Daikin FDY125B7V1 Installation Manual
Split system air conditioners
Hide thumbs
Also See for FDY125B7V1:
- Operation manual (10 pages) ,
- Installation manual (10 pages) ,
- Operation manual (10 pages)
Related Manuals for Daikin FDY125B7V1
Summary of Contents for Daikin FDY125B7V1
- Page 1 INSTALLATION MANUAL Split System air conditioners Installation manual English Split System air conditioners FDY125B7V1 FDY200B7V1 FDY250B7V1 FDYP125B7V1 FDYP200B7V1 FDYP250B7V1...
- Page 2 File Tecnico di Costruzione DAIKIN.TCF.004 / DAIKIN.TCF.016 e giudicato positivamente da KEMA secondo il Certificato 59277-KRQ/ECM95-4233 / 81728-KRQ/ECM98-4341. fi ˆ˜ ÚÔÛ‰ÈÔÚ›˙ÂÙ·È ÛÙÔ ∞Ú¯Â›Ô ∆¯ÓÈ΋˜ ∫ ·Ù·Û΢‹˜ DAIKIN.TCF.004 / DAIKIN.TCF.016 Î·È ÎÚ›ÓÂÙ·È ıÂÙÈο · fi ÙÔ KEMA Û‡Ìʈӷ Ì ÙÔ ¶ÈÛÙÔ ÔÈËÙÈÎfi 59277-KRQ/ECM95-4233 / 81728-KRQ/ECM98-4341.
- Page 3 FDY(P)125: > 350 FDY(P)200, 250: > 450 > 300 1440 1400 602 (FDY(P)125) 840 (FDY(P)200 - FDY(P)250) X33A X33A X27A X27A X10A X10A 1 2 3 C L M H 1 2 3 P1 P2 C L M H 1 2 3 P1 P2 X1 X2 X3 X4 1 2 3...
- Page 4 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 L N P 1 2 3 L N P 1 2 3 L N P 1 2 3 L N P C L M C L M H 1 2 3 P1 P2 4PW05089-1A...
-
Page 5: Selecting Installation Site
DAMAGE TO THE EQUIPMENT. BE SURE ONLY TO USE ACCESSORIES MADE BY sulfide gas, a place where chemicals are used nearby, a place DAIKIN WHICH ARE SPECIFICALLY DESIGNED FOR USE WITH THE EQUIPMENT with high voltage fluctuations, a place with volatile flammable AND HAVE THEM INSTALLED BY A PROFESSIONAL. -
Page 6: Indoor Unit Installation
NSTALLATION EXAMPLE A liquid line and gas line must be provided between the condensing and the air conditioning unit. • The outdoor unit is charged with refrigerant. • Use a pipe cutter and flare suitable for the used refrigerant. • The liquid line must be connected to the air conditioning unit via a flare connection. -
Page 7: Drain Check
ETHODS OF WIRING UNITS AND CONNECTING REMOTE . 5) CONTROLLER CORDS EFER TO FIG • Wiring the units (Power supply wiring). • Connect the interconnection wiring (from outdoor to indoor) to the 1-2-3 terminal (1) using a separate power supply wire to •... -
Page 8: Main/Sub Changeover
ONTROL BY EMOTE ONTROLLERS Note ONTROLLING INDOOR UNIT BY REMOTE CONTROLLERS 1. All transmission wiring except for the remote controller wires When using 2 remote controllers, one must be set to "MAIN" and must match the terminal symbol. the other to "SUB". 2. -
Page 9: Internal Wiring
NTERNAL WIRING PARTS TABLE Refer to the wiring diagram on the unit. The abbreviations used are listed below. Note When using the central remote controller, see manual for connection to the unit. Ground the shield of the remote controller cord to the indoor unit. - Page 10 4PW10621-1 Zandvoordestraat 300, B-8400 Oostende, Belgium...
