- Page 1 Installation and operation manual Split system air conditioners Installation and operation manual FDA200AXVEB English Split system air conditioners FDA250AXVEB...
- Page 2 3P471028-17K...
-
Page 3: Table Of Contents
Symptoms that are NOT system malfunctions ......15 Daikin website (publicly accessible). 14.1.1 Symptom: The system does not operate ....15 ▪ The full set of latest technical data is available on the Daikin 14.1.2 Symptom: White mist comes out of a unit (Indoor extranet (authentication required). -
Page 4: For The Installer
2 About the box For the installer About the box Following special symbols may appear on the indoor unit packing case. For general symbols, refer to the General safety precaution. Symbol Meaning Be careful when handling the unit. Indoor unit contains rotating parts. -
Page 5: Installation
5 Installation a ≥650 1100 1028 4× d ≥1143 (mm) Nut (field supply) Double nut (field supply) Washer (accessories) Hanger bracket (attached to the unit) Service space (mm) Inspection hatch (600×600 mm) ▪ Installation example: Top view Side view Service space Ceiling Floor surface Minimum required space of installation... -
Page 6: Guidelines When Installing The Ducting
5 Installation ▪ Connecting the drain piping to the indoor unit ▪ Checking for water leaks General guidelines ▪ Pipe length. Keep drain piping as short as possible. ▪ Pipe size. Keep the pipe size equal to or greater than that of the connecting pipe (vinyl pipe of 25 ... -
Page 7: Connecting The Refrigerant Piping
5 Installation Sealing (on the attached piping) 5 Insulate the duct to prevent condensation from forming. Use Indoor unit glass wool or polyethylene foam 25 mm thick. NOTICE ▪ Join the attached piping (accessory) and the field refrigerant piping (field supply) by brazing before fixing the attached piping to the unit. -
Page 8: Specifications Of Standard Wiring Components
5 Installation 5.3.1 Specifications of standard wiring components Component FDA200 FDA250 Power supply 4 A 4.3 A cable Voltage 220~240 V Phase Interconnection cable Frequency 50/60 Hz Power supply cable Circuit breaker Wire sizes Must comply with applicable Earth leakage circuit breaker legislation Power supply Earth Interconnection cable 4-core cable 1.5 mm... -
Page 9: Commissioning
6 Commissioning WARNING To perform a test run Provide adequate measures to prevent that the unit can be INFORMATION used as a shelter by small animals. Small animals that make contact with electrical parts can cause malfunctions, For the test run procedure, see the reference guide or the smoke or fire. -
Page 10: Disposal
▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). Harness H*P, LED*, V*L Pilot lamp, light emitting diode ▪ The full set of latest technical data is available on the Daikin extranet (authentication required). Light emitting diode (service monitor green) HIGH VOLTAGE... -
Page 11: For The User
Improper installation or attachment of equipment or accessories could result in electric shock, short-circuit, leaks, fire or other damage to the equipment. Only use accessories, optional equipment and spare parts made or approved by Daikin. FDA200+250AXVEB Installation and operation manual Split system air conditioners... -
Page 12: Components
11 User interface 10.1 Components Operation INFORMATION 12.1 Operation range The following illustration is an example and might NOT match your system layout. For combination with R410A outdoor unit, refer to the following table: Outdoor units Cooling Heating RZQ200+250 Outdoor –5~46°C DB –15~15°C WB temperature... -
Page 13: Cleaning The Air Filter And Air Outlet
13 Maintenance and service 2 Slowly pull out the air filter (composed of 3 equal parts). DANGER: RISK OF ELECTROCUTION To clean the air conditioner or air filter, be sure to stop operation and turn all power supplies off. Otherwise, an electric shock and injury may result. -
Page 14: About The Refrigerant
14 Troubleshooting ▪ Check if there is somewhere a broken wire. Contact your dealer in The system MUST be repaired by a qualified service person. case of problems. Malfunction Measure ▪ Clean the air filter and the casing of the indoor unit (see If a safety device such as a fuse, a Turn OFF all main power "13.2 Cleaning the air filter and air outlet" on... -
Page 15: Symptoms That Are Not System Malfunctions
14 Troubleshooting necessary to clean the interior of the indoor unit. Ask your dealer Malfunction Measure for details on cleaning the unit. This operation requires a qualified Operation stops ▪ Check if the air filter is clogged (see service person. suddenly. - Page 16 15 Disposal Disposal NOTICE Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. Installation and operation manual FDA200+250AXVEB Split system air conditioners...
- Page 20 3P580564-1 2019.04...
