- Page 1 AT-6010 Advanced Wire Tracer User Manual ENG FRE SPA 1.800.561.8187 information@itm.com www. .com...
-
Page 2: User Manual
AT-6010 Advanced Wire Tracer User Manual 3/2019, 6011540 B ©2019 Amprobe All rights reserved. Printed in China. 1.800.561.8187 information@itm.com www. .com... - Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for one year from the date of purchase unless local laws require otherwise. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
-
Page 4: Table Of Contents
2. KIT COMPONENTS ...................... 2.1 AT-6010-R Receiver ......................5 2.2 AT-6010-T Transmitter ......................6 2.3 CT-400 Signal Clamp (optional accessory for the AT-6010) ..........9 3. MAIN APPLICATIONS ....................3.1 Tracing – Energized and De-energized Wires ..............11 3.2 Identifying Breakers and Fuses (Energized and De-energized) ........13 4. -
Page 5: Precautions And Safety Measures
• If the Transmitter or Receiver will not be used for a long time, remove the batteries to prevent leakage in the instruments. • Use Amprobe approved cables and accessories only. Safety precautions • In many instances, dangerous levels of voltage and/or current may be present. Therefore, it is important to avoid direct contact with any uninsulated current carrying surfaces. - Page 6 1. PRECAUTIONS AND SAFETY MEASURES Safety information The product complies with: • UL/IEC/EN 61010-1, CAN/CSA C22.2 No. 61010-1, Pollution Degree 2, Measurement CAT III 600 V MAX • IEC/EN 61010-2-033 • IEC/EN 61010-2-032 • IEC/EN 61010-031 (test leads) • EMC IEC/EN 61326-1 Measurement Category III (CAT III) is applicable to test and measure circuits connected to the distribution part of the building’s low-voltage MAINS installation.
- Page 7 CAUTION: Do not connect the Transmitter to a separate ground in Electrically Susceptible Patient areas of a health care facility. Make the ground connection before disconnecting. Your shipping box should include: AT-6010 KIT AT-6010-R RECEIVER AT-6010-T TRANSMITTER TL-6000-INTL TEST LEAD AND ACCESSORY KIT*...
-
Page 8: Kit Components
2. KIT COMPONENTS 2.1 AT-6010-R Receiver The AT-6010-R Receiver detects the signal in wires and cables. The signal is generated by the AT- 6010-T Transmitter, which is connected to the wire. The main advantage of this method is the ability to trace the path of the particular wire using the Receiver. -
Page 9: At-6010-T Transmitter
2. KIT COMPONENTS 2.2 AT-6010-T Transmitter The AT-6010-T Transmitter works on Energized and De-energized circuits up to 600 V AC/DC in Category I through Category III electrical environments. Transmitter signal modes: High Signal (Hi) – The HIGH mode function is recommended for most wire tracing applications on Energized and De-energized circuits including breaker location. - Page 10 2. KIT COMPONENTS Figure 2.2b: Generating a signal in Loop mode Note: Loop mode only works on De-energized circuits. It is automatically disabled when the Transmitter is connected to an Energized line with test leads. Working with the Transmitter: When the Transmitter is on and connected to the circuit with test leads, it checks for voltage. A red Voltage Warning Indicator will light up if the Transmitter detects dangerous voltage levels above 30 V AC/DC.
- Page 11 LOW BATTERY ON / OFF BUTTON INDICATION Figure 2.2c: Overview of AT-6010-T Transmitter ON/OFF: • Long press >2s to turn the Transmitter on (Transmitter is automatically in HIGH mode). • Short press ON/OFF button to switch between HIGH and LOOP mode.
-
Page 12: Ct-400 Signal Clamp (Optional Accessory For The At-6010)
2. KIT COMPONENTS 2.3 CT-400 Signal Clamp (optional accessory for the AT-6010) The Signal Clamp accessory is used for applications when where is no access to the bare conductors. The clamp attachment enables the Transmitter to induce a signal through the insulation into either wires. -
Page 13: Main Applications
3. MAIN APPLICATIONS IMPORTANT NOTICE, PLEASE READ BEFORE STARTING TRACING X� Avoiding signal cancellation problems with a separate ground connection The signal generated by the Transmitter creates an electromagnetic field around the wire. This field is what is detectable by the Receiver. The clearer this signal, the easier it is to trace the wire. If Transmitter is connected to two adjacent wires on the same circuit (for example, hot and neutral wires on a Romax cable), the signal travels in one direction through the first wire and then returns (in opposite direction) through the second. -
Page 14: Tracing - Energized And De-Energized Wires
Figure 3.1b: Connecting Transmitter to Energized working system Setting up the AT-6010-T Transmitter 1. Press ON/OFF key to turn on the Transmitter. 2. Verify that the test leads are properly connected;... - Page 15 3. MAIN APPLICATIONS - TRACING ENERGIZED AND DE-ENERGIZED WIRES Using the AT-6010-R Receiver in Tracing Mode Use Receiver to precisely pinpoint the wire location or the place of the fault. The Receiver will indicate detected signal strength using a two digit readout, bar graph and sound.
