Page 1 Owner's Manual Web Edition...
Page 3 In the USA: In Canada:...
Page 4 Contents 00 Introduction 01 Safety 02 Locks and alarm...
Page 5 Contents 03 Your driving environment 04 Comfort and driving pleasure 05 During your trip...
Page 6 Contents 06 Maintenance and 07 Index specifications...
Page 7 Contents...
Page 8 Introduction Important information About this manual Options and accessories NOTE WARNING WARNING Points to keep in mind...
Page 9 Introduction Important information Vehicle event data (Black box)
Page 10 Introduction Important warnings Driver distraction Accessory installation...
Page 11 Introduction Environment Volvo and the environment WARNING PROPOSITION 65 WARNING!
Page 14 01 Safety Occupant safety Volvo's concern for safety Occupant safety reminders...
Page 15 01 Safety Reporting safety defects Reporting safety defects in the U.S. Reporting safety defects in Canada...
Page 16 01 Safety Seat belts General information Adjusting the seat belt Seat belt pretensioners Buckling a seat belt The retractor will lock up as follows: When wearing the seat belt remember: Unbuckling the seat belt Seat belt maintenance WARNING...
Page 17 01 Safety Seat belts Seat belt reminder WARNING READ Seat belt reminder light in ceiling console READ READ regardless of whether or not Rear seats...
Page 18 01 Safety Seat belts Seat belt use during pregnancy Child seats...
Page 19 01 Safety Supplemental Restraint System (SRS) General information WARNING WARNING Automatic transmission: Warning symbols in the instrument panel I II...
Page 20 01 Safety Supplemental Restraint System (SRS) Front airbags The front airbag system Location of the passenger's side front airbag SRS AIRBAG WARNING...
Page 21 01 Safety Supplemental Restraint System (SRS) Front airbag deployment WARNING In Canada In the USA...
Page 22 01 Safety Supplemental Restraint System (SRS) Airbag decals NOTE Airbag decal on passenger's side dashboard Airbag decal on the far right end of the passeng- er's dashboard Airbag decal on the outside of both sun visors...
Page 23 01 Safety Supplemental Restraint System (SRS) WARNING WARNING...
Page 24 01 Safety Occupant Weight Sensor General information Occupant Weight Sensor (OWS) indicator light Disabling the passenger's side front airbag NOTE PASS. AIRBAG OFF SERVICE URGENT WARNING...
Page 25 WARNING Passeng- OWS indi- Passeng- er's seat cator light er's side occu- status front air- pancy sta- bag status 01 Safety Occupant Weight Sensor Modifications...
Page 26 01 Safety Occupant Weight Sensor In the USA WARNING WARNING In Canada...
Page 27 01 Safety Occupant Weight Sensor WARNING...
Page 28 01 Safety Side impact protection (SIPS) airbags General information Location of the side impact (SIPS) airbags (front seats only) SIPS airbag deployment SIPS decal on the front of the driver's door open- NOTE Components in the SIPS airbag system...
Page 29 01 Safety Side impact protection (SIPS) airbags WARNING...
Page 30 01 Safety Volvo Inflatable Curtain (VIC) General information WARNING WARNING both NOTE...
Page 31 01 Safety Whiplash Protection System – WHIPS General information Whiplash Protection System (WHIPS) – WARNING front seats only WARNING...
Page 32 01 Safety Whiplash Protection System – WHIPS WARNING WARNING...
Page 33 01 Safety Rollover Protection System (ROPS) WARNING...
Page 34 01 Safety Crash mode Driving after a collision SAFETY MODE SEE MANUAL NOTE WARNING SAFETY MODE SEE MANUAL SAFETY MODE SEE MANUAL Attempting to start the vehicle Moving the vehicle SAFETY MODE SEE MANUAL WARNING...
Page 35 01 Safety Child safety Children should be seated safely Canada...
Page 36 01 Safety Child safety WARNING Automatic Locking Retractor/ Emergency Locking Retractor (ALR/ ELR) When attaching the seat belt to a child seat: Volvo's recommendations Volvo has some very specific recommendations:...
Page 37 01 Safety Child restraint systems Child restraints Convertible seat Booster cushion Infant seat WARNING WARNING general infor- mation...
Page 38 01 Safety Child restraint systems WARNING...
