- Page 1 User Guide USB for Pro A/V Series USER MANUAL USB Extenders Twisted Pair Extender for USB Peripherals 68-1719-01 Rev. E 01 19...
- Page 2 Safety Instructions Safety Instructions • English Istruzioni di sicurezza • Italiano WARNING: This symbol, , when used on the product, is intended to AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad alert the user of the presence of uninsulated dangerous voltage within avvertire l’utente della presenza di tensione non isolata pericolosa the product’s enclosure that may present a risk of electric shock.
- Page 3 ついては、 エクス トロンのウェブサイ ト より 『Extron Safety www.extron.com and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。 Copyright © 2017-2019 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks( ®...
- Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 5 Conventions Used in this Guide Notifications The following notifications are used in this guide: CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure. ATTENTION: • Risk of property damage. • Risque de dommages matériels. NOTE: A note draws attention to important information. TIP: A tip provides a suggestion to make working with the application easier.
-
Page 6: Table Of Contents
Contents Introduction ..........1 Reference Information ......13 About this User Guide ......... 1 TP Cable Termination......... 13 About the USB Extender Tx/Rx ......2 Mounting the USB Extender ......14 TP Cable Advantages .......... 3 Tabletop Placement ........14 Features .............. 3 Rack Mounting .......... - Page 7 USB Extenders • Contents...
-
Page 8: Introduction
• Features About this User Guide This user guide contains information to install, configure, and operate the Extron Electronics USB Extender Tx/Rx, USB Extender AAP Tx/Rx, and the USB Extender D (decorator-style) Tx/Rx transmitter and receiver. Additional information can be found on the Extron Electronics website at www.extron.com. -
Page 9: About The Usb Extender Tx/Rx
A USB Extender system consists of a transmitter (Tx) and a receiver (Rx). The transmitter connects directly to a USB port on a PC or USB host. The receiver features a four port USB hub to connect multiple peripheral devices. The USB Extender Tx/Rx, AAP Tx/Rx, and Decorator-Style Tx/Rx transmitters and receivers can be mixed to accommodate applications that could require both rack mountable and architectural USB Extenders. -
Page 10: Tp Cable Advantages
Switcher Video LI N LI N LI N CAT 5/5e/6/7 Extron up to 450' (135 m) M AX 2. 0A USB Extender Tx USB Transmitter Laptop Extron M AX 2. 0A LI N P 10 USB Extender Rx USB Receiver Interactive Display Figure 2. -
Page 11: Installation And Operation
Installation and Operation This section provides the following details: Installation Overview • • Connection Guidelines • Mounting Options Overview Connections • • Operation System Operation • • Troubleshooting Installation Overview To install and set up the USB Extender series: Shut off power to all devices that will be directly connected to a USB Extender transmitter or receiver. -
Page 12: Connection Guidelines
Connection Guidelines The USB Extenders can be installed in existing and new systems within the following guidelines: • USB Extenders cannot be cascaded (you cannot sequentially connect a set of USB extenders to another set of USB extenders). • The maximum number of USB hubs that can be connected downstream is four, with a maximum total of 14 USB devices. -
Page 13: Connections
Connections Transmitter Rear Panel The Tx rear panel has the following connections: HOST POWER 0.4A MAX. DO NOT CONNECT TO LAN LINK Rack Mount DO NOT CONNECT TO LAN LINK POWER 0.4A MAX DO NOT CONNECT TO LAN Decorator-Style Figure 3. Transmitter (Tx) Rear Panel Connectors Power input connector —... - Page 14 USB host connector (USB Extender Tx only) — Connect a Type A-B female USB cable between this port and the USB port of a PC or laptop. The USB Extender is USB 2.0 compliant and supports data transfers of 480 Mbps (high speed), 12 Mbps (full speed), and 1.5 Mbps (low speed).
-
Page 15: Operation
Operation Transmitter Front Panel Indicators The transmitters have three LED indicators on the front panel. AAP and decorator-style transmitters also include a female USB mini-type B port. ACTIVITY HOST LINK USB EXTENDER Tx HOST ACTIVITY LINK HOST ACTIVITY HOST LINK... -
Page 16: Receiver Front Panel Indicators
Receiver Front Panel Indicators All receivers have a power, link, and host indicator LED on the front panel (similar to the transmitters) and also have four LEDs associated with the four USB hub ports. In addition, the front panel of the USB Extender Rx AAP and decorator-style includes four female Type A USB ports. -
Page 17: Cabling And Setup
Cabling and Setup To ensure proper operation, the transmitter, receiver, USB host, and USB peripherals must be connected properly and in the sequence described below. Connections are the same regardless of which models (Extender, Extender AAP or decorator-style) are installed. NOTE: If the USB host is capable of powering the transmitter (0.4 A maximum), the external supply for the transmitter is not required. - Page 18 If a host PC or laptop powers the transmitter: UTP or STP CAT5 or better cable. Terminate both ends identically, in accordance with either the TIA/EIA T 568A or the TIA/EIA T 568B wiring standard. (USB Host) Keyboard (Peripheral) Transmitter Receiver HOST POWER...
-
Page 19: System Operation
System Operation No drivers are required for a host PC to function with the USB Extenders. The transmitter is detected by the operating system and appropriate USB drivers are loaded. Certain USB peripherals, such as gaming keyboards, USB interactive whiteboards, scanners, printers, and similar devices, require specific drivers installed on the PC. -
Page 20: Reference Information
Reference Information This section provides information on the following subjects: TP Cable Termination • • Mounting the USB Extender TP Cable Termination NOTES: • RJ-45 termination with CAT 5, CAT 5e, CAT 6, CAT 6e, and CAT 7 cable must comply with the TIA/EIA T 568A or TIA/EIA T 568B wiring standard for all connections. -
Page 21: Mounting The Usb Extender
Mounting the USB Extender ATTENTION: • Installation and service must be performed by authorized personnel only. • L’installation et l’entretien doivent être effectués par le personnel autorisé uniquement. The three inch deep, one inch high, quarter-rack width USB Extender transmitters and receivers can be placed on a tabletop, mounted on a rack shelf, or mounted under a desk or tabletop. -
Page 22: Through-Furniture Mounting
Through-furniture Mounting The transmitter or receiver can be mounted through a desk or other furniture using an optional Extron Through-Desk Mounting Kit for quarter-rack or half-rack width products (see www.extron.com). To mount the USB Extenders follow the instructions provided with the mounting kit. - Page 23 Prepare the site and install the wall box • Choose a location that allows cable runs without interference. • Allow enough depth for both the wall box, the TP cable and power supply wiring. The box should be at least 2.5 inches (6.35 cm) deep to accommodate the connectors and cables.
- Page 24 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
