See also: Configuration Manual
SENTRON 3WL / 3VL
Library for SIMATIC PCS 7 V1.0
Function Manual
11/2008
•
SIMATIC

Advertisement

Table of Contents
loading

Related Manuals for Siemens Library SENTRON 3WL

Summary of Contents for Siemens Library SENTRON 3WL

  • Page 1 SENTRON 3WL / 3VL Library for SIMATIC PCS 7 V1.0 Function Manual 11/2008 • SIMATIC...

  • Page 3: A5E02316914A

    Introduction Information about the library Description of blocks Configuration Manual Library SENTRON 3WL / 3VL for Technical specifications SIMATIC PCS 7 Technical support Function Manual V1.0 11/2008 A5E02316914A-01...
  • Page 4 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Table Of Contents

    3.3.5 Assignment of the cyclic process image..................100 3.3.6 Addressing and module driver ....................101 3.3.7 Processing the diagnostics data of the 3VL device ..............102 3.3.8 Start-up characteristics ......................102 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 6 Faceplate for diagnosis view, trip reason tab................72 Figure 3-11 Faceplate for diagnosis view, setpoints tab ................74 Figure 3-12 Faceplate for maintenance view, maintenance 1 tab ..............76 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 7 Compile program ........................133 Figure 4-8 Generate module driver ......................133 Figure 4-9 Driver block in CFC chart connected ..................134 Figure 4-10 Basing the block icons on the plant hierarchy ................135 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 8 Creating block icons out of plant hierarchy ................136 Figure 4-12 Create block icons when compiling OS ..................136 Figure 4-13 Link picture component with measuring point................137 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 9: Introduction

    Introduction General The Library SENTRON 3WL / 3VL for SIMATIC PCS 7 software package is used to connect the circuit breakers SENTRON 3WL and 3VL to a SIMATIC PCS 7 process control system and contains the following components: ● Block library with: –...

  • Page 10: Hardware Configuration

    ● Outputs: 2 bytes of digital control data ● Inputs: 44 bytes of binary status (2 bytes) and measurements with property bytes (42 bytes) Figure 1-2 Selection of basic type for 3WL Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 11: Figure 1-3 Selection Of Basic Type For 3Vl

    Figure 1-3 Selection of basic type for 3VL This configuration corresponds to basic type 1 for 3VL. This basic type must be set to ensure operation. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 12: Figure 1-4 Properties Of The 3Wl / 3Vl Device Directly Connected To The Dp Master System

    In the HW config., 3WL / 3VL is installed with the corresponding GSD file (see above) and with basic type 3 and/or 1. Figure 1-4 Properties of the 3WL / 3VL device directly connected to the DP master system Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 13: Figure 1-5 Properties Of The 3Wl / 3Vl Device Following A Y Link

    The LADDR parameter input of the driver block must be connected to the start address of the inputs of the 3WL / 3VLdevice. The assignment of the cyclic interface is included in the description of the driver block. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 14 Introduction 1.4 Hardware configuration Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 15: Information About The Library

    The display forms part of the @PG_DRV_3WL_OVERVIEW.pdl / @PL_DRV_3WL.pdl (and/or @PG_DRV_3VL_OVERVIEW.pdl / @PL_DRV_3VL.pdl) basic displays. Group display Message lock (MSG_LOCK) Message acknowledgment Message suppression (QMSG_SUP) Figure 2-1 Section of the overview display Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 16: Figure 2-2 Trend Setting On The Icon

    • ReturnPath: .AVGCUR Structural element name starting with a full stop Separators CO_GREEN Color for trend Separators between two online values Figure 2-2 Trend setting on the icon Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 17: Symbols

    The icons contain the following visible information: Tag name Maximum phase current Group display (EventState) Circuit breaker in manual (M) / automatic (A) Circuit breaker state Figure 2-3 Icons in Graphics Designer Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 18 Information about the library 2.2 General information about OS typicals Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 19: Description Of Blocks

    ● Read diagnostics data of 3WL / 3VL (Page 19) ● Start-up characteristics (Page 20) ● Block parameters (Page 20) See also Driver module DRV_3WL (Page 22) Driver module DRV_3VL (Page 95) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 20: Calling Obs

    MOD_PAX0 block (in the case of direct connection to the DP master system) or PADP_L00 (in the case of connection following the Y link DPV0) or OB_DIAG1 (in the case of connection following the Y link DPV1). Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 21: Error Behavior

