Volvo XC60 2010 Wiring Diagram page 164

Connector
74/418 RHD - 74/420
74/418 RHD
6-pin gray
No.
1 27/5C1:1 Forward looking camera
2 27/5C1:2 Forward looking camera
3 27/5C1:3 Forward looking camera
4 27/5C1:4 Forward looking camera
5 27/5C1:5 Forward looking camera
6 27/5C1:6 Forward looking camera
S 27/5C1:S Forward looking camera
74/419
2-pin blue
No. Dashboard harness
1 16/60C5:1 Phone module (PHM)
1S 16/60C5:1S Phone module (PHM)
74/420
5-pin gray
No. Dashboard harness
1 16/1C5:1 Integrated Audio Module (IAM)
2 16/1C5:2 Integrated Audio Module (IAM)
3 16/1C5:3 Integrated Audio Module (IAM)
4 16/1C5:4 Integrated Audio Module (IAM)
5 16/1C5:5 Integrated Audio Module (IAM)
Harness FLC
WH
BN
GN
PK
GY
YE
-
WH
-
TP39133202 XC60 2009
FLC adapter harness
4/80C2:1 Forward Sensing Module (FSM)
4/80C2:2 Forward Sensing Module (FSM)
4/80C2:3 Forward Sensing Module (FSM)
4/80C2:4 Forward Sensing Module (FSM)
4/80C2:5 Forward Sensing Module (FSM)
4/80C2:6 Forward Sensing Module (FSM)
4/80C2:S Forward Sensing Module (FSM)
Infotainment harness
16/47C1:1 Antenna GSM/GPS/RDAR
16/47C1:1S Antenna GSM/GPS/RDAR
Tunnel harness
17/42C1:1 USB-port)
RD
WH 17/42C1:2 USB-port
GN 17/42C1:3 USB-port
17/42C1:4 USB-port
BK
- 17/42C1:5 USB-port
WH
BN
GN
PK
GY
YE
-
WH
-
RD
WH
GN
BK
-
164
