DVP20CC70-1
DVP30CC70-1
This conversion kit is to be installed by an Empire Comfort Systems, Inc. distribu tor (or other
qualified agency
)* in accordance with the manufac turer's instruc tions and all codes and re-
1
quirements of the authority having jurisdiction. Failure to follow instructions could result in
serious injury or property damage. The qualified agency performing this work assumes re-
sponsibility for this conversion.
National Fuel Gas Code Z223.1 (Latest Edition), Natural Gas and Propane Installation Code,
1
CSA b149.1
*The term "qualified agency" means any individual, firm, corporation or company which either
in person or through a representative is engaged in and is responsi ble for (a) the installation
of gas piping or (b) the connection, installation repair, or servicing of equipment, who is ex-
perienced in such work, familiar with all precau tions required, and has complied with all the
requirements of the authority having jurisdic tion.
CHECK SAFETY SHUTDOWN PERFORMANCE
Perform the safety shutdown test anytime work is done on a gas system to avoid the possibility
of fire or explosion with property damage, personal injury or loss of life.
SAFETY SHUTDOWN SYSTEM
Continuous Ignition Systems (Standing Pilot)
1. Place gas control knob in PIlOT position. Main burner should go off and pilot should remain lit.
2. Extinguish pilot flame. Pilot gas flow should stop within 30 seconds. Safety shutoff of pilot gas proves complete shutdown
since safety shutoff valve blocks flow of gas to main burner and pilot.
3. Relight pilot burner and operate system through one complete cycle to make sure all controls operate properly.
31064-2-0919
GAS CONVERSION INSTRUCTIONS
DIRECT VENT STOVES
FOR USE ON DIRECT VENT STOVE MODELS:
DVP20CC70-1, DVP30CC70-1
CONVERSION KITS
MODEL
FOR CONVERSION TO PROPANE GAS
Empire Comfort Systems Inc. • Belleville, IL
WARNING
WARNING
PART NUMbER
31054
31060
Page 1
Advertisement
Related Manuals for Empire Comfort Systems DVP20CC70-1
Summary of Contents for Empire Comfort Systems DVP20CC70-1
- Page 1 31060 FOR CONVERSION TO PROPANE GAS WARNING This conversion kit is to be installed by an Empire Comfort Systems, Inc. distribu tor (or other qualified agency )* in accordance with the manufac turer’s instruc tions and all codes and re- quirements of the authority having jurisdiction.
