Homelite UT80522G Quick Reference Manual

WARNING:
This Quick Reference Guide is not a substitute for reading the operator's manual. To reduce the risk of injury or death, user must read and understand operator's manual before using this product. All page references refer to
the operator's manual.
FIRST TIME ASSEMBLY
Connect the high pressure hose to the pump
1 Attach the wheel assembly (see page 8). 6
(see page 8).
Completely uncoil and straighten high pressure
2 Install the handle (see page 8).
hose to prevent kinks.
7 Connect your garden hose to the pressure washer
(see page 9).
Install the upper and lower spray wand holder
3
(see page 8).
Completely uncoil garden hose or remove
completely from reel to prevent kinks.
Turn water faucet on fully.
Make sure there are no leaks.
With no nozzle installed, squeeze the trigger
to relieve air pressure. Hold the trigger until a
steady stream of water appears.
Add entire bottle of lubricant provided to the pres-
8
sure washer (see page 10).
4
Connect the spray wand to the trigger handle
(see page 8).
Connect the high pressure hose to the trigger handle
5
(see page 8).
Turn the fuel valve to OFF before adding
lubricant.
Set unit on flat surface so engine is level.
Remove dipstick, wipe clean, put back in hole
(but don't screw in) and check lubricant level.
DO NOT OVERTILT THE UNIT!
UT80522G QUICK REFERENCE GUIDE
STARTING THE UNIT (COLD START)
1
Add fuel (see page 10). 5 Pull starter grip and rope to start (see page 11).
NOTICE:
Do not use E15 or E85 fuel in this prod-
uct. It is a violation of federal law and will
damage the unit and void your warranty.
Only use unleaded gasoline containing
up to 10% ethanol.
If the engine does not start after each pull of
the starter grip and rope, squeeze the trigger to
relieve water pressure before attempting to start
the engine again.
Allow engine to run for several seconds, then
6
move choke to OFF (RUN) position (see page 11).
This is a 4-cycle engine. Do not mix fuel and
lubricant together.
Mix fuel stabilizer with gasoline according to
fuel stabilizer manufacturer's directions.
2
Turn the fuel valve to ON (see page 11).
CHOKE LEVER OFF (RUN)
RESTARTING THE UNIT
(HOT RESTART)
1
FUEL VALVE ON Pull recoil starter to start (see page 11).
Put choke lever in ON (START) position
3
(see page 11).
CHOKE LEVER ON (START)
4 Put engine switch in ON position (see page 11).
ENGINE
SWITCH
ON
If the engine does not start:
• check for enough fuel;
• may need to adjust choke position;
• try starting again.
USING DETERGENT
Put soap injection hose in
1
cleaning solution (see page
13).
Use of soap nozzle will activate soap injector at a 20:1
dilution ratio.
WARNING! Never use bleach or solvent-based detergent.
• Will damage your pump
• Will void your warranty
• Will damage plants/shrubs
5 S
NOZZLE SELECTION GUIDE
Use the chart below to determine the correct nozzle for your job.
ABRASIVE
Concrete, Brick, Masonry
Siding, Gutters, House
Fencing, Deck, Patio
Lawn Equipment, Boat, RV
BEFORE STORING THE UNIT
Always add Pump Protector to the unit after each use and before storing. This will significantly im-
1
prove pump life.
Pump Protector is available from your local retailer. For further assistance, call customer service at
1-800-242-4672.
To add, follow the instructions provided by the Pump Protector manufacturer.
Make the most of your purchase!
Go to www.homelite.com and register your new tool
online. For questions about operating or maintaining
your product, please call 1-800-242-4672.
Install blue soap nozzle (see Squeeze trigger and wait
2 3
page 12). approx. 5 seconds for
detergent (see page 13).
5 S
If soap injection hose
comes loose from
pressure washer,
reattach it here.
LOW
HIGH PRESSURE
PRESSURE
(NO SOAP WHEN USING THESE NOZZLES)
(FOR SOAP OR
GENTLE RINSE)
Blue Soap
0º Red 25º Green 40º White
Nozzle
GENTLE
   
  
  
  
 Recommended Nozzle Use With Caution for Certain Applications

991000379
1-13-15 (REV:01)
PUMP
PROTECTOR