    ● MAINT_MC ! = 0 ● R_MAINT = 1 ● Cyclically at DIAREQ_T ! = 0.0 min The diagnostics data can also be displayed on a Maintenance Station (MS). Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 22: Start-Up Characteristics

    1 = DP slave system failure (primary) BOOL FALSE RACK2ERR 1 = DP slave system failure (redundant) BOOL FALSE QUALITY Quality code of process value BYTE OMODE Status MODE DWORD Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 23 16#01: Cold restart (OB100) Byte 1; 0 16#0000 Irrelevant Structure of QDIAG_INF VALUE Meaning Everything ok Perform visual inspection on main contacts Immediate maintenance of main contacts Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 24: 3.2 Driver Module Drv_3Wl

    Driver module DRV_3VL (Page 95) 3.2.1 Calling OBs The OB watchdog interrupt in which the block is installed (e.g. OB32). Also in OB100 (performed automatically in CFC, see start-up characteristics). Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 25: Called Blocks

    Under certain circumstances this means that resetting error states may cause a switching operation of the circuit breaker. If this is not desired the user must configure the AS program accordingly. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 26 If such a state is reset the response of the mode must be observed as it may cause a switching operation of the circuit breaker under certain circumstances. See Automatic / Manual mode switchover Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 27 At the same time, the circuit breaker must be locked locally to prevent it being switched back on. Maintenance specifications apply to the circuit breakers (in accordance with EN 50 110-1, DIN VDE 0105-100 and BGV A2). Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 28: Message Behavior

    Perform visual inspection on main contacts Immediate maintenance of main contacts Monitoring error AS Control System Fault Forbidden switching command for auto mode - switching AS Control System command ignored Fault Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 29: Assignment Of The Cyclic Process Image

    EB of current phase 2 EB of current phase 3 EB of max. current in phase under highest load EB of current in neutral conductor EB of phase-to-phase voltage L12 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 30: Addressing And Module Driver

    The user has the possibility of setting the cycle for cyclic reading of the diagnostics data record at the "DIAREQ_T" input. At DIAREQ_T = 0.0 minutes no cyclic reading takes place. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 31: Start-Up Characteristics

