Volvo XC60 2010 Wiring Diagram page 167

Connector
74/504:41-57 - 74/504B
74/504
57-pin natural
No. Engine compartment harness
41 74/9:7 Connector
42 74/301:20 Connector, Man
43 4/118C1:17 Headlamp Control Module
(HCM)
44 73/3021 Branching point
73/3023-1 Branching point
45 73/3022 Branching point
73/3024 Branching point
46 -
47 -
48 -
49 4/118C1:8 Headlamp Control Module
(HCM)
50 4/16C1:22 Brake control module (BCM)
51 4/16C1:29 Brake control module (BCM)
52-55 -
56 73/3019 Branching point
4/56C1:49 Central electronic module
(CEM)
57 73/3020 Branching point
4/56C1:50 Central electronic module
(CEM)
74/504B
2-pin red
No. Engine compartment harness
1 11A/4:2 Fuse, engine compartment
distribution box
2 11A/3:2 Fuse, engine compartment
distribution box
74/512:14
YE-RD
GY-BN 73/5055
YE-GN 74/512:9
74/511:3
BU-BK
GN-BK 74/511:4
- -
- -
-
-
74/512:10
GN-BN
VT-BN 7/164:3
GN-BU 7/164:5
-
-
GY-OG 73/5005
73/5009
73/5006
VT-OG
73/5010
RD-GY 73/5040
RD-GN 73/5075
TP39133202 XC60 2009
Floor harness
Connector
Branching point
Connector
Connector
Connector
Connector
Body sensor cluster stability
sensor (BSC)
Body sensor cluster stability
sensor (BSC)
Branching point
Branching point
Branching point
Branching point
Floor harness
Branching point
Branching point
YE-RD
GY-BN
YE-GN
BU-BK
GN-BK
-
-
-
GN-BN
VT-BN
GN-BU
-
GY-OG
VT-OG
RD-GY
RD-GN
167
