5.3

Client Side Node Parameters

Section Title
Nodes
Column Title Function
Node_Name Provide name for Node.
Node_ID Specify the BACnet Device object instance.
Protocol Specify protocol used.
Port Specify port.
Retries* Number of timeouts before the Node goes offline.
Example
// Client Side Nodes
Nodes
Node_Name , Node_ID
DEV_1 , 1
5.4

Map Descriptor Parameters

Column Title
Map_Descriptor_Name
Data_Array_Name
Data_Array_Offset
Function
, Protocol , Port
, BACnet_PTP , P1
Function
Name of this Map Descriptor. This is used
for Object_Name Property. Refer to
Appendix A.1.
Name of Data Array where data is to be
stored in the FieldServer.
Starting location in Data Array.
Function of Client Map Descriptor.
Page 9 of 34
BACnet PTP Serial Driver Manual
Legal Values
Up to 32 alphanumeric characters
1 - 16777215
BACnet_PTP
P1-P2
0,1,2,3
, Retries
, 2
Legal Values
Up to 32 alphanumeric
characters
One of the Data Array names
from Section
0 to (Data_Array_Length-1) as
specified in Section
Rdbc, Wrbc, Wrbx, Arcs