    1 = Active message suppression BOOL FALSE SUP_SP_EXCEED 1 = Active message suppression BOOL FALSE SUP_WRN 1 = Active message suppression BOOL FALSE SUP_LD_SHED 1 = Active message suppression BOOL FALSE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 32 DR 130: Delay time for power factor BOOL FALSE capacitive not available T_PF_IND_I DR 130: Delay time for power factor REAL inductive T_PF_IND_I_QC Quality code of T_PF_IND_I BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 33 DR 130: Delay time for THD voltage OFF BOOL FALSE T_VOLT_THD_I_NA DR 130: Delay time for THD voltage not BOOL FALSE available CREST_F_I DR 130: Crest factor REAL CREST_F_I_QC Quality code of CREST_F_I BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 34 DR 130: Demand reactive power REAL RAP_DEM_I_QC Quality code of RAP_DEM_I BYTE RAP_DEM_I_OFF DR 130: Demand reactive power OFF BOOL FALSE RAP_DEM_I_NA DR 130: Demand reactive power not BOOL FALSE Available Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 35 DR 130: Delay time for apparent power BOOL FALSE T_AP_I_NA DR 130: Delay time for apparent power not BOOL FALSE available CUR_OVER_I DR 130: Over current REAL Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 36 FALSE UNBAL_CUR_I_NA DR 130: Phase unbalance current not BOOL FALSE available T_UNBAL_CUR_I DR 130: Delay time for phase unbalance REAL current T_UNBAL_CUR_I_QC Quality code of T_UNBAL_CUR_I BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 37 DR 130: Delay time for over voltage not BOOL FALSE available RD_DR69 Read data record 69 (status of the BOOL FALSE modules) RD_DR91 Read data record 91 (statistic and BOOL FALSE maintenance) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 38 QOFF_OP 1 = Operator enabled for "OFF" BOOL FALSE QON_OP 1 = Operator enabled for "ON" BOOL FALSE QRES_OP 1 = Operator enabled for "RESET" BOOL FALSE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 39 Quality code of PF_AVG BYTE ACT_W Active energy in normal direction REAL ACT_W_QC Quality code of ACT_W BYTE KVA_TOT Apparent power total REAL KVA_TOT_QC Quality code of KVA_TOT BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 40 Short time off / Ground fault on not BOOL FALSE available N_ACT_LD DR 91: Number of switch actions under WORD load N_ACT_LD_QC Quality code of N_ACT_LD BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 41 BOOL FALSE S_I2T_L3 DR 91: Sum of I2T-values L3 REAL S_I2T_L3_QC Quality code of S_I2T_L3 BYTE S_I2T_L3_NA DR 91: Sum of I2T-values L3 not available BOOL FALSE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 42 Setpoint warning number 3 SP_NO4 Setpoint warning number 4 SP_NO5 Setpoint warning number 5 SP_NO6 Setpoint warning number 6 SP_NO7 Setpoint warning number 7 SP_NO8 Setpoint warning number 8 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 43 DR 94: Phase unbalanced voltage (in %) BOOL FALSE not available VOLT_L1L2 DR 94: Delta voltage between phase L1 REAL and L2 VOLT_L1L2_QC Quality code of VOLT_L1L2 BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 44 RP_L2_QC Quality code of RP_L2 BYTE RP_L2_NA DR 94: Real power in phase L2 not BOOL FALSE available RP_L3 DR 94: Real power in phase L3 REAL Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 45 Quality code of AP_L3 BYTE AP_L3_NA DR 94: Apparent power in phase L3 not BOOL FALSE available DEM_AP_L1 DR 94: Demand of the apparent power in REAL phase L1 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 46 DR 94: Reactive energy in normal direction REAL [MVarh] REC_E_NORM_QC Quality code of REC_E_NORM BYTE REC_E_NORM_NA DR 94: Reactive energy in normal direction BOOL FALSE [MVarh] not available Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 47 DR 94: Temperature in the cubicle (det. in BOOL FALSE the COM15) not available TMP_MSAE DR 94: Temperature in the circuit breaker REAL (det. in BSS) TMP_MSAE_QC Quality code of TMP_MSAE BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 48 0 CUR_TRNS_LIM_QC Quality code of CUR_TRNS_LIM BYTE CUR_TRNS_LIM_OFF DR 128: Current transmission limit; below BOOL FALSE this all currents will be set to 0 OFF Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 49 DR 128: Under frequency OFF BOOL FALSE UNDER_FRQ_NA DR 128: Under frequency not available BOOL FALSE T_OV_FRQ DR 128: Delay time for over frequency REAL T_OV_FRQ_QC Quality code of T_OV_FRQ BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 50 DR 128: Delay time for phase unbalanced REAL voltage T_PH_U_V_QC Quality code of T_PH_U_V BYTE T_PH_U_V_OFF DR 128: Delay time for phase unbalanced BOOL FALSE voltage OFF Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 51 DR 128: 2. event for the 1st output not BOOL FALSE available EV3_OUT1 DR 128: 3. event for the 1st output BYTE EV3_OUT1_QC Quality code of EV3_OUT1 BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 52 DR 128: 5. event for the 2nd output OFF BOOL FALSE EV5_OUT2_NA DR 128: 5. event for the 2nd output not BOOL FALSE available EV6_OUT2 DR 128: 6. event for the 2nd output BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 53 Quality code of EV_OUT5 BYTE EV_OUT5_OFF DR 128: Event for the 5th output OFF BOOL FALSE EV_OUT5_NA DR 128: Event for the 5th output not BOOL FALSE available Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 54 DR 129: Delay time for S-trip tsd PS A not BOOL FALSE available E_FLT_PROT_A DR 129: Earth fault protection parameter REAL lg1 PS A E_FLT_PROT_A_QC Quality code of E_FLT_PROT_A BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 55 DR 129: I4t curve for overload protection BOOL FALSE PS A not available THERM_MEM_A DR 129: Thermal memory PS A BOOL FALSE THERM_MEM_A_QC Quality code of THERM_MEM_A BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 56 PS B OFF SHORT_D_PROT_B_NA DR 129: Short time delayed prot. BOOL FALSE parameter lsd PS B not available T_STRIP_B DR 129: Delay time for S-trip tsd PS B REAL Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 57 DR 129: I2t curve for earth fault protection BOOL FALSE PS B OFF I2T_EFLT_PROT_B_NA DR 129: I2t curve for earth fault protection BOOL FALSE PS B not available Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 58 FALSE EARTH_FLT_CUR DR 129: Determination of earth fault REAL current EARTH_FLT_CUR_QC Quality code of EARTH_FLT_CUR BYTE EARTH_FLT_CUR_OFF DR 129: Determination of earth fault BOOL FALSE current OFF Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 59 UNDER_FRQ_O DR 130: Under frequency REAL UNDER_FRQ_O_QC Quality code of UNDER_FRQ_O BYTE T_UNDER_FRQ_O DR 130: Delay time for under frequency REAL T_UNDER_FRQ_O_QC Quality code of T_UNDER_FRQ_O BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 60 Quality code of RAP_REV_O BYTE AP_O DR 130: Apparent power REAL AP_O_QC Quality code of AP_O BYTE T_RAP_REV_O DR 130: Delay time for reactive power in REAL reverse direction Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 61 OVER_VOLT_O DR 130: Over voltage REAL OVER_VOLT_O_QC Quality code of OVER_VOLT_O BYTE T_OVER_VOLT_O DR 130: Delay time for over voltage REAL T_OVER_VOLT_O_QC Quality code of T_OVER_VOLT_O BYTE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 62: Description Of Symbols And Faceplates