Page 39 01 Safety Infant seats Securing an infant seat with a seat belt WARNING Positioning the seat belt through the infant seat Do not place the infant seat in the front passeng- WARNING er's seat NOTE Fasten the seat belt...
Page 40 01 Safety Infant seats Pull out the shoulder section of the seat belt Ensure that the seat is securely in place WARNING NOTE...
Page 41 01 Safety Convertible seats Securing a convertible seat with a seat WARNING belt Route the seat belt through the convertible seat WARNING Do not place the convertible seat in the front pas- senger's seat NOTE...
Page 42 01 Safety Convertible seats Fasten the seat belt Ensure that the seat is securely in place WARNING Pull out the shoulder section of the seat belt WARNING NOTE...
Page 43 01 Safety Booster cushions Securing a booster cushion Positioning the seat belt Position the child correctly on the booster cushion WARNING...
Page 44 01 Safety ISOFIX lower anchors Using the ISOFIX lower child seat anchors ISOFIX lower child restraint anchors To access the anchors NOTE Fasten the attachment correctly to the ISOFIX lower anchors WARNING...
Page 45 01 Safety Top tether anchors Child restraint anchorages WARNING NOTE Securing a child seat...
Page 46 01 Safety Child restraint registration and recalls Registering a child restraint...
Page 47 Integrated two-stage booster cushion* Correct seating position: child's head is below the head restraint and the shoulder belt is across the collarbone 01 Safety Integrated booster cushion Incorrect seating position: the child's head is above the head restraint and the shoulder belt is not across the collarbone Stage 1 Stage 2...
Page 48 01 Safety Integrated booster cushion Using an integrated booster cushion Stage 1 Stage 2...
Page 49 Stowing the two-stage integrated booster cushion NOTE NOTE CAUTION 01 Safety Integrated booster cushion WARNING...
Page 50 01 Safety Child safety locks Child safety locks Manual child safety locks – rear doors Power child safety locks* With the function activated: NOTE WARNING...
Page 51 01 Safety...
Page 54: Locks And Alarm
02 Locks and alarm Remote key and key blade Introduction NOTE WARNING Detachable key blade Loss of a remote key settings Car key memory Number of keys Key memory – door mirrors and driver's seat Car settings key memory Seat & mirror positions...
Page 55 Confirmation when locking/unlocking the vehicle NOTE Car settings Light settings Lock confirmation, light, Car settings Light settings Unlock confirmation, light Immobilizer (start inhibitor) 02 Locks and alarm Remote key and key blade Message Meaning Key error Reinsert Car key Not found Immobilizer See manual CAUTION...
Page 56 02 Locks and alarm Remote key and key blade Replacing the battery in the remote key Replace car key battery NOTE Common functions – Remote key/ Personal Car Communicator (PCC) Remote key Personal Car Communicator (PCC)* Buttons on the remote Lock Unlock Car settings...
Page 57 Unlock tailgate NOTE Panic alarm Range NOTE 02 Locks and alarm Remote key and key blade Functions – PCC Using the information button...
Page 58 02 Locks and alarm Remote key and key blade NOTE Range NOTE Outside of the PCC´s range NOTE Heartbeat Sensor NOTE Keyless drive...
Page 59 Detachable key blade Unlocking the doors with the detached key blade NOTE To disable the alarm: Locking the doors with the detached key blade Removing the key blade Reinserting the key blade in the remote 02 Locks and alarm Remote key and key blade Replacing batteries in the remote key/...
Page 60 02 Locks and alarm Remote key and key blade Battery type CR 2430, 3 V (one battery in the remote key, two batteries in the PCC) Opening the remote key/PCC NOTE Replacing the batteries CAUTION Remote key (one battery) PCC (two batteries) Re-assembling the remote key –...
Page 61 Keyless drive (models with Personal Car Communicator only) Keyless locking and unlocking Range of the keyless drive remote key–5 ft (1.5 meters) NOTE Unlocking the vehicle Car settings Lock settings Keyless entry NOTE 02 Locks and alarm Keyless drive Locking the vehicle NOTE Keyless drive remote key and driver's seat/door mirror memory...
Page 62 02 Locks and alarm Keyless drive NOTE CAUTION Keyless drive information messages Location of the keyless drive antennas READ...
Page 63 02 Locks and alarm Keyless drive WARNING...
