2-048-589-11(2)
Micro Hi-Fi
Component
System
Operating Instructions
Owner's Record
The model and serial numbers are located on the rear of the unit. Record the serial number
in the space provided below. Refer to them whenever you call upon your Sony dealer
regarding this product.
Model No. ______________
Serial No. ______________
CMT-CPX11
©2004 Sony Corporation
Advertisement
Table of Contents
Related Manuals for Sony CMT-CPX11
Summary of Contents for Sony CMT-CPX11
-
Page 1: Operating Instructions
Owner’s Record The model and serial numbers are located on the rear of the unit. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. ______________ Serial No. - Page 2 The use of optical instruments with this product will increase eye hazard. Except for European model ® is a U.S. NERGY registered mark. As an E NERGY ® partner, Sony Corporation has determined that this product ® meets the E NERGY guidelines for energy efficiency.
-
Page 3: Table Of Contents
Table of Contents How to use this manual... 4 Playable discs... 4 Getting Started Hooking up the system... 6 Setting the clock... 7 CD/MP3 – Play Loading a disc ... 8 Playing a disc ... 8 — Normal Play/Shuffle Play Playing repeatedly... -
Page 4: How To Use This Manual
How to use this manual This manual mainly explains operations using the remote, but the same operations can also be performed using the buttons on the system having the same or similar names. Playable discs You can play back the following discs on this system. - Page 5 Notes on CD-R and CD-RW • Some CD-Rs or CD-RWs cannot be played on this system depending upon the recording quality or physical condition of the disc, or the characteristics of the recording device. Furthermore, the disc will not play if it has not been correctly finalized.
-
Page 6: Getting Started
Getting Started Hooking up the system Perform the following procedures 1 to 3 to hook up your system using the supplied cords and accessories. Right speaker 1 Connect the speakers. Connect the right and left speaker cords to the SPEAKER terminals as shown below. AM loop antenna FM lead antenna 2 Connect the FM and AM antennas. -
Page 7: Setting The Clock
Note To prevent noise pickup, keep the antennas away from the system and other components. 3 Connect the mains lead to mains. If the plug does not fit the wall socket, detach the supplied plug adaptor (only for models equipped with an adaptor). To turn on the system, press ?/1. -
Page 8: Cd/Mp3 - Play
CD/MP3 – Play Loading a disc Press CD (or FUNCTION repeatedly) to switch the function to CD. Insert a disc in the disc slot with the label side up. When you play a disc, insert it with the label side up. Notes •... -
Page 9: Other Operations
Other operations Do this Press x (or CD x on the unit). Stop play Pause Press X (or CD NX on the unit). Press again to resume play. Press ./> repeatedly. Select a track Select an album Press ALBUM +/– repeatedly of MP3 after step 2. -
Page 10: Creating Your Own Program
Creating your own program — Program Play You can make a program of up to 25 steps. You can synchro record the programmed tracks onto a cassette tape (page 15). Press CD (or FUNCTION repeatedly) to switch the function to CD. Press PLAY MODE in stop mode repeatedly until “PROGRAM”... -
Page 11: Tuner
Tuner Presetting radio stations You can preset up to 20 FM stations and 10 AM stations. You can then tune in any of those stations simply by selecting the corresponding preset number. Automatic tuning preset You can automatically tune in all of the stations that can be received in your area and then store the radio frequency of the desired stations. -
Page 12: Listening To The Radio
To change the AM tuning interval (except for European models) The AM tuning interval is factory-preset to 9 kHz (or 10 kHz for some areas). To change the AM tuning interval, tune in any AM station first, then turn off the system. While holding TUNING +, press ?/1 on the unit. -
Page 13: Using The Radio Data System (Rds)
Using the Radio Data System (RDS) (European model only) What is the Radio Data System? Radio Data System (RDS) is a broadcasting service that allows radio stations to send additional information along with the regular program signal. RDS is available only on FM stations.* Note RDS may not work properly if the station you are tuned... -
Page 14: Tape - Play
Tape – Play Loading a tape Press TAPE Z on the unit. Load a tape into the cassette holder. With the side you want to play/record facing towards you. Playing a tape You can use TYPE I (normal) tape. Press TAPE (or FUNCTION repeatedly) to switch the function to TAPE. -
Page 15: Tape - Recording
Tape – Recording Recording your favorite CD tracks on a tape — CD-Tape Synchro Recording You can record a whole CD on a tape. You can use TYPE I (normal) tape. Use buttons on the unit for the operation. Load a recordable tape. Load a CD you want to record. -
Page 16: Recording On A Tape Manually
Recording on a tape manually — Manual Recording You can record just the portions you like from a CD on a tape. You can also record a radio program. Use buttons on the unit for the operation. Load a recordable tape. Press FUNCTION repeatedly to select the desired source to record. -
Page 17: Timer
Timer Falling asleep to music — Sleep Timer You can set the system to turn off after a certain time, so that you can fall asleep to music. Use buttons on the remote for the operation. Press SLEEP. Each time you press the button, the minute display (the turn-off time) changes cyclically as follows: AUTO* t 90MIN t 80MIN t …... -
Page 18: Timer Recording Radio Programs
Other operations Do this Check the settings Press CLOCK/TIMER SELECT. Press ./> repeatedly until “PLAY SEL” appears, then press ENTER. Change the setting Start over from step 1. Cancel the timer Press CLOCK/TIMER SELECT. Press ./> repeatedly until “TIMER OFF” appears, then press ENTER. -
Page 19: Other Operations
Other operations Do this Check the settings Press CLOCK/TIMER SELECT. Press ./> repeatedly until “REC SEL” appears, then press ENTER. Change the setting Start over from step 1. Cancel the timer Press CLOCK/TIMER SELECT. Press ./> repeatedly until “TIMER OFF” appears, then press ENTER. -
Page 20: Display
Display Turning off the display — Power Saving Mode The clock display can be turned off to minimize the amount of power consumed during standby (Power Saving Mode). Press DISPLAY repeatedly while the system is off until the clock display disappears. - Page 21 Note When fast forward or fast reverse is performed, elapsed playing time and remaining time of the track may not be displayed accurately.