    ● Setpoints view, current tab ● Setpoints view, voltage tab ● Setpoints view, frequency tab ● Setpoints view, active power tab ● Setpoints view, apparent/reactive power tab ● Message suppression view Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 63: Figure 3-1 Symbol With 1 Measurement

    Protect. para with the tabs Parameter Set A PARA_SET_A Parameter Set B PARA_SET_B Additional PROTPARA_ADD Ext. Prot. Para with the tabs Current EXTPROTPARA_CUR Voltage EXTPROTPARA_VOLT Active power EXTPROTPARA_ACT_POW Frequency EXTPROTPARA_FREQ Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 64 "---". These measured values are therefore not indicated in the faceplates. The faceplates in the figures below are shown for direct connection of 3WL to the DP master system. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 65: Figure 3-2 Faceplate For Standard View

    CUR_L3 RES_MONERR QMON_ERR (10) MAINT (11) POS_CB (12) QLOC_OFF / ST_CB (13) CUR_MAX (14) ST_CB Figure 3-2 Faceplate for standard view not ready tripped Symbol for status Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 66 RESET Reset "Tripped" or "Local turn off" status CUR_L1 Current in phase L1 CUR_L2 Current in phase L2 CUR_L3 Current in phase L3 RES_MONERR Reset monitoring error Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 67: Figure 3-3 Faceplate For Measurements View, Current Tab

    Current in neutral conductor CUR_DEM_L1 Demand for current L1 CUR_DEM_L2 Demand for current L2 CUR_DEM_L3 Demand for current L3 CUR_DEM3 Demand for 3-phase current CUR_UNBAL Phase unbalance current (as %) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 68: Figure 3-4 Faceplate For Measurements View, Voltage Tab

    Faceplate for measurements view, voltage tab Element (parameters) Meaning Display when 3WL is connected following Y-link U_L1_L2 Voltage V U_L2_L3 Voltage V U_L3_L1 Voltage V U_L1_N Voltage V U_L2_N Voltage V Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 69: Figure 3-5 Faceplate For Measurements View, Active Power/Energy Tab

    Element (parameters) Meaning Display when 3WL is connected following Y-link RP_L1 Active power in phase L1 RP_L2 Active power in phase L2 RP_L3 Active power in phase L3 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 70: Figure 3-6 Faceplate For Measurements View, Reactive Power/Energy Tab

    Display when 3WL is connected following Y-link RAP_L1 Reactive power in phase L1 RAP_L2 Reactive power in phase L2 RAP_L3 Reactive power in phase L3 SUM_RAP Total reactive power Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 71: Figure 3-7 Faceplate For Measurements View, Apparent Power Tab

    Apparent power in phase L3 DEM_AP_L1 Demand of apparent power in phase L1 DEM_AP_L2 Demand of apparent power in phase L2 DEM_AP_L3 Demand of apparent power in phase L3 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 72: Figure 3-8 Faceplate For Measurements View, Miscellaneous Tab

    Power factor in phase L3 TMP_CUB Temperature in the control cabinet (acc. to in COM15) TMP_MSAE Temperature in circuit-breaker (acc. to in BSS) PF_AVG Mean power factor value Frequency Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 73: Figure 3-9 Faceplate For Diagnosis View, Warnings Tab

    3rd warning currently active WRN_NO4 4th warning currently active WRN_NO5 5th warning currently active WRN_NO6 6th warning currently active WRN_NO7 7th warning currently active WRN_NO8 8th warning currently active Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 74: Figure 3-10 Faceplate For Diagnosis View, Trip Reason Tab