Page 64 02 Locks and alarm Locks Locking and unlocking the vehicle From outside the vehicle NOTE From inside the vehicle Unlocking ± Locking ± Automatic relocking Automatic locking Car settings Lock settings Doors automatic lock Glove compartment...
Page 65 Locking/unlocking the tailgate Tailgate unlock button on the remote key Unlocking the tailgate with the remote ± NOTE Locking the tailgate with the remote key ± 02 Locks and alarm Locks Unlocking the tailgate from the passenger compartment ± NOTE...
Page 66 02 Locks and alarm Alarm The alarm system Arming the alarm NOTE ± Car settings Lock settings The alarm indicator light Keyless entry...
Page 67 Disarming the alarm ± Turning off (stopping) the alarm Other alarm-related functions Automatic re-arming Audible/visual alarm signal Remote key not functioning Reduced alarm function Turning off the accessory alarm sensors ENTER MENU EXIT 02 Locks and alarm Alarm Car settings Reduced guard Enter Activate once...
Page 68 02 Locks and alarm Alarm ENTER Full guard EXIT...
Page 69 02 Locks and alarm...
Page 72: Your Driving Environment
03 Your driving environment Instruments and controls Instrument overview...
Page 73 03 Your driving environment Instruments and controls Information displays Function Page Function Page Information displays in the instrument panel...
Page 74 03 Your driving environment Instruments and controls Gauges Gauges in the instrument panel Indicator, information, and warning symbols Indicator and warning symbols Function check Indicator and information symbols Symbol Description...
Page 75 03 Your driving environment Instruments and controls Rear fog light Symbol Description Stability system Fault in the Active Bending Light Anti-lock Brake System (ABS) (ABL) system warning light Tire pressure monitoring system (TPMS)* Malfunction Indicator Light Low fuel level Information symbol READ...
Page 76 03 Your driving environment Instruments and controls High beam indicator Left turn signal indicator Right turn signal indicator NOTE Indicator and warning symbols Symbol Description Symbol Description Low oil pressure Parking brake applied NOTE Airbags – SRS Seat belt reminder Generator not charging Engine temperature...
Page 77 HIGH ENGINE TEMP – SLOW DOWN HIGH ENGINE TEMP – STOP ENGINE COOLANT LEVEL LOW Fault in brake system 03 Your driving environment WARNING NOT DRIVE Warning symbol Instruments and controls READ READ Reminder – doors not closed...
Page 78 03 Your driving environment Instruments and controls Trip odometers Trip odometers and reset button Clock Clock and setting control...
Page 79 Inserting and removing the remote key Ignition slot with remote key and START/STOP ENGINE button. Inserting the remote key CAUTION Removing the remote key 03 Your driving environment P (Park) Ignition modes Posi- Function tion Ignition modes NOTE Ignition mode 0 ±...
Page 80 03 Your driving environment Ignition modes Functions with timer POWER NOTE POWER...
Page 81 03 Your driving environment Seats Front seats WARNING WARNING Folding the front seat backrest...
Page 82 03 Your driving environment Seats Power seat* Operation NOTE Seat with memory function* Programming the memory To move the seat and mirrors to the position that they were in when a button was pro- grammed: ± NOTE...
Page 83 Remote keyless entry system and the driver's seat Automatic seat adjustment 03 Your driving environment NOTE Car key memory Seat & mirror positions Emergency stop Seats WARNING Heated seats*...
Page 84 03 Your driving environment Seats Rear seats WARNING Folding down the rear seat backrests NOTE...
Page 85 03 Your driving environment Seats Rear center head restraint Manually lowering the rear seat's outboard head restraints WARNING NOTE...
Page 86 03 Your driving environment Seats WARNING...
Page 87 Adjusting Adjusting the steering wheel 03 Your driving environment WARNING Keypads Keypads in the steering wheel Steering wheel Horn Horn ±...
Page 88 03 Your driving environment Lighting Lighting panel Overview, light switches Instrument lighting High/low beam headlights Headlight switch and lever Daytime running lights/no high beams Parking lights Low beams Low beams NOTE High beam flash ± High/low beam headlights Continuous high beams...
Page 89 Active Bending Lights (ABL)* Headlight pattern with the Active Bending Light function deactivated (left) and activated (right) Car settings Light settings Active bi xenon lights NOTE 03 Your driving environment Symbol Display Explana- tion Headlamp failure Service required Lighting Parking lights Headlight control in position for parking lights...
