• The FCB camera is equipped with a CCD which adopts the all-pixel read-out method for all 330,000 effective picture elements “progressive scan” and the primary color filter, enabling use of square pixels. The adoption of this type of CCD enables the high resolution and high color reproduction of this camera.
Otherwise, you may get an electric shock or a fire may occur. Precautions In case of abnormal operation, contact your authorized Sony dealer or the store where you purchased the product. Phenomena specific to CCD image sensors The following phenomena that may appear in images are specific to CCD (Charge Coupled Device) image sensors.
Overview of Functions VISCA commands are the basis of camera control. Timing Chart As VISCA Command processing can only be carried out one time in a Vertical cycle, it takes the maximum 1V cycle time for an ACK/Completion to be returned. If the Command ACK/Completion communication time can be cut shorter than the1V cycle time, then every 1V cycle can receive a Command.
Page 7
Zoom The FCB camera employs an 18× optical zoom lens. Lens specifications: Optical 18×, f = 4.1 to 73.8 mm (F1.4 to F3.0) The horizontal angle of view is approximately 48 degrees (wide end) to 2.8 degrees (tele end). You can activate the zoom in the following two ways: •...
White Balance White Balance has the following modes, all of which can be set using VISCA Commands. • Auto White Balance Auto white balance obtains the proper color reproduction by automatically adjusting white balance to ensure a white object always looks white. This function computes the white balance value output using color information from the entire screen.
Page 9
AE – Iris Priority The iris can be set freely by the user to 18 steps between F1.4 and Close. The gain and shutter speed are set automatically according to the brightness of the subject. Data Setting value Data F1.4 F1.6 F2.0 F2.4...
Exposure Compensation Exposure compensation is a function which offsets the internal reference brightness level used in the AE mode by steps of 1.5 dB. Data Step Setting value 10.5 dB 9 dB 7.5 dB 6 dB 4.5 dB 3 dB 1.5 dB 0 dB –1...
Page 11
When ICR is ON There are threshold levels at which ICR is switched from ON to OFF. Usually, the 1st threshold level is used to switch ICR from ON to OFF. The following figure shows the process by which ICR is switched from ON to OFF.
Page 12
Digital Image Output Modes Three kinds of digital image output modes are available. Also, 30 fps and 25 fps modes are available for each of these digital image output modes. In total, six digital image output modes are supported. I/F mode Output SYNC 16bit...
Title Display The camera can be given a title containing up to 20 characters such as “ENTRANCE” or “LOBBY”. The position of the first character (horizontal, vertical) of the title, blinking state, and color can also be changed. Vposition Hposition 00: Does not blink Blink 01: Blinks...
Page 14
Privacy Zone Function Privacy Zone masking protects private objects and areas such as house windows, entrances, and exits which are within the camera’s range of vision but not subject to surveillance. Privacy zone masking can be masked on the monitor to protect privacy.
Page 15
Privacy Zone Setting Command List Command Set Command CAM_PrivacyZone SetMask Display SetMaskColor SetPanTiltAngle SetPTZMask Non_InterlockMask Grid On Grid Off CenterLineOn Privacy Zone Inquiry Command List Inquiry Command Command Packet Inquiry Packet CAM_Privacy 8x 09 04 77 FF DisplayInq CAM_PrivacyPan 8x 09 04 79 FF TiltInq CAM_Privacy 8x 09 04 7B mm FF y0 50 0p 0p 0p 0q 0q 0q 0r 0r...
Page 16
Parameters mm: Mask setting list Mask Name mm (Hex) Mask Name Mask_A Mask_M Mask_B Mask_N Mask_C Mask_O Mask_D Mask_P Mask_E Mask_Q Mask_F Mask_R Mask_G Mask_S Mask_H Mask_T Mask_I Mask_U Mask_J Mask_V Mask_K Mask_W Mask_L Mask_X Note The priority order of the mask display is in the sequence from A (highest) to X (lowest).
Page 17
Details of Setting Commands Set Mask Command: 8x 01 04 76 mm nn 0r 0r 0s 0s FF Parameters: Setting Mask See “mm: mask setting list” in “Parameters” on page 16. Selects new setting or resetting for the zone. See nn: Setting”...