    Faceplate for diagnosis view, trip reason tab Element (parameters) Meaning Display when 3WL is connected following Y-link LST_TRIP Trip reason TRIP_NO Accurate trip reason in event of trip by extended protective function Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 75 Phase unbalance voltage Real power in normal direction Real power in reverse direction Over voltage Under voltage Over frequency Under frequency THD current THD voltage Change of phase rotation Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 76: Figure 3-11 Faceplate For Diagnosis View, Setpoints Tab

    5th current case of setpoint being exceeded SP_NO6 6th current case of setpoint being exceeded SP_NO7 7th current case of setpoint being exceeded SP_NO8 8th current case of setpoint being exceeded Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 77 Apparent power Over frequency Under frequency Over current Over current earth fault Over current N-phase Phase unbalance current Demand current Under voltage Phase unbalance voltage Over voltage Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 78: Figure 3-12 Faceplate For Maintenance View, Maintenance 1 Tab

    Number of short-circuit releases (SI) N_OVL_TRP Number of overload trips (L) N_EF_TRP Number of ground-fault trips (G) S_I2T_L1 Total of deactivated I2t values L1 S_I2T_L2 Total of deactivated I2t values L2 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 79 Faceplate for maintenance view, maintenance 2 tab Element (parameters) Meaning Display when 3WL is connected following Y-link CON_MOD Modules which are connected to the cubicle bus RD_DR91 Read maintenance information (data record 91) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 80 Analog output module #1 Metering or Metering Plus When the relevant bit is set, the corresponding text is displayed in the faceplate. Otherwise the field remains empty. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 81 A tripping operation currently active is acknowledged and reset DEL_TRIP Delete tripping and event log R_VAL_MEM Reset all min./max. value memories (apart from temperature) R_TEMP Reset minimum / maximum temperatures Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 82 I2T_EFLT_PROT_A (10) E_FLT_PROT2_A (11) E_FLT_PROT_A (12) IN_PRO_PARA_A (13) T_STRIP_A (14) SHORT_D_PROT_A (15) TL_CL_A (16) THERM_T_A (17) OV_LD_A Figure 3-15 Faceplate for protect. para view, parameter set A Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 83 Overload protection neutral conductor IN PS A (WL) T_EFLT_A Delay time for ground fault tg1 PS A T_EFLT2_A Delay time for ground fault tg2 PS A RD_DR129 Read protect. para (data record 129) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 84 I2T_EFLT_PROT_B (10) E_FLT_PROT2_B (11) E_FLT_PROT_B (12) IN_PRO_PARA_B (13) T_STRIP_B (14) SHORT_D_PROT_B (15) TL_CL_B (16) THERM_T_B (17) OV_LD_B Figure 3-16 Faceplate for protect. para view, parameter set B Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 85 Overload protection neutral conductor IN PS B (WL) T_EFLT_B Delay time for ground fault tg1 PS B T_EFLT2_B Delay time for ground fault tg2 PS B RD_DR129 Read protect. para (data record 129) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 86 EARTH_FLT_CUR Type of ground fault detection STON_GFOFF ZSI short-circuit STOFF_GFON ZSI ground fault RD_DR69 Read ZSI parameter (data record 69) RD_DR129 Read protect. para (data record 129) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 87 T_PH_U_CUR Delay time for current unbalance T_THD_CUR Delay time of THD of current RD_DR128 Read ext. protect. para (data record 128) CUR_TRNS_LIM Lower limit of current transfer Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 88 Phase direction of rotation T_PH_U_V Delay time for voltage unbalance T_UN_VOLT Delay time for under voltage T_OV_VOLT Delay time for over voltage RD_DR128 Read ext. protect. para (data record 128) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 89 Real power in reverse direction T_RP_NORM Delay time for active power in normal direction T_RP_REV Delay time for active power in reverse direction RD_DR128 Read ext. protect. para (data record 128) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 90 Y-link UNDER_FRQ Under frequency OV_FRQ Over frequency T_UN_FRQ Delay time for under frequency T_OV_FRQ Delay time for over frequency RD_DR128 Read ext. protect. para (data record 128) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 91 Current which flows to earth CUR_N_I Over current in neutral conductor UNBAL_CUR_I Phase unbalance current CUR_DEM_I Demand of current CUR_THD_I THD current T_CUR_OVER_I Delay time for over current Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 92 T_UNDER_VOLT_I T_OVER_VOLT_I T_UNBAL_VOLT_I T_VOLT_THD_I T_CREST_F_I T_FORM_F_I WR_DR130 RD_DR130 FORM_F_I (10) CREST_F_I (11) VOLT_THD_I (12) UNBAL_VOLT_I (13) OVER_VOLT_I (14) UNDER_VOLT_I Figure 3-23 Faceplate for setpoints view, voltage tab Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 93 Read setpoints (data record 130) WR_DR128 Write setpoints (data record 130) Setpoints – frequency tab (SETPOINTS_FREQ) T_UNDER_FRQ_I T_OVER_FRQ_I WR_DR130 RD_DR130 OVER_FRQ_I UNDER_FRQ_I Figure 3-24 Faceplate for setpoints view, frequency tab Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 94 Setpoints – active power tab (SETPOINTS_ACT_POW) T_RP_NORM_I T_RP_REV_I T_PF_CAP_I T_PF_IND_I T_RP_DEM_I WR_DR130 RD_DR130 RP_DEM_I PF_IND_I (10) PF_CAP_I (11) RP_REV_I (12) RP_NORM_I Figure 3-25 Faceplate for setpoints view, active power tab Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 95 T_PF_IND_I Delay time for power factor, inductive T_RP_DEM_I Delay time for demand of active power RD_DR128 Read setpoints (data record 130) WR_DR128 Write setpoints (data record 130) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 96 Delay time for apparent power T_RAP_NORM_I Delay time for reactive power in normal direction T_RAP_REV_I Delay time for reactive power in reverse direction T_AP_DEM_I Delay time for demand of apparent power Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 97: Driver Module Drv_3Vl