Page 90 03 Your driving environment Lighting Brake lights Emergency brake lights (EBL) Front fog lights Button for front fog lights ± NOTE Rear fog light Button for rear fog light ±...
Page 91 NOTE Hazard warning flashers ± 03 Your driving environment NOTE Turn signals Turn signals When changing lanes Lighting When turning NOTE...
Page 92 03 Your driving environment Lighting Interior lighting, front Light switches, front roof lighting Interior lighting, rear Rear reading lights Rear reading lights (models with the optional lami- nated panoramic roof) Courtesy lights/door step lighting* Glove compartment lighting Overhead courtesy lighting...
Page 93 Home safe lighting Car settings Light settings Home safe lighting 03 Your driving environment Approach lighting Car settings Light settings Approach lighting Lighting...
Page 94 03 Your driving environment Wipers and washers Windshield wipers/washers Windshield wipers and washers CAUTION Windshield wipers off Single sweep Intermittent wiping Continuous wiping Rain sensor* NOTE Activating and setting the sensitivity Deactivating...
Page 95 CAUTION Windshield washing Washing function 03 Your driving environment Heated washer nozzles* High-pressure headlight washing* Low/high beam headlights on. Parking lights on. CAUTION NOTE Wipers and washers Tailgate wiper/washer Tailgate wiper and reverse gear...
Page 96 03 Your driving environment Wipers and washers NOTE IR-reflecting windshield* Section of the windshield where the IR-coating is not applied...
Page 97 Power windows Driver's door control panel WARNING 03 Your driving environment Operating Operating the power windows Power windows NOTE Manual up/down ± Auto up/down ± Resetting...
Page 98 03 Your driving environment Power windows Laminated glass*...
Page 99 Power door mirrors Door mirror controls Adjusting WARNING 03 Your driving environment Retractable power door mirrors* Storing the position* Car key memory Seat & mirror positions Tilting the door mirror when parking* Mirrors NOTE Automatic retraction when locking Car settings Retract mirrors when locking Resetting to neutral...
Page 100 03 Your driving environment Mirrors Home safe and approach lighting Rear window and door mirror defrosters Climate settings Auto. rear defroster Interior rearview mirror Auto-dim function...
Page 101 03 Your driving environment Laminated panoramic roof* Introduction CAUTION WARNING Operation Automatic operation second Quick open/close...
Page 102 03 Your driving environment Laminated panoramic roof* Open Close Manual operation Opening the sun shade Opening the rear edge of the laminated panoramic roof second Opening the front glass section third NOTE Tilt position Tilt position, raised at the rear edge...
Page 103 03 Your driving environment HomeLink® Wireless Control System* Introduction Programming HomeLink WARNING NOTE...
Page 104 03 Your driving environment HomeLink® Wireless Control System* NOTE press, hold for five seconds and release stays on con- stantly, programming is complete rapidly for two seconds and then turns to a con- stant light continue with “Program- ming” steps 4-6 Gate Operator/Canadian Programming replace “Programming HomeLink”...
Page 105 03 Your driving environment HomeLink® Wireless Control System* Erasing HomeLink Buttons NOTE Reprogramming a Single HomeLink Button DO NOT...
Page 106 03 Your driving environment Starting the engine Start Ignition switch with remote key inserted ( see page 79 for more information on ignition modes) WARNING START/STOP ENGINE NOTE Keyless drive...
Page 107 03 Your driving environment Starting the engine WARNING WARNING NOTE Keylock:...
Page 108 03 Your driving environment Starting the engine Switching off the engine CAUTION START/ STOP ENGINE Jump starting Connecting the jumper cables...
Page 109 03 Your driving environment Starting the engine WARNING WARNING PROPOSITION 65 WARNING! CAUTION...
Page 110 03 Your driving environment Transmission Automatic transmission Shiftgate positions R N D Park position (P) Keylock Shiftlock CAUTION Reverse (R) Neutral position (N) Drive (D) Sport (S)
Page 111 Geartronic–manual shifting NOTE While driving 03 Your driving environment Shiftlock – Neutral (N) Geartronic–starting on slippery surfaces Transmission Shiftlock override...
Page 112 03 Your driving environment Transmission NOTE AWD disabled Service required All Wheel Drive – AWD...