Grid Use the grid displayed on the screen to set mask positions (see the figure below). Alarm Function This function instructs the camera to detect movement within the monitoring area and then send an alarm signal automatically. 14hex (20(10)) A High level signal is output when camera detects movement inside the monitoring area.
Page 19
ALARM Setting Command List Command Set Command CAM _ Alarm Set Mode Set Day Night Level VISCA Mode Code (pp) Details of Mode Set the internal focus position. When focus movement is detected, the detect signal is High. When focus goes back to the previous position, the detect signal is Low.
Page 20
Flowchart of 12 Modes Function Mode “00” Set the Focus Position Hysteresis. Focus moves outside of the hysteresis. High level signal output Focus goes back to the previous position. Low level signal output Set to the factory preset Alarm On Focus Position into memory AE moves Focus...
Page 21
Mode “01” Focus moves outside of the hysteresis. * Repeat this loop until Alarm off. Update the Focus position data. Alarm On AE moves. High level signal output AE does not move for a period of time. Low level signal output Basic Functions Focus Position into memory Hysteresis is set to the factory...
Page 22
Mode “02” Set the AE level Hysteresis. AE moves outside of the hysteresis. High level signal output AE goes back to the previous level. Low level signal output Set to the factory preset AE Level into memory Alarm On AE moves Bright AE Level High...
Page 23
Mode “03” * Repeat this loop until Alarm off. Alarm On AE moves. AE moves outside of the hysteresis. High level signal output AE does not move for a period of time. Low level signal output Update the AE level data Basic Functions AE level into memory Hysteresis is set to the factory...
Page 24
Details of Mode “01”/”03" Alarm ON Hysteresis Focus Pos AE Level Signal level Mode “04” High output result of mode “00” High output result of mode “02” T1: Reset interval timer (5sec) T2: Detect timer (2sec) T3: High level signal count timer (2sec) Reset Reset Reset...
Page 25
Mode “05” High output result of mode “00” High output result of mode “03” Mode “06” High output result of mode “01” High output result of mode “02” Mode “07” High output result of mode “01” High output result of mode “03” High output High output High output...
Page 26
Mode “08” High output result of mode “00” High output result of mode “02” High output Mode “09” High output result of mode “00” High output result of mode “03” High output Mode “0A” High output result of mode “01” High output result of mode “02”...
Page 27
Mode “0B” High output result of mode “01” High output result of mode “03” High output Day-Night Mode (Mode “0C”) Set the Day-Night Mode and the Day/ Night AE level. Alarm On AE move Brightness is higher than Day AE level. Low level signal output Bright AE level...
Eclipse When designing the housing, refer to the dimensional allowance as shown in the figure below. Spectral Sensitivity Characteristics Vibration Specifications Test Method (Random vibration) • Fix the camera at the four fixation points of the base using M2 screws. •...
Key Function Specifications Classification Name Function ZOOM WIDE Move ZOOM to WIDE side quickly. WIDE SLOW Move ZOOM to WIDE side slowly. TELE SLOW Move ZOOM to TELE side slowly. TELE FAST Move ZOOM to TELE side quickly. D-ZOOM DZOOM Turn on/off the mode for shifting from optical MAX to electronic ZOOM in combined mode.
Page 31
Classification Name Function FEATURE FREEZE Capture still image. Horizontal reversal REVERSE BLACK & Black-and-white output WHITE NEGA ART Negative art output MUTE Mute video output DISPLAY DISPLAY Display TITLE Title setting EXEC Confirm title/clock settings. UP/DOWN Data UP key (priority for AE mode, Bright, manual WB, title, and clock) DOWN Data DOWN key (priority for AE mode, Bright,...
Initial Settings, Custom Preset and Backup Initial settings for the various functions are indicated in the “Initial settings” column. The “Custom preset” column indicates whether the custom preset function can be used to store the settings. The function enables the stored settings to be recalled automatically when the camera is turned on.
