ADDENDUM TO
MC68341 Integrated Processor User's Manual
April 19, 1995
This addendum to the initial release of the MC68341UM/AD User's Manual provides corrections to the original
text, plus additional information not included in the original. This document and other information on this product
is maintained on the AESOP BBS, which can be reached at (800)843-3451 (from the US and Canada) or
(512)891-3650. Configure modem for up to 14.4Kbaud, 8 bits, 1 stop bit, and no parity. Terminal software
should support VT100 emulation. Internet access is provided by telneting to pirs.aus.sps.mot.com
[129.38.233.1] or through the World Wide Web at http://pirs.aus.sps.mot.com.
1. Signal Index
On page 2-4, Table 2-4, the QSPI serial clock QSCLK should be listed as an I/O signal. At the bottom of Table
2-5, FC3/DTC is an output-only signal.
2. Operand Alignment
On page 3-9, last paragraph, change the first two lines to: "The CPU32 restricts all operands (both data and
instructions) to be word-aligned. That is, word and long-word operands must be located on a word boundary."
Long-word operands do not have to be long-word aligned.
3. WE on Fast Termination
On page 3-17, Figure 3-6, UWE and LWE do not assert for fast termination writes.
4. Write Cycle Timing Waveforms
On page 3-25, the M68300 write cycle timing diagram (Figure 3-12) shows incorrect timing for DS, UWE, and
LWE. On page 3-28, the M68000 write cycle timing diagram (Figure 3-14) shows incorrect timing for AS68K,
CSx, UDS/LDS, and UWE/LWE. Replace these figures with the following corrected figures.
5. Additional Note on MBAR Decode
Add to the CPU Space Cycles description on page 3-31: The CPU space decode logic allocates the 256-byte
block from $3FF00-3FFFF to the SIM module. An internal 2-clock termination is provided by this initial decode
for any access to this range, but selection of specific registers depends on additional decode.
Accesses to the MBAR register at long word $3FF00 are internal only, and are only visible by enabling show
cycles. Users should directly access only the MBAR register, and use the LPSTOP instruction to generate the
LPSTOP broadcast access to $3FFFE. The remaining address range $3FF04-3FFFD is Motorola reserved and
should not be accessed.
This document contains information on a product under development. Motorola reserves the right to change or discontinue this product without notice.
© MOTOROLA, 1995
SEMICONDUCTOR PRODUCT INFORMATION
Order this document by
MC68341UMAD/AD
MC68341

Advertisement

Table of Contents
loading

Summary of Contents for Motorola MC68341

  • Page 1 LPSTOP broadcast access to $3FFFE. The remaining address range $3FF04-3FFFD is Motorola reserved and should not be accessed. This document contains information on a product under development. Motorola reserves the right to change or discontinue this product without notice. SEMICONDUCTOR PRODUCT INFORMATION...
  • Page 2 CLKOUT A31–A2 FC3–FC0 SIZ1 BYTE WORD SIZ0 AS68K UDS, LDS DSACK D15–D8 D7–D0 WORD WRITE BYTE WRITE BYTE WRITE Figure 3-12. M68300 Write Cycle timing MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 3 CLKOUT A31–A2 FC3–FC0 SIZ1 BYTE WORD SIZ0 AS68K DSACK D15–D8 D7–D0 WORD WRITE BYTE WRITE BYTE WRITE Figure 3-14. M68000 Write Cycle Timing MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 4: Interrupt Latency

    On page 3-42, Table 3-4: When HALT and BERR are asserted together in case #5 to force a retry of the current bus cycle, relative timing of HALT and BERR must be controlled to avoid inadvertently causing bus error ter- MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 5: External Reset