Page 113 Brake system NOTE WARNING DO NOT DRIVE 03 Your driving environment Power brakes function only when the engine is running Water on brake discs and brake pads affects braking Severe strain on the brake system Brakes Anti-lock braking system Cleaning the brake discs...
Page 114 03 Your driving environment Brakes Symbols in the instrument panel NOTE Symbol Specification Emergency Brake Assistance WARNING DO NOT DRIVE...
Page 115 03 Your driving environment Hill Descent Control (HDC) Introduction Function Using HDC WARNING first reverse NOTE...
Page 116 03 Your driving environment Hill Descent Control (HDC) NOTE...
Page 117 Electric parking brake NOTE Low battery voltage 03 Your driving environment Applying the electric parking brake Parking brake control Parking brake NOTE Parking on a hill...
Page 118 03 Your driving environment Parking brake Releasing the electric parking brake Parking brake control Manual release Vehicles with Keyless drive* START/STOP ENGINE Automatic release NOTE Heavy load uphill Symbols Symbol Specification Messages Parking brake not fully released...
Page 119 03 Your driving environment Parking brake Parking brake not applied Parking brake Service required WARNING...
Page 122: Comfort And Driving Pleasure
04 Comfort and driving pleasure Menus and messages Center console Center console controls Center console with information display and con- trols for menus MENU EXIT ENTER 1–9 Steering wheel keypad ENTER EXIT Search paths Car settings Lock settings MENU Menu ENTER Submenu ENTER...
Page 123 Climate settings Reset climate settings Main menu AM HD radio Audio settings 04 Comfort and driving pleasure Main menu FM HD radio FM settings Audio settings Main menu CD Random CD settings Audio settings Main menu AUX Volume, AUX input Audio settings Menus and messages Main menu USB...
Page 124 04 Comfort and driving pleasure Menus and messages Phone settings Main instrument panel Information display and menu controls READ RESET READ Menu overview Driving distance on current fuel reserve Average Instantaneous: Average speed Current speed in mph (Canadian models only) DSTC Message READ...
Page 125 Message Description Service urgent Service required See manual Book time for maintenance Time for regular maintenance 04 Comfort and driving pleasure Message Description Maintenance over- Temporarily OFF Power save mode Menus and messages...
Page 126 04 Comfort and driving pleasure Climate system Introduction Air conditioning NOTE Sensor location NOTE NOTE Side windows and laminated panoramic roof Fog on the inside of the windows Temporary shut-off of the air conditioning Ice and snow Climate system maintenance Refrigerant Passenger compartment filter...
Page 127 NOTE Interior Air Quality System (IAQS) NOTE 04 Comfort and driving pleasure Menu settings Air distribution Climate system AUTO Air vents in the dashboard...
Page 128 04 Comfort and driving pleasure Climate system Air vents in the door pillars Electronic climate control, ECC Auto A/C ON OFF Blower control AUTO NOTE Heated front seats*...
Page 129 Heated rear seats* Air distribution 04 Comfort and driving pleasure Auto AUTO AUTO CLIMATE Climate settings Automatic blower adjust Low Normal High NOTE Climate system Temperature control NOTE A/C – ON/OFF...
Page 130 04 Comfort and driving pleasure Climate system Defroster Recirculation/air quality system Recirculation Timer Climate control settings Recirculation timer NOTE Interior Air Quality System–IAQS* AUTO Activating the air quality sensor...
Page 131 04 Comfort and driving pleasure Climate system NOTE Air distribution table Air distribution Air distribution...
Page 132 04 Comfort and driving pleasure Climate system Air distribution Air distribution...
Page 133 04 Comfort and driving pleasure Audio system Introduction Overview Steering wheel keypad POWER...
Page 134 04 Comfort and driving pleasure Audio system Audio functions Center console, controls for audio functions AM FM Audio volume and automatic volume control Audio settings Auto volume control External audio source audio volume MODE Volume, AUX input Sound settings Bass Treble Fader Balance...
Page 135 Equalizer Audio settings Equalizer Front Equalizer Rear ENTER EXIT Sound stage Audio settings Soundstage Optimal sound reproduction 04 Comfort and driving pleasure Bass Treble Equalizer Radio functions Center console, controls for radio functions Audio system Automatic tuning Manual tuning TUNING Preset stations Manually storing preset stations...