Page 33
Mode/Position Title Display On/Off Title Setting Mask Setting Mask Display On/Off Mask Color Setting Alarm On/Off Alarm Mode Alarm Detect Level E-Flip On/Off Privacy Zone On/Off Privacy Zone Setting Key Lock On/Off Camera ID Note The number of times data can be written to EEPROM (by executing Custom Preset) is limited.
MALFUNCTION OR DAMAGE. THIS CONTROL PROTOCOL AND COMMAND LIST SHOULD BE USED WITH CAUTION. 1) VISCA is a protocol which controls consumer camcorders developed by Sony. “VISCA” is a trademark of Sony Corporation. Command List Overview of VISCA In VISCA the device outputting commands, for example, a computer, is called the controller.
Page 38
VISCA Communication Specifications VISCA Packet Structure The basic unit of VISCA communication is called a packet. The first byte of the packet is called the header and comprises the sender’s and receiver’s addresses. For example, the header of the packet sent to the FCB camera assigned address 1 from the controller (address 0) is hexadecimal 81H.
Page 39
Responses for Commands and Inquiries ACK message Returned by the FCB camera when it receives a command. No ACK message is returned for inquiries. Completion message Returned by the FCB camera when execution of commands or inquiries is completed. In the case of inquiry commands, it will contain reply data for the inquiry after the 3rd byte of the packet.
Page 40
Inquiry Packet Reply Packet Description 8X 09 00 02 FF Y0 50 GG GG GGGG = Vender ID HH HH JJ JJ (0020: Sony) KK FF HHHH = Model ID 0440 = FCB-PV480 JJJJ = ROM revision KK = Maximum socket # (02)
FCB Camera Commands Command List (1/4) Command Set Command AddressSet Broadcast IF_Clear Broadcast CommandCancel CAM_Power CAM_Zoom Stop Tele(Standard) Wide(Standard) Tele(Variable) Wide(Variable) Direct CAM_Focus Stop Far(Standard) Near(Standard) Far(Variable) Near(Variable) Direct Auto Focus Manual Focus Auto/Manual One Push Trigger Infinity Near Limit AF Sensitivity Normal CAM_AFMode...
Page 44
Command List (2/4) Command Set Command CAM_WB Auto Indoor Outdoor One Push WB Manual One Push Trigger CAM_RGain Reset Down Direct CAM_BGain Reset Down Direct CAM_AE Full Auto Manual Shutter Priority Iris Priority Bright CAM_SlowShutter Auto Manual CAM_Shutter Reset Down Direct CAM_Iris Reset...
Page 45
Command List (3/4) Command Set Command CAM_Aperture Reset Down Direct CAM_LR_Reverse CAM_Freeze CAM_PictureEffect B&W CAM_PictureFlip CAM_ICR CAM_AutoICR CAM_Memory Reset Recall CAM_CUSTOM Reset Recall CAM_MemSave Write CAM_Display On/Off CAM_Title Title Set1 Title Set2 Title Set3 Title Clear CAM_Mute On/Off a) Some models do not support Infrared Mode. Command Packet Comments 8x 01 04 02 00 FF...
Page 46
Command List (4/4) Command Set Command CAM_PrivacyZone SetMask Display SetMask Color SetPan TiltAngle SetPTZMask Non_InterlockMask GridOn GridOff CAM_KeyLock CAM_IDWrite CAM_ExternalLock Line Lock CAM_Alarm SetMode SetDayNightLevel Alarm (Reply) CAM_ContinuesZoomPosReply (Reply) CAM_ReplyIntervalTimeSet CAM_RegisterValue Command Packet Comments 8x 01 04 76 mm nn mm: Mask Settings 0r 0r 0s 0s FF nn 00: Modify, 01: New...
Page 49
Block Inquiry Command List Lens Control System Inquiry Commands ... Command Packet 8x 09 7E 7E 00 FF Byte Comments Destination Address Source Address 0 Completion Message (50h) Zoom Position (HH) Zoom Position (HL) Zoom Position (LH) Zoom Position (LL) Byte Comments Focus Near Limit (H)
Page 50
Camera Control System Inquiry Commands ... Command Packet 8x 09 7E 7E 01 FF Byte Comments Destination Address Source Address 0 Completion Message (50h) R Gain (H) R Gain (L) B Gain (H) B Gain (L) Byte Comments WB Mode Aperture Gain Exposure Mode Spot AE 1: On 0: Off...
