DVD Player with
Component
Video Connectors
DVD player
Use this hookup if:
❑
Your DVD player has component (YP
Disconnect all power sources before making any connections.
1
Use a component video cable to connect the DVD player's YP
to the TV's YP P jacks. Use the HD/DVD IN 4 or 5 input.
B R
✍
The YP P jacks on your DVD player are sometimes labeled YC
B R
or Y, B-Y and R-Y. If so, connect the cables to like colors.
2
Use an audio cable to connect the DVD player's AUDIO OUT jacks to
the TV's AUDIO IN jacks. Be sure to use the same row of inputs that
you used for the video connection (HD/DVD IN 4 or 5).
Component video cable
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Audio cable
✍
To take advantage of the Wide Mode feature, set the DVD player's
aspect ratio to 16:9. For details, refer to the operating instructions
supplied with your DVD player.
P ) jacks.
B R
Rear of TV
4 5
1 3
S VIDEO
VIDEO
L
(MONO)
AUDIO
R
HD/DVD IN
VIDEO IN
(1080i/720p/480p/480i)
AUDIO-R
AUDIO-L
P jacks
B R
C ,
B R
Y
P
B
P
R
Y
P
B
AUDIO
OUT
P
R
( VAR/FIX )
L
R