    Message ("An active setpoint has been exceeded") is not output SUP_WRN Message ("There is currently a warning message present") is not output SUP_LD_SHED Message ("Load shedding warning") is not output Driver module DRV_3VL FB1740 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 98: Calling Obs

    READ_CLK SFC6 RD_SINFO SFC20 BLKMOV SFC21 FILL 3.3.3 Function The DRV_3VL block is used for measurement acquisition and control and it forms the interface to the OS. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 99 • the circuit breaker is already off (QOFF = 1) • the circuit breaker has tripped (QTRIP = 1) • the circuit breaker has been switched off locally (QLOC_OFF = 1) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 100 Data record 68 writes the current time in cycles in order to transfer the current time to the circuit breaker. This cycle can be set in seconds using the TIME_SYNC_T parameter. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 101: Message Behavior

    Overload warning present An activated setpoint value has been exceeded MSG_EVID2 An alarm signal is currently present Error time synchronization Local turn off of circuit breaker / tripped Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 102: Assignment Of The Cyclic Process Image

    2 / 3 Current in phase 1 4 / 5 Current in phase 2 6 / 7 Current in phase 3 8 / 9 Current in neutral conductor Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 103: Addressing And Module Driver

    The input DPA_LINK is parameterized with the connection mode of the 3VL device by the module driver. ● DPA_LINK = 0 → Directly connected to the DP master ● DPA_LINK = 1 → Connected following a DP/PA link Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 104: Processing The Diagnostics Data Of The 3Vl Device

    Linkable Input for MANUAL / AUTO mode BOOL FALSE AUTO_ON AUTOMode: Switch off (open the main BOOL FALSE contacts) AUTO_OFF AUTOMode: Switch on (close the main BOOL FALSE contacts) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 105 REAL UNBAL_CUR_I_QC Quality code of UNBAL_CUR_I BYTE 16#80 UNBAL_CUR_I_OFF DR 130: Phase unbalance current OFF BOOL FALSE UNBAL_CUR_I_NA DR 130: Phase unbalance current not BOOL TRUE available Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 106 A current trip is acknowledged and reset BOOL FALSE DEL_TRIP Delete trip and event log BOOL FALSE R_VAL_MEM Reset all min./max. value memories (except BOOL FALSE temperatures) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 107 1 = Circuit breaker not ready BOOL FALSE QOFF 1 = Main contacts disconnected BOOL FALSE 1 = Main contacts closed BOOL FALSE QTRIP 1 = Circuit breaker has tripped BOOL FALSE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 108 DR 91: Number of earth fault trips (G) not BOOL TRUE available DIAG_WRN DR 92: Active warnings WORD DIAG_WRN_QC Quality code of DIAG_WRN BYTE 16#80 WRN_NO1 Warning number 1 WRN_NO2 Warning number 2 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 109 DR 94: Earth fault current REAL CUR_EARTH_F_QC Quality code of CUR_EARTH_F BYTE 16#80 CUR_EARTH_F_NA DR 94: Earth fault current not available BOOL TRUE DR 94: Frequency REAL Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 110 DR 129: Time lag class tR PS A not available BOOL TRUE IN_PRO_PARA_A DR 129: Instantaneous protection parameter REAL li PS A IN_PRO_PARA_A_QC Quality code of IN_PRO_PARA_A BYTE 16#80 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 111 PS A not available ZSS_ON DR 129: ZSI on / off BYTE 16#0 ZSS_ON_QC Quality code of ZSS_ON BYTE 16#80 ZSS_ON_OFF DR 129: ZSI on / off OFF BOOL FALSE Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 112 REAL current T_UNBAL_CUR_O_QC Quality code of T_UNBAL_CUR_O BYTE 16#80 T_CUR_DEM_O DR 130: Delay time for demand of the REAL current T_CUR_DEM_O_QC Quality code of T_CUR_DEM_O BYTE 16#80 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 113: Description Of Symbols And Faceplates