Page 136 04 Comfort and driving pleasure Audio system Channel stored Automatically storing preset stations AUTO Autostoring… Autostoring… Auto EXIT AUTO AUTO Auto Scan NOTE SCAN SCAN SCAN EXIT Radio text Radio text USB/iPod connector* AUX and USB sockets in the storage compartment between the front seats MODE iPod...
Page 137 LOADING ENTER ENTER 04 Comfort and driving pleasure NOTE USB flash drive NOTE MP3 player Audio system iPod NOTE Rear control panel with headphones socket*...
Page 138 04 Comfort and driving pleasure Audio system Volume MODE Activating/deactivating MODE MODE Scroll/search forward and backward Limitations HD Radio reception (U.S. models only) Introduction Display when the radio is receiving an HD Radio broadcast NOTE...
Page 139 Benefits of digital broadcasting 04 Comfort and driving pleasure How HD broadcasting works Limitations Main channel vs. sub-channels (FM only) Reception coverage area Audio system Analogue to digital/digital to analogue blending NOTE The above items are dependant on the broadcaster's equipment settings and do not indicate a fault in the vehicle's radio receiver or antenna systems...
Page 140 04 Comfort and driving pleasure Audio system Switching HD on or off MENU ENTER Sub-channels Example of an HD Radio station with sub-channels Selecting sub-channels NOTE sub-chan- No HD reception 6 seconds...
Page 141 No HD reception Sirius satellite radio* Listening to satellite radio NOTE Selecting Sirius radio mode Power MODE 04 Comfort and driving pleasure Activating Sirius radio AUTO UPDATING SUBSCRIPTION SIRIUS ID Selecting a channel category ENTER Audio system ENTER NOTE Selecting a channel...
Page 142 04 Comfort and driving pleasure Audio system NOTE Direct channel entry MENU Direct channel entry ENTER Scanning Storing a channel long short Song Seek and Song Memory Song Seek Song Memory Song Seek Song Memory Song memory MENU Add song to song mem. ENTER NOTE Song seek...
Page 143 Radio text AUTO Advanced settings MENU Advanced Sirius settings WARNING 04 Comfort and driving pleasure Skip options Skipping a channel CHANNEL SKIP LIST ENTER ENTER ENTER Unskip all channels Temp. unskip all ch. Channel lock Audio system NOTE Locking a channel: Sirius ID LOCK OPTIONS ENTER...
Page 144 04 Comfort and driving pleasure Audio system Temp. unlock all ch. CHANGE CODE CHANGE CODE ENTER ENTER ENTER ENTER WRONG CODE! If you have forgotten the access code: SIRIUS ID ENTER ENTER SIRIUS ID CD functions Center console, controls for CD functions Playing a CD (CD player Playing a CD (CD changer) 1 –...
Page 145 NOTE Pause Sound files NOTE 04 Comfort and driving pleasure Navigating the disc and playing tracks ENTER ENTER Fast-forward/change CD tracks and sound files TUNING Scan CD SCAN Audio system EXIT SCAN Random NOTE RANDOM RND ALL RANDOM FOLDER CD player Random Random Folder...
Page 146 04 Comfort and driving pleasure Audio system CD changer Random Single disc Random All discs discs Random Folder Disc text CD settings Disc text...
Page 147 Introduction System overview ® Bluetooth hands-free 04 Comfort and driving pleasure Bluetooth NOTE WARNING ® hands-free connection ® Bluetooth functions in the center console control panel VOLUME PHONE EXIT ENTER...
Page 148 04 Comfort and driving pleasure ® Bluetooth hands-free connection PHONE Getting started My Car PHONE Add phone Activating/deactivating PHONE My Car TELEPHONE Add phone Synchronising PHONE My Car Connecting cell phones Making a call TELEPHONE PHONE PHONE...
Page 149 ENTER. EXIT. Disconnecting the cell phone PHONE NOTE 04 Comfort and driving pleasure Handling calls Incoming calls ± ENTER ± EXIT Automatic answer Phone settings Call options Automatic answer Call settings MENU ENTER Microphone off Transfer call to mobile Phone book ®...
Page 150 04 Comfort and driving pleasure ® Bluetooth hands-free connection Ringing volume Phone settings Sounds and volume Ring volume Ringing tones Phone settings Sounds and volume Ring signal Ring signal 1,2,3... NOTE Phone settings Sounds and volume Ring signal Use mobile phone signal More information about registering and connecting cell phones...