Page 51
Other Inquiry Commands ... Command Packet 8x 09 7E 7E 02 FF Byte Comments Destination Address Source Address 0 Completion Message (50h) Auto ICR 1: On 0: Off Key Lock 1: On 0: Off Power 1:On 0:Off ICR 1: On 0: Off Freeze 1:On 0:Off LR Reverse 1:On 0:Off Privacy Zone 1: On 0: Off...
Page 52
Enlargement Function Query Command ... Command Packet 8x 09 7E 7E 03 FF Byte Comments Destination Address Source Address 0 Completion Message (50h) AF Activation Time (H) AF Activation Time (L) Byte Comments AF Interval Time (H) AF Interval Time (L) SpotAE Position (X) SpotAE Position (Y) Alarm (1: On, 0: Off)
Page 53
VISCA Command Setting Values Exposure Control (1/2) 30fps Shutter Speed 10000 6000 4000 3000 2000 1500 1000 Iris F1.4 F1.6 F2.0 F2.4 F2.8 F3.4 F4.0 F4.8 F5.6 F6.8 F8.0 F9.6 CLOSE Gain 25fps 10000 6000 3500 2500 1750 1250 1000 Command List 28 dB 26 dB...
Page 54
Exposure Control (2/2) IRIS Bright F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.4 F1.6 F2.0 F2.4 F2.8 F3.4 F4.0 F4.8 F5.6 F6.8 F8.0 F9.6 CLOSE Exposure Comp. –1 –2 –3 –4 –5 –6 –7 Zoom Ratio and Zoom Position (for reference)
Page 55
Mask Setting MASK set Mask_A Mask_B Mask_C Mask_D Mask_E Mask_F Mask_G Mask_H Mask_I Mask_J Mask_K Mask_L Mask_M Mask_N Mask_O Mask_P Mask_Q Mask_R Mask_S Mask_T Mask_U Mask_V Mask_W Mask_X Size of Mask Width (W) High (H) Mask of Offset H Position (X) V Position (Y) Mask Bit Mask...
Register Setting Register # Value VISCA Baud Rate Frame Rate Image Out mode Others AF Active time AF interval time Spot AE X table Spot AE Y table R Gain B Gain Aperture ICR ON t OFF Threshold Level Title Setting Vposition Hposition 00: Does not blink...
Image sensor type IT CCD (HAD) Picture elements Approx. 330K pixels (659 (H) × 494 (V)) Horizontal resolution VGA 640 × 480 Lens 18× zoom F= 4.1 mm (WIDE) to 73.8 mm (TELE), F1.4 to F3.0 Zoom movement speed Optical WIDE/Optical TELE 2.1 s ∞...
Page 58
Specifications Timing Charts DIGITAL Port Interface...
External Dimensions Front Within a depth of 3 mm ( or less form the top surface Bottom Within a depth of 3 mm ( less form the bottom surface Right side Within a depth of 3 mm in.) or less form the side Left side in.) in.) or...
Pin Assignment CN501 24P FFC (0.5mm) KYOCERA ELCO Co. 046240024006848+ Pin No. Name 16 bit data bus Level Signal Ground Digital Y-Out 0 0 - 3.3 Vp-p Digital Y-Out 1 0 - 3.3 Vp-p Digital Y-Out 2 0 - 3.3 Vp-p Digital Y-Out 3 0 - 3.3 Vp-p Digital Y-Out 4...
Page 63
CN403 12P FFC (0.5mm) KYOCERA ELCO Co. 086222012101848+ Pin No. Name Level KEY_AD0 Pull up to 3.0 V by 100 kohm KEY_AD1 Pull up to 3.0 V by 100 kohm KEY_AD2 Pull up to 3.0 V by 100 kohm KEY_AD3 Pull up to 3.0 V by 100 kohm KEY_AD4 Pull up to 3.0 V by 100 kohm...