    VCC is high enough for the internal logic to begin operating. For crystal mode and external clock with VCO mode, after the VCO frequency has reached an initial MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 6 19. Internal IMB Arbitration On page 4-6, first paragraph, change the first sentence to read “There are eight arbitration levels for the various bus masters on the MC68341 to access the inter-module bus (IMB).” 20. Additional Note for External Clock Mode with PLL On page 4-9, Table 4-1, External Clock Mode with PLL: the PLL phase locks the CLKOUT falling edge to the falling edge of the EXTCLK input clock.
  • Page 7 58720 3801 7602 15204 1901 3801 15204 30409 60817 3932 7864 15729 1966 3932 15729 31457 62915 1016 4063 8126 16253 2032 4063 16253 32506 65012 1049 4194 8389 16777 2097 4194 16777 33554 67109 MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 8 11 Electrical Characteristics for CLKOUT and VCO frequency limits. 2. Any change to W or Y results in a change in the VCO frequency - the VCO should be allowed to relock if necessary. MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 9 Rev. 1 releases) did not show AS7 set. Code which was developed based on these manual revisions should be checked for this problem when porting to the MC68341 - this change should also be applied back to the MC68330 and/or MC68340.
  • Page 10 37. IPIPE Timing On page 5-88, Figure 5-29 shows the third IPIPE assertion low lasting for 1.5 CLKs - it actually asserts for an additional 0.5 CLKs. IPIPE transitions occur after the falling edge of CLKOUT. MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 11 DMA transfer with internal IMB arbitration. Specifically, an idle clock can follow 1) single address 2-clock transfers and 2) dual address transfers from memory to 2-clock devices. Arbitration is completely overlapped for all other cases. MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 12 50. Additional Note on DMA Interrupt Prioritization Add to the Interrupt Register description on page 6-31: When both DMA channels are programmed to the same interrupt level, channel 1 is higher priority than channel 2. MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 13 One method to extend the minimum CLKOUT frequency is to reduce the X1 frequency by powers of 2 as shown in the table below. The corresponding baud rates selected by the clock select register programming are MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 14 60. Typos in Timer Initialization Examples On pages 8-27 and 8-29, the Timer register offsets should be from the timer base address, not from the SIM41 base address. The correct equates for the Timer register offsets are: MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 15: Sram Interface

    61. MC68341 BSDL File An electronic copy of the BSDL file for the MC68341 is maintained on the AESOP BBS - refer to the beginning of this document for information on accessing AESOP. 62. Additional Note on Oscillator Layout Guidelines Add to the Processor Clock Circuitry (page 11-1) and Serial Interface (page 11-4) sections: In general, use short connections and place external oscillator components close to the processor.
  • Page 16 SIM, and must meet the tighter duty cycle requirements outlined for External Clock Mode Without PLL. 69. Clock Skew Notes 12-7, External Clock With PLL Mode, Clock Input to CLKOUT Skew: Clock skew is measured from the falling MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 17: Ordering Information

    In paragraph 3.2.8 page 3-6, change (D15–D0) to (D15–D8) and (D8–D0) to (D7–D0). 75. Figure 3-2 Change Note 1 to reference MC68341 instead of MC68340. 76. Figure 4-8 The Periodic Interrupt Control Register (PICR) and Periodic Interrupt Timing Register (PITR) should be 1 word instead of 2 bytes.
  • Page 18: Package Dimensions

    The timing diagrams reference as Figures 9-24 — 9-27 should be changes to 12-22–12-25. 81. Page 9-29, DT–Delay A value of 1 enable this bit and 0 disables it. 82. Package Dimensions The package dimension drawing on page 13-3 should be discarded and replaced with the following drawing. MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 19 Ç Ç Ç Ç Ç É É É Ç Ç Ç Ç Ç É É É Ç Ç Ç Ç Ç É É É DETAIL C –H– SECTION B–B TOP & BOTTOM –H– –C– DETAIL C Case 864A-03 MOTOROLA MC68341 USER’S MANUAL ADDENDUM...
  • Page 20 Motorola reserves the right to make changes without further notice to any products herein. Motorola makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does Motorola assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation consequential or incidental damages.