-
Page 22: Optional Components
Optional Components Hooking up optional components To enhance your system, you can connect optional components. Refer to the operating instructions provided with each component. A MD/VIDEO IN jacks Use audio cords (not supplied) to connect an optional analog component (MD deck or VCR, etc.) to these jacks. -
Page 23: Listening To Audio From A Connected Component
Listening to audio from a connected component Connect audio cords. See “Hooking up optional components” on page 22. Press FUNCTION repeatedly until “MD” or “VIDEO” appears. Start playing the connected component. If you cannot select “VIDEO” by pressing FUNCTION repeatedly, turn off the system and then press ?/1 while holding down FUNCTION on the unit. -
Page 24: Troubleshooting
• Locate the system away from the fluorescent light. Speakers Sound comes from only one channel, or the left and right volumes are unbalanced. • Check the speaker connections and placement. CD/MP3 player “LOCKED” appears. • Contact your Sony dealer or local authorized Sony service facility. continued... -
Page 25: Tape Deck
• Keep the antennas away from the system and other components. • Consult your nearest Sony dealer if the supplied AM antenna has come off the plastic stand. • Try turning off surrounding electrical equipment. • Set “CD POWER” and “OFF” by the CD power manage function (page 12). -
Page 26: Messages
The tape does not record. • No cassette is loaded. Load a cassette. • The tab has been removed from the cassette. Cover the broken tab with adhesive tape (page 29). • The tape has wound to the end. Optional components There is no sound. - Page 27 Other INVALID You pressed on invalid button.
-
Page 28: Additional Information
• When you move the system, take out any disc. If you have any questions or problems concerning your system, please consult your nearest Sony dealer. Notes on discs • Before playing, clean the disc with a cleaning cloth. - Page 29 Notes on CD-R and CD-RW • This system can play CD-R/CD-RW discs edited by the user. However, note that playback of some discs may not be possible depending on the recording device used for recording or the disc condition. • CD-R and CD-RW discs that have not been finalized (processing to allow play by a normal CD player) cannot be played.
-
Page 30: Specifications
CD: 2 Hz – 20 kHz 780 – 790 nm 4-track 2-channel stereo 50 – 13,000 Hz (±3 dB), using Sony TYPE I cassettes ±0.15% W. Peak (IEC) 0.1% W. RMS (NAB) ±0.2% W. Peak (DIN) 87.5 – 108.0 MHz (100 kHz step) 87.5 –... - Page 31 General Power requirements North American model: 120 V AC, 60 Hz European model: 230 V AC, 50/60 Hz Korean model: 220 V AC, 60 Hz Australian model: 230 – 240 V AC, 50/60 Hz Other models: 220 – 240 V AC, 50/60 Hz Power consumption North American model: 50 W...
-
Page 32: List Of Button Locations And Reference Pages
List of button locations and reference pages How to use this page Use this page to find the location of buttons and other parts of the system that are mentioned in the text. Main unit ALPHABETICAL ORDER A – O BASS +/–... -
Page 33: Remote Control
Remote control ALPHABETICAL ORDER A – O ALBUM +/– qa (9, 10, 15) CD qh (8, 10) CLEAR qd (10) CLOCK/TIMER SELECT 2 (18, 19, 24) CLOCK/TIMER SET 3 (7, 17, DISPLAY ql (13, 20) ENTER 9 (7, 10, 11, 17, 18, 19) EQ qs (16) FM MODE 4 (12, 25) FUNCTION 6 (8, 10, 12, 14, 16,... - Page 36 Sony Corporation Printed in Hungary...
