Editing EQ Parameters (EQ)

Equalizer (also called "EQ") is a sound processor that divides the frequency spectrum into multiple bands that can be
boosted or cut as required to tailor the overall frequency response. The "Panel"–"Song" Part Selection tabs at the top
of the Mixer display let you adjust the EQ for each corresponding part, while "Master" lets you make overall EQ
adjustments for the entire instrument.
Part EQ (when one of the "Panel"–"Song" tabs is selected)
High
Low
Master EQ (When the "Master" tab is Selected)
This instrument possesses a high-quality eight-band digital EQ. With this function, a final effect—tone control—can
be applied to the output of your instrument. You can select one of the five preset EQ types in the "Master" display. You
can even create your own custom EQ settings by adjusting the frequency bands, and save the settings to one of 30 User
Master EQ types.
NOTE
Master EQ cannot be applied to an Audio Song, the audio input via the AUX IN jack, or the metronome sound.
8 bands (default) → 80Hz
Boosts or cuts the high EQ band for each part.
Boosts or cuts the low EQ band for each part.
Gain Bandwidth (also called "Shape" or "Q")
0
250Hz 500Hz 630Hz 800Hz 1.0kHz 4.0kHz 8.0kHz
Frequency
