WIRING DIAGRAM
Wiring is to be done as shown in the electrical wiring diagram (Do not change the internal wiring)
Use copper conduction only.
How to tighten screw on terminal block.
1. Bare the ends of electric wire.
2. After retaining the wire, check that all the terminal screws are firmly tightened.
FDT21-FDT25
