- Page 1 All manuals and user guides at all-guides.com 30XR-A Professional Digital Multimeter Users Manual 99 Washington Street Melrose, MA 02176 Fax 781-665-0780 TestEquipmentDepot.com...
- Page 2 All manuals and user guides at all-guides.com 30XR-A MIN MAX HOLD CONTACT VOLTAGE MADE IN TAIWAN PATENTS PENDING www.amprobe.com 200m 200m 200k 200m 10 A 10 A 200m 1.5V 9V BATT 600V BATT 1.5V 300V BATT 9V 200mA FUSED 10A MAX...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com 30XR-A Digital Multimeter Contents Making Measurements ................2 Verify Instrument Operation..............2 Correcting an Overload (o) Indication W ..........2 Measuring DC Voltage .........See Figure ....2 Measuring AC Voltage .........See Figure ....2 Preparing for Current Measurements ............2 Measuring DC Current .........See Figure... -
Page 4: Making Measurements
All manuals and user guides at all-guides.com Symbols Used in this Manual Battery Refer to the manual Double insulated Dangerous Voltage Direct Current Earth Ground Alternating Current Audible tone Complies with EU directives Underwriters Laboratories, Inc Fuse Making Measurements Verify Instrument Operation Before attempting to make a measurement, verify that the instrument is operational and the battery is good. -
Page 5: Measuring Dc Current
All manuals and user guides at all-guides.com Measuring DC Current See Figure 1. Set the Range Switch to an appropriate A range. Select the highest range and work down if the current level is unknown. 2. Connect the Test Leads: Red to mA or 10 A, Black to COM. 3. -
Page 6: Measuring Ncv (Non-Contact Voltage)
Additional Features Input Lead Warning The 30XR-A emits a continuous tone to indicate that the user has placed the unit in a potentially dangerous configuration. Specifically, a test lead is in a current connector and the Range Switch is set to measure some other function. If, in this configuration, the DMM is connected to a voltage source, very high and potentially dangerous current could result. -
Page 7: Product Maintenance
Battery: 9 V NEDA mA Fuse: Fast Blow 250 mA/600 V (Amprobe FP375) ® To replace the 10 A fuse, remove the battery, remove the four rear-case screws, separate the case, remove the 10 A fuse cover, and remove and replace the 10 A fuse. -
Page 8: Warranty
EN61010-1: Cat II - 600V / Cat III - negative polarity indication. 300V; Class 2, Pollution degree II. Overrange: (OL) or (-OL) is displayed. The 30XR-A is recommended for use with local level power distribution, Zero: Automatic. appliances, portable equipment, etc,... - Page 9 All manuals and user guides at all-guides.com RESISTANCE (45 Hz – 500 Hz) AC VOLTS Ranges: 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, Ranges: 200 m, 2 V, 20 V, 200 V, 600 V 2 MΩ, 20 MΩ Accuracy: All ranges, ± (1.5 % rdg + Accuracy: 4 dgts) 200 Ω...
- Page 10 All manuals and user guides at all-guides.com 30XR-A MIN MAX HOLD CONTACT VOLTAGE 200m 200m 200k 200m 10 A 10 A 200m 1.5V 9V BATT 600V BATT 1.5V 300V BATT 9V 200mA FUSED 10A MAX 600V FUSED 600V 30XR-A MIN MAX...
- Page 11 All manuals and user guides at all-guides.com 30XR-A MIN MAX CONTACT HOLD VOLTAGE 200m 200m 200k 200m 10 A 10 A 200m 1.5V 9V BATT 600V BATT 1.5V 300V BATT 9V 200mA FUSED 10A MAX 600V 600V FUSED 600V 600V...
- Page 12 All manuals and user guides at all-guides.com 30XR-A MIN MAX CONTACT HOLD VOLTAGE 200m 200m 200k 200m 10 A 10 A 200m 1.5V 9V BATT 600V BATT 1.5V 300V BATT 9V 200mA FUSED 10A MAX 600V FUSED 600V 30XR-A MIN MAX...
- Page 13 All manuals and user guides at all-guides.com 30XR-A MIN MAX CONTACT HOLD VOLTAGE 200m 200m 200k 200m 10 A 10 A 200m 1.5V 9V BATT 600V BATT 1.5V 300V BATT 9V 200mA FUSED 10A MAX 600V 600V FUSED 600V 600V...
- Page 14 All manuals and user guides at all-guides.com BATT 30XR-A MIN MAX HOLD CONTACT VOLTAGE 200m 200m 200k 200m 10 A 10 A 200m 1.5V 9V BATT 600V BATT 1.5V 300V BATT 9V 200mA FUSED 10A MAX 600V FUSED 600V...
