Burnside T355 Quick Start Manual

Burnside Telecom Limited
Opus House, Herriard, Basingstoke,
Hampshire, RG25 2PH, United Kingdom
Ring back test
The ring back test can confirm the link with the connected phone as well as the Caller ID
feature (if supported) and the current ring style. If possible you should also test by making
calls to, and receiving calls from another phone.
1 Lift the handset and dial 9#
*
2 Replace the handset. The attached phone should ring (for 30 seconds).
If the phone supports Caller ID, the display should show the number '01234567890'
and the message 'Test Call'.

Making calls

1 Lift the handset and listen for a dial tone.
If you hear a series of short tones, the T355 terminal is either waiting for a PIN code
(see 'Enter a PIN code' overleaf) or no SIM card is installed.
2 Dial the required number and then press the # key to place the call.
If you do not dial #, the call will be placed automatically three seconds after the last
button is pressed. You can adjust the delay period (see 'Dial delay' within the full user
guide for details).
Receiving calls
• When the phone rings, lift the handset and take the call in the normal way.
If the caller's number is made available by the network, and the attached phone sup-
ports Caller ID, it will be shown on the display of the phone.
Status Indicators
The amber and centre green indicators provide status
information by flashing on and off in various ways. Each
GREEN
GREEN complete circle below represents 2 seconds and the shaded
AMBER
portions show the period that each indicator is on.
( POWER
STATUS )
AMBER GREEN
Initialising/searching
Standby - ready for use
Waiting for PIN code
Tel: +44 (0)3333 441200
Email: info@burnsidetelecom.com
Web: www.burnsidetelecom.com
AMBER GREEN
Weak signal
Battery low, please wait
Fault
BURNSIDE
landline alternatives
This quick start guide will help you to set up, switch on and begin using your T355 fixed
cellular terminal unit. For further information on all features, please refer to the full user
guide available within the 'Service & Support' section at:
Setting up
Remove the cover
Place the terminal on a level sur-
face. Grip the ridges on either side
of the light-grey top cover and lift it
gently from the base unit. This will
reveal the SIM card holder and the
battery.
Install your SIM card
Note: Ensure the unit is switched off (see inside pages) before installing a SIM card.
1 2
(a) Slide back the
hinged lid to unlock it,
then (b) swing it open.
(b) Swing
a shut the
hinged lid
ensuring that the
SIM card remains
fully in place.
T355 fixed cellular terminal
quick start guide
www.burnsidetelecom.com
3
(a) Insert the SIM card
Press down
into the hinged lid
upon the hinged
as shown. lid and slide it
across so that it
locks into
place.
