INDOOR UNIT INSTALLATION
6.1 SELECTION OF INSTALLATION
LOCATION.
A place where water is easily drained out.
A place that can handle the weight of the indoor unit.
A place which has easy access for maintenance.
MODEL
42FDT21
42FDT25
Remark: Supply & Return air dimension are F x G.
A
B
C
1790
870
810
1990
870
810
6.2 CAUTIONS FOR INSTALLATION WHERE
AIR CONDITIONER TROUBLE IS
LIABLE TO OCCUR.
Where it is acid base area.
Where there is irregular electrical supply.
J
G
G
I
A
D
DIMENSION (mm.)
D
E
F
1650
440
365
1850
440
365
13
INSTALLATION INSTRUCTIONS
G
H
I
1550
610
1790
1750
610
1990
C
J
1230
1700
