  • Page 37 2.1.4 Timer Edit menu You can edit the programs scheduled for recoding from the Timer Edit menu. (Timer Edit menu) Function explain： Recorder : (Off / On). "Off" sets a reminder for a particular program for watching; it does not record the program.
  • Page 38 Key Stroke in menu： Key Stroke Action KEY_UP Focus on the previous option on the Edit list. KEY_DOWN Focus on the next option on the Edit list. Edit Start Time、Duration、Date. KEY_0~9 KEY_ENTER Confirm the choice.(For popList options) KEY_MENU Return to the previous menu (Timer menu) and save the setting. KEY_ Exit Exit all menus.
  • Page 39 2.1.6 REC info menu REC input info menu: This indicates that recording is in progress. It is displayed continuously until recording is stopped (except when some other menu is selected). REC info banner menu: This displays information about the current recording. Enter method：After REC start, press KEY_DISPLAY to show the REC info banner menu.
  • Page 40 Progress bar is for current recording length compared with the disk free space when REC start. The black triangular icon is for current play length compared with current recording length. MB Free is the disk instantaneous free space. The right red time menu has the same function with the time in info banner menu(only when info banner menu closed it showed).
  • Page 41 The save direction for the output files: the inserted storage device (USB/Card). If user wants to change the output direction, he can open the partition list by pressing the button “Device” and make the choice. It supports 4 partitions at most; The rules of naming the output files: Program name + (REC date_time(h/m/s),eg ：...
  • Page 42 If the signal is not stable there may be some pause; The recording progress will stop when the device has no more free spaces if there is no setting about when to end before. A warning message pops up, the recording process stops and it will keep on the normal playback process.
  • Page 43 (Press KEY_GREEN twice for recorder) In Timer menu, user can increase、delete preengage programs; In Timer Edit menu, user could set、modify preengaged programs’ information; In Timer menu: press KEY_YELLOW to get into Timer Edit menu to add a timer .Then set timer’s information in Timer Edit menu.
  • Page 44 （Timer Record start prompt window ） If there are not any storage media, the settings fail and a warning message “no USB device” shows; If target partition (default partition) is not set, it selects the first partition that the system identified automatically.
  • Page 45 （Timeshift Play Info menu and stop prompt） A UI (Timeshift time menu) on the right top corner shows the fallen time between the current picture and the living broadcasting picture; During the recoding progress, if the signal is missing, the recording process will take a pause until the signal is stable again.

  • Page 46: Technical Specification

    5.Technical Specification 32 inch ( 81cm ) 1366 X 768 200±10% 3000 English 1 x USB ports 730x189x472mm(L x D x H) Net Weight: 4.3 kg...

  • Page 47: Supported Signal Modes

    6. Supported Signal Modes A.VGA Mode Resolution Horizontal Frequency (Khz) Vertical Frequency (Hz) Memo 640 x 480 31.50 60.00 35.16 56.25 800 x 600 37.90 60.00 48.40 60.00 1024 x 768 1366x 768 47.85 60.00 Note:Use VGA connecting cord of less than 5 meters to ensure the appropriate picture quality.

  • Page 48: Troubleshooting

    Simple Troubleshooting If your TV has a main power switch (O/I switch), make sure it is set to ON - refer to the Overview diagram for position. Note: The main power switch, if available, is separate from the standby button. Make sure the standby button is also turned on.
  • Page 49 RWXM00-E139...