Page 151 Searching for contacts Phone book Search ENTER ENTER. ENTER Voice control ENTER. Voice mail number Phone settings Call options Voice mail number 04 Comfort and driving pleasure Call lists ENTER Call register NOTE Entering text EXIT EXIT ® Bluetooth hands-free connection Button Function .1-? ! , : "...
Page 152 04 Comfort and driving pleasure ® Bluetooth hands-free connection ® Bluetooth menus Missed calls Received calls Dialed calls Phone book Bluetooth... Phone settings...
Page 153 Introduction Information display and controls READ RESET 04 Comfort and driving pleasure Functions NOTE READ Average speed RESET Current speed in mph (Canadian models only) Current speed in km/h (U.S. models only) Current fuel consumption (Instantaneous) Trip computer ---- Average fuel consumption RESET Driving distance on current fuel reserve ---- miles to empty tank...
Page 154 04 Comfort and driving pleasure Trip computer...
Page 155 Operation Rearview mirror with compass. Calibration 04 Comfort and driving pleasure NOTE Compass Selecting a magnetic zone Magnetic zones.
Page 156 04 Comfort and driving pleasure Stability system Introduction CAUTION Traction control (TC) Active Yaw Control (AYC) Spin control (SC) WARNING Operation Temporarily switching off Spin control DSTC RESET DSTC SPIN CONTROL ON or Messages in the information display DSTC Temporarily OFF DSTC Service required Symbols in the instrument panel...
Page 157 04 Comfort and driving pleasure Stability system WARNING...
Page 158 04 Comfort and driving pleasure Active chassis system–Four C Active chassis (Four C)* Comfort Sport Advanced Operation Chassis settings Speed-dependent steering force* settings Steering force level NOTE...
Page 159 Operation Steering wheel-mounted controls and display Engaging the cruise control function ± CRUISE 04 Comfort and driving pleasure (---) mph NOTE Setting a speed NOTE Adjusting the set speed Cruise control NOTE Automatic deactivation temporarily...
Page 160 04 Comfort and driving pleasure Cruise control Temporary deactivation Resume set speed WARNING Deactivation CRUISE, WARNING...
Page 161 Introduction Collision warning Brake support Auto-brake WARNING 04 Comfort and driving pleasure Collision warning with Auto-brake* WARNING Function Function overview Collision warning Brake support...
Page 162 04 Comfort and driving pleasure Collision warning with Auto-brake* Auto-brake WARNING NOTE Operation On and off Car settings Collision warning settings Activating/deactivating warning signals Car settings Collision warning settings Warning sound Setting a warning distance Long, Normal Short settings Collision warning settings Warning distance Long Normal.
Page 163 04 Comfort and driving pleasure Collision warning with Auto-brake* Limitations WARNING NOTE The camera’s limitations NOTE NOTE...
Page 164 04 Comfort and driving pleasure Collision warning with Auto-brake* WARNING Cause Fault tracing and actions Windshield sensors blocked Action...
Page 165 04 Comfort and driving pleasure Collision warning with Auto-brake* Cause Action Symbols and messages in the display Symbol Message Description Collision warn. Collision warn. Unavailable Auto braking was activated Camera blocked See manual...
Page 166 04 Comfort and driving pleasure Collision warning with Auto-brake* Symbol Message Radar blocked See manual Collision warn. Service required Description...
Page 167 04 Comfort and driving pleasure City Safety™ Introduction WARNING difference in speed...
Page 168 04 Comfort and driving pleasure City Safety™ Function Location of the laser sensor in the windshield NOTE Using City Safety™ NOTE On and Off Display and turn signal lever RESET...
Page 169 04 Comfort and driving pleasure City Safety™ City Safety RESET Limitations NOTE WARNING RESET Vehicles not equipped with keyless Troubleshooting drive: Windshield sensors blocked START/STOP ENGINE Vehicles equipped with the optional keyless drive: START/STOP ENGINE START/STOP ENGINE...
Page 170 04 Comfort and driving pleasure City Safety™ The laser sensor CAUTION Cause Action...
Page 171 04 Comfort and driving pleasure City Safety™ Symbols and messages in the display WARNING READ NOTE WARNING...