-
Page 16: Identifying Breakers And Fuses (Energized And De-Energized)
3. MAIN APPLICATIONS - TRACING ENERGIZED AND DE-ENERGIZED WIRES 3.2 Identifying Breakers and Fuses (Energized and De-energized) Note: For breaker locating, a simplified direct connection to hot and neutral wires can be used because these wires are separated at the breaker panel. There is no risk of signal cancellation effect if wires are at least a few inches away from each other. - Page 17 3. MAIN APPLICATIONS – LOCATING BREAKERS Figure 3.2c: Connecting Transmitter to Energized working system Setting up the AT-6010-T Transmitter 1. Press the ON/OFF key to turn on the Transmitter. 2. Verify that the test leads are properly connected. The red LED voltage status light will illuminate for Energized circuits with a voltage above 30 V AC/DC.
-
Page 18: Special Applications
4. SPECIAL APPLICATIONS 4.1 GFCI-Protected Circuit Wire Tracing: Connecting the AT-6010-T Transmitter to GFCI Protected Circuits Connecting the Transmitter to an Energized GFCI protected circuit using a separate ground method will trip the GFCI protection. Use the following methods to work with GFCI protected circuits. -
Page 19: Finding Shorts
4. SPECIAL APPLICATIONS The tracing signal generated by the Transmitter is conducted along the wire as long as there is continuity in the metal conductor. To find a fault, trace the wire until the signal stops. To verify the fault’s location, move the Transmitter to the other end of the wire and repeat, tracing from the opposite end. -
Page 20: Tracing Non-Metallic Pipes And Conduits
4. SPECIAL APPLICATIONS 4.5 Tracing Non-Metallic Pipes and Conduits The Transmitter can indirectly trace plastic conduits and pipes using the following steps: 1. Insert fish tape or wire inside the conduit. 2. Connect the Transmitter with the red test lead to the fish tape and the green ground wire to a separate ground (see section 3.1 for further set-up instructions). -
Page 21: Tracing Underground Wires
Follow general wire tracing instructions in section 3. Figure 4.7: Tracing underground wires 4.8 Tracing Low Voltage Wires and Data Cables The AT-6010 can trace data, audio and thermostat cables (to trace shielded data cables, refer to section 4.6). Trace data, audio, and thermostat cables 1. -
Page 22: Sorting Bundled Wires
4. SPECIAL APPLICATIONS 4.9 Sorting Bundled Wires Identify a specific wire in a bundle 1. Connect the Transmitter as described in section 3.1. If connecting to an Energized wire, make sure the Transmitter is connected on the load side. 2. Turn on the Receiver. Tracing mode is automatically activated. 3. -
Page 23: Tracing Breakers On Systems With Light Dimmers
Figure 4.12a: Connecting the clamp Setting up the AT-6010-T Transmitter 1. Press the ON/OFF key to turn on the Transmitter. The red LED voltage status indicator should be OFF when the clamp is connected and when working with either Energized or De-energized systems. -
Page 24: Signal Clamp (Optional Accessory) - Mapping Circuits
4. SPECIAL APPLICATIONS Using the AT-6010-R Receiver 1. Turn on the Receiver. Tracing mode is automatically activated. 2. Hold the Receiver with the Tip Sensor facing the target area. 3. Scan the target area with the Tip Sensor to find the highest signal level. While tracing, periodically adjust the sensitivity to keep the signal strength near 50. -
Page 25: Maintenance
5. MAINTENANCE 5.1 Battery Replacement Changing the Transmitter Batteries The battery compartment on the back of the Transmitter is designed to make it easy for the user to change the batteries. A screw is added to secure the battery in case the unit is dropped. Eight (8) AA alkaline batteries should be used. - Page 26 5. MAINTENANCE Changing the Receiver Batteries The battery compartment on the back of the Receiver is designed to make it easy for the user to change the batteries. Use four (4) AA 1.5 V alkaline batteries. Note: Batteries do not come pre-installed in the Receiver. 1.
-
Page 27: Fuse Replacement
5. MAINTENANCE 5.2 Fuse Replacement Transmitter Fuse Replacement: X� Warning: To avoid shock, injury, or damage to the Transmitter, disconnect test leads before opening case. 1. Disconnect all test leads from the Transmitter. 2. Make sure the Transmitter is turned off. 3. -
Page 28: Specifications
6. SPECIFICATIONS Features AT-6010-R AT-6010-T CT-400 Measurement CAT III 600 V CAT III 600 V CAT IV 600 V, Category CAT III 1000 V Operating 0 to 600 V AC/DC 0 to 600 V AC/DC 0 to 1000 V AC... -
Page 29: General Specifications
6. SPECIFICATIONS General specifications Features AT-6010-R AT-6010-T CT-400 Display Size LCD 2.5 in (6.35 cm) LEDs Display Dimensions 1.45 x 1.93 in (36.72 x 48.96 mm) (W x H) Display Type Segment LCD LEDs Display Color Black and white Operating mode LEDs: red... - Page 30 6. SPECIFICATIONS Accessory specifications Features TL-6000-INTL Measurement Category CAT III (test leads) CAT IV (alligator clips) CAT II (outlet adapters) Operating Voltage and Current 1000 V, 16 A max. (red/green leads) 600 V, 16 A max. (black lead) 600 V, 10 A max. (alligator clips) 300 V, 10 A max.