    Maximum phase current Faceplate The faceplate available is described in this chapter. The following views are available: Standard Measurements Diagnosis Maintenance with the tabs Maintenance 1 MAINTENANCE_1 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 114 "---". These measured values are therefore not indicated in the faceplates. The faceplates in the figures below are shown for direct connection of 3VL to the DP master system. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 115 CUR_L1 CUR_L2 CUR_L3 RES_MONERR QMON_ERR (10) MAINT (11) QLOC_OFF / ST_CB (12) CUR_MAX (13) ST_CB Figure 3-29 Faceplate for standard view not ready tripped Symbol for status Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 116 RESET Reset "Tripped" or "Local turn off" status CUR_L1 Current in phase L1 CUR_L2 Current in phase L2 CUR_L3 Current in phase L3 RES_MONERR Reset monitoring error Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 117 Description of blocks 3.3 Driver module DRV_3VL Measurements CUR_L2 CUR_N CUR_DEM_L2 CUR_DEM3 CUR_UNBAL CUR_DEM3PH CUR_EARTH_F CUR_DEM_L3 (10) CUR_DEM_L1 (11) CUR_L3 (12) CUR_L1 Figure 3-30 Faceplate for measurements view Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 118 Mean current value over the three phases CUR_EARTH_F Current which flows to earth Frequency Diagnosis WRN_NO1 WRN_NO2 WRN_NO3 WRN_NO4 WRN_NO5 WRN_NO6 WRN_NO7 WRN_NO8 Figure 3-31 Faceplate for diagnosis view Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 119 WRN_NO8 8th warning currently active Possible warnings Pretrip for L Overload Overload N-phase Load shedding warning Load restorage Phase unbalance current µP-Error Earth fault warning Over temperature Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 120 Number of switches caused by trips N_SC_TRP Number of short-circuit releases (SI) N_OVL_TRP Number of overload trips (L) N_EF_TRP Number of ground-fault trips (G) RD_DR91 Read maintenance information (data record 91) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 121 Reset all maintenance information and counters which can be reset ACK_TRIP A tripping operation currently active is acknowledged and reset DEL_TRIP Delete tripping and event log R_VAL_MEM Reset all min./max. value memories (apart from temperature) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 122 Ground-fault protection Ig1 PS A I2T_EFLT_PROT_A I2t characteristic for ground-fault protection PS A I2T_D_STRIP_A I2t characteristic for delayed ground-fault protection PS A OV_LD_N_A Overload protection neutral conductor IN PS A (WL) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 123 EARTH_FLT_CUR Type of ground fault detection STON_GFOFF ZSI short-circuit STOFF_GFON ZSI ground fault RD_DR69 Read ZSI parameter (data record 69) RD_DR129 Read protect. para (data record 129) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 124 Faceplate for ext. protect. para view Element (parameters) Meaning Display when 3VL is connected following Y-link PH_UNBL_CUR Current unbalance RD_DR128 Read ext. protect. para (data record 128) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 125 Delay time for over current T_CUR_GRD_I Delay time of current which flows to earth T_CUR_N_I Delay time for over current in neutral conductor T_UNBAL_CUR_I Delay time for phase imbalance Current Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 126 Message ("Overload warning present") is not output SUP_SP_EXCEED Message ("An active setpoint has been exceeded") is not output SUP_WRN Message ("There is currently a warning message present") is not output Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 127: Configuration Manual

