5.4.1
Client Side Connection Par ameters
Column Title
Node_Name
Object_Type
(Alias = Data_Type)
Object_Instance
(Alias = Address)
Property
Data_Array_Low_Scale*
Data_Array_High_Scale*
Node_Low_Scale*
Node_High_Scale*
Length*
Array_Index*
Write_Priority*
Linked_Map_Descriptors*
Length*
5.4.2
Timing Parameters
Column Title
Function
Scan_Interval*
Rate at which data is polled
Function
Name of Node to fetch data from.
Appendix D.1
Type of object. Refer to
more information.
Instance of the object on the device.
The BACnet property to be read.
Scaling zero in Data Array.
Scaling max in Data Array.
Scaling zero in Connected Node.
Scaling max in Connected Node.
Used to create an array of sequential
Object_Instances on an Object_Type.
When referencing Multistate properties,
allows the user to specify the index of the
property to be read. If 1 is specified, the
first one will be read, if 2 is specified, the
second will be read, etc. If 0 is specified,
the driver will return the total number
(count) of array items linked to the
property. If the parameter is not specified,
a list of all items will be returned. Refer to
Appendix
A.3.
Allows the driver to specify the write
priority used to write an output.
This parameter allows the linking of Map
Descriptors to an active read or write Map
Descriptor in order to construct a
ReadPropertyMultiple or
WritePropertyMultiple transaction. Refer
Appendix
A.9.
to
When the optional Length parameter is
set to a value N, the Map Descriptor will
include N consecutive instances of the
specified Object_Type. For example, if a
Map Descriptor specifies Object_Type,
Address 4 and Length 3, this means that
the AO instances 4, 5 and 6 will be
included in the read or write transaction.
The corresponding Data Array values are
in consecutive positions in the Data Array,
starting at the specified
Data_Array_Offset.
Legal Values
0-32000, 2s
Page 10 of 34
BACnet PTP Serial Driver Manual
Legal Values
One
of
the
Node_Names
specified in Section
for
AI, AO, AV, BI, BO, BV, MI,
MO, MV, NC
0, 1, 2, 3, ...4194303
Appendix D.2
Refer to
-32767 to 32767, 0
-32767 to 32767, 100
-32767 to 32767, 0
-32767 to 32767, 100
1 to max point count of the
FieldServer, 1
0 to max number of array items
in the BACnet Property, -
1..16, 16
The name of a previously
defined active Map Descriptor,
-
Any positive integer that falls
between the range of the
Data_Array_Offset and the
Data_Array_Length as
specified in Section 4, -
Appendix A.9
Refer also to
5.3
