5.4.3

Map Descriptor Example

// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name
CMD_AI_01 , DA_AI_01
CMD_AI_02 , DA_AI_01
CMD_AI_03 , DA_AI_01
CMD_AO_01 , DA_AO_01
CMD_AO_02 , DA_AO_01
CMD_AO_03 , DA_AO_01
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name
CMD_DI_01 , DA_DI_01
CMD_DI_02 , DA_DI_01
CMD_DI_03 , DA_DI_01
CMD_DO_01 , DA_DO_01
CMD_DO_02 , DA_DO_01
CMD_DO_03 , DA_DO_01
, Data_Array_Offset , Function , Node_Name
, 0 , Rdbc , DEV_1
, 1 , Rdbc , DEV_1
, 2 , Rdbc , DEV_1
, 0 , Rdbc , DEV_1
, 1 , Rdbc , DEV_1
, 2 , Rdbc , DEV_1
, Data_Array_Offset , Function , Node_Name
, 0 , Rdbc , DEV_1
, 1 , Rdbc , DEV_1
, 2 , Rdbc , DEV_1
, 0 , Rdbc , DEV_1
, 1 , Rdbc , DEV_1
, 2 , Rdbc , DEV_1
Page 11 of 34
BACnet PTP Serial Driver Manual
, Data_Type , Object_Instance , Property
, AI , 1 , Present_Value
, AI , 2 , Present_Value
, AI , 3 , Present_Value
, AO , 1 , Present_Value
, AO , 2 , Present_Value
, AO , 3 , Present_Value
, Data_Type , Object_Instance , Property
, BI , 1 , Present_Value
, BI , 2 , Present_Value
, BI , 3 , Present_Value
, BO , 1 , Present_Value
, BO , 2 , Present_Value
, BO , 3 , Present_Value
, Scan_Interval
, 20.000s
, 20.000s
, 20.000s
, 30.000s
, 30.000s
, 30.000s
, Scan_Interval
, 15.000s
, 15.000s
, 15.000s
, 30.000s
, 30.000s
, 30.000s
