When "Wide Mode" in the INPUT SETTING menu is set to "Full 2"
PS 40 60
a' N
1270 1910
1
(50) (75 /
4
M 1430
2160
3 1
(56 / ) (85 /
8 8
x
b
a'(N) = {(PS × 31.147) × 1.03} – 32.0 + 16.4
a'(M) = {(PS × 37.367) × 0.97} – 32.0 + 16.4
x = b + {PS × 4.481 + (a'+ 32.0 – 16.4) × 0.07344 – 2.3 + 72.5}
Notes
• The projected image size is the one when "Wide Mode" in the INPUT SETTING menu is set to
"Full 2". When "Wide Mode" in the INPUT SETTING menu is set to other than "Full 2", black
bands may appear at the top and bottom or right and left of the screen.
• When "Wide Mode" in the INPUT SETTING menu is set to "4:3", the projected image size
(diagonal) will be approximately 88 % of "Full 2" size.
• When "Wide Mode" in the INPUT SETTING menu is set to "16:9", the projected image size
(diagonal) will be approximately 97 % of "Full 2" size.
The alphabetical letters in the charts and calculation methods indicate the following.
PS: projected image size measured diagonally (inches)
a': distance between the hole (front) for mounting a projector suspension support on bottom
surface of this projector and the center of the screen
b: distance between the projector suspension support mounting surface on bottom of this
projector and the ceiling
x: distance between the center of the screen and the ceiling
N: minimum
M: maximum
80 100 120
2550 3190 3830
1 5
) (100 / ) (125 / ) (150
2 8
2880 3610 4330
1 1
) (113 / ) (142 / ) (170
2 4
Based on the calculation formula given below.
150 180
4800 5760
7 7
/ ) (189) (226 / )
8 8
5420 6510
1 3
/ ) (213) (256 / )
2 8
Free
Unit: mm (inches)
200 250 300
6400 8000 9610
1
(252) (315) (378 /
7230 9050 10860
3 3 5
(284 / ) (356 / ) (427 /
4 8
