Core Health & Fitness
Star Trac
8-RB
ASSEMBLY
MANUAL

Advertisement

loading

Related Manuals for Star Trac 8-RB

Summary of Contents for Star Trac 8-RB

  • Page 1 Core Health & Fitness Star Trac 8-RB ASSEMBLY MANUAL...

  • Page 2: Product Spotlight

    PRODUCT SPOTLIGHT 9-8130 8-RB Upright Bike Overall Weight Width Length Height Max User Weight 178 lbs (81 kg) 28 in (71 cm) 66 in (168 cm) 52 in (132 cm) 0-350 lbs (0-159 kg) All products may be covered by US and Foreign Patents and Patents Pending.
  • Page 3 Description 718-5796-XX BEAUTY RING, UPRIGHT BIKE, 8-SERIES 720-5203-XX ASSY, HANDLEBAR, NO DISPL, E-RB 730-0889 SCREW,M8X1.25,20mm,SHCS,HK,SS,A-2,FT 718-5693 WASHER, M8, COUNTERBORE, COSMETIC 720-5054 ASSY, CONTACT HR, GRIP CABLE, RB PRO 720-5206 ASSY, CABLE, RB, HR EXT 120-3257 WASHER, M6, TEETH, 0.6 THICK SCREW,M6x1.0,25mm,SHC,H- 110-3916 K,AS,Grd-12.9,NKL,FT...
  • Page 4 Thread the cable bundle through the beauty ring (718-5796-XX) and up through the mast (720- 5203-XX). NOTE: Ensure that the curved portion of the beauty ring is facing in and down towards the shrouds. Use a 6mm allen key to secure the mast assembly to the frame using four (4) pieces each of the M8 x 20mm socket head cap screw (730-0889) and M8 cosmetic counter-bore washer (718-5693).
  • Page 5 Use a 5mm allen key to secure the reading rack assembly to the mast using four (4) pieces each of the M6 x 25mm socket head cap screw (110- 3916) and M6 tooth washer (120-3257). Set the seat assembly (720-5233-XX) onto the seat trolley assembly.
  • Page 6 Use a #2 phillips screwdriver to secure the back console shroud to the console weldment using eight (8) pieces of the #8-18 x 3/4” screw (110- 3402) and M4 washer (120-3307). Refer to the documentation contained inside the console box in order to connect the console to the unit.

  • Page 7: Support And Service

    SUPPORT AND SERVICE The Support website provides a wealth of resources to help you get the best experience from your unit. It is important to check the website periodically for Owner’s Manual and Installation Instruc- tions, Service Bulletins, and other information. The resources include: •...
  • Page 8 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8383, REV C...