    The "Open" contact is used to switch off the circuit breaker and controls the F1 switch-off solenoid. (The circuit breaker should be fitted with the "Shunt release suited to uninterrupted duty, 100 % ED") Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 128: Dc Voltage

    Configuration Manual 4.1 Interconnections on COM15 for 3WL 4.1.1 24V DC voltage Figure 4-1 COM15 interconnection at 24V DC voltage Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 129: Other Voltage Levels

    Configuration Manual 4.1 Interconnections on COM15 for 3WL 4.1.2 Other voltage levels Figure 4-2 COM15 interconnection at other voltage levels Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 130: Interconnections On Com10 For 3Vl

    Configuration Manual 4.2 Interconnections on COM10 for 3VL Interconnections on COM10 for 3VL 4.2.1 Connection for communication Figure 4-3 Connection for communication Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 131: Connection For Motorized Operating Mechanism

    Configuration Manual 4.2 Interconnections on COM10 for 3VL 4.2.2 Connection for motorized operating mechanism Figure 4-4 Connection for motorized operating mechanism Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 132: Connection On Com20 For 3Vl

    COM20 and a SENTRON VL including the LEDs and the PROFIBUS write protection DPWriteEnable. Figure 4-5 COM20 connection to SENTRON VL Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 133: Connecting The Optional Motorized Operating Mechanism To Com20

    Connection diagram for COM20 on motorized operating mechanism, SENTRON VL: Motor COM20 Power supply L2– X20.1 X20.2 SEO (ON) X20.3 SEO (OFF) X20.4 X20.5 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 134: Configuring A Measuring Point

    3WL device. Procedure: Select input -> right mouse -> Interconnection to -> Enter parameter button address... e.g. EW512. Figure 4-6 Driver block in CFC chart (not connected) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 135 ● Select "Generate module drivers" function when compiling the CFC chart: Figure 4-7 Compile program ● Or use Select chart folder -> right mouse button -> Generate module drivers…: Figure 4-8 Generate module driver Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 136: Figure 4-9 Driver Block In Cfc Chart Connected

    →The driver block connected by the module driver is supplied as the result: Figure 4-9 Driver block in CFC chart connected The PLC program has now been created. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 137: Connection To Wincc

    – in property dialog of WinCC display "Select Derive block icons from Plant View" (as of PCS 7 V7.0 this tick is set automatically) Figure 4-10 Basing the block icons on the plant hierarchy Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 138: Figure 4-11 Creating Block Icons Out Of Plant Hierarchy

    Plant hierarchy / Create / update block icons or Figure 4-11 Creating block icons out of plant hierarchy – Automatically create/update when compiling the OS Figure 4-12 Create block icons when compiling OS Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 139 Dynamic Wizard "Link picture with measuring point" Figure 4-13 Link picture component with measuring point The driver block is now fully integrated into WinCC. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 140 Configuration Manual 4.4 Configuring a measuring point Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 141: Technical Specifications

    The local data memory needed when calling the block in an execution level. This is limited depending on the CPU. If exceeded, you must check this in the CPU configuration and, if necessary, redistribute to OBs of the size actually needed. Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 142 SFC20 SFC21 DRV_3VL 1740 23050 / 20014 2414 / 1172 SFB35 SFB52 SFB53 SFC1 SFC6 SFC20 SFC21 DIA_WLVL 1742 1824 / 1472 322 / 94 SFC6 SFC51 Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...

  • Page 143: Technical Support

    If you require technical support or you have questions about the product, contact Technical Support. Utility Address, number Phone +49 (0)180-50-50-222 +49 (0)180-50-50-223 Internet (http://www.siemens.com/automation/service&support) Support request (www.siemens.com/lowvoltage/technical-assistance) Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 144 Technical support Library SENTRON 3WL / 3VL for SIMATIC PCS 7 Function Manual, 11/2008, A5E02316914A-01...
  • Page 146 Contact for all technical information: Technical Assistance Tel.: +49 (911) 895-5900 E-Mail: technical-assistance@siemens.com www.siemens.com/lowvoltage/technical- assistance Siemens AG Subject to change without prior notice Industry Sector Order No.: A5E02316914 Postfach 48 48 90327 NÜRNBERG © Siemens AG 2008 GERMANY www.siemens.com/automation...

This manual is also suitable for:

Library sentron 3vl

Table of Contents