Page 172 04 Comfort and driving pleasure City Safety™ Symbol Message Meaning/action required Auto Braking by City Safety Windshield sensors blocked City Safety Service required City Safety ON/OFF City Safety Unavailable Unavailable City Safety Unavailable...
Page 173 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* Introduction Function WARNING WARNING Function overview...
Page 174 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* WARNING WARNING WARNING Cruise Control Unavailable WARNING Warning light-driver braking required NOTE WARNING...
Page 175 Operation Controls and display Engaging the cruise control function 04 Comfort and driving pleasure Setting a speed NOTE Adjusting the set speed Adaptive Cruise Control (ACC)* NOTE Cruise Control Unavailable Setting a time interval...
Page 176 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* WARNING Deactivating and resuming settings WARNING Deactivation due to action by the driver NOTE Automatic deactivation Cruise Control Canceled The radar sensor and its limitations WARNING...
Page 177 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* NOTE Fault tracing and actions Radar blocked See manual WARNING Radar sensor field of vision (gray) Cause Action...
Page 178 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* Cause Symbols and messages in the display Symbol Message Turn on DSTC to enable Cruise Cruise control canceled Cruise control unavailable Action Description...
Page 179 04 Comfort and driving pleasure Adaptive Cruise Control (ACC)* Symbol Message Description Radar blocked See manual Cruise control Service required...
Page 180 04 Comfort and driving pleasure Distance alert Introduction NOTE WARNING Operation ± Setting a time interval ± No. of bars Approx. time interval (in seconds)
Page 181 04 Comfort and driving pleasure Distance alert Limitations WARNING NOTE NOTE WARNING Symbol Message Description...
Page 182 04 Comfort and driving pleasure Distance alert Symbol Message Description Radar blocked See manual Collision warn. Service required...
Page 183 Introduction Driver Alert Control (DAC) Lane Departure Warning (LDW) WARNING 04 Comfort and driving pleasure Driver Alert Control (DAC)–general information NOTE Driver Alert System* WARNING Limitations...
Page 184 04 Comfort and driving pleasure Driver Alert System* Operating DAC Driver Alert Off, Unavailable [-----] READ Activating DAC settings Driver Alert WARNING...
Page 185 04 Comfort and driving pleasure Driver Alert System* Symbols and messages in the display Symbol Message Description Driver Alert Driver Alert Unavailable Driver Alert Driver Alert Time for a break Camera blocked See manual Driver Alert Sys Service required...
Page 186 04 Comfort and driving pleasure Driver Alert System* Lane Departure Warning (LDW)– general information Increased sensitivity Operation and function Lane Depart Warn Unavailable Lane Depart Warn Available Lane Depart Warn Unavailable No warning signal WARNING...
Page 187 Symbols and messages in the display Symbol Message Lane departure warning On/Off Lane Depart Warn Available Lane Depart Warn Unavailable Camera blocked See manual Driver Alert Sys Service required Settings Car settings Lane Departure Warning On at startup 04 Comfort and driving pleasure Description Increased sensitivity Driver Alert System*...
Page 188 04 Comfort and driving pleasure Park assist* Introduction WARNING Function Park assist button Activating/deactivating ± NOTE...
Page 189 Signals from the park assist system Active Active Active Views in the display Visual indicator 04 Comfort and driving pleasure Audible signal Park assist* Rear park assist NOTE...
Page 190 04 Comfort and driving pleasure Park assist* Front park assist Faults in the system Park Assist syst Service required CAUTION Cleaning the sensors Location of the front sensors Location of the rear sensors NOTE...
Page 191 Introduction NOTE WARNING 04 Comfort and driving pleasure Function WARNING Park Assist Camera (PAC)* Ambient lighting conditions NOTE Using PAC Activation Automatic Parking camera settings...
Page 192 04 Comfort and driving pleasure Park Assist Camera (PAC)* Deactivation Guiding lines NOTE vehicle WARNING Sidelines Intersecting lines Yellow Vehicles equipped with Park Assist...
Page 193 Marker (color) Distance to object Settings MENU Main menu Car settings Parking camera settings Park Assist lines Distance information 04 Comfort and driving pleasure Activating the system Automatic Limitations NOTE Keep in mind Park Assist Camera (PAC)*...
Page 194 04 Comfort and driving pleasure Blind Spot Information System* Introduction CAUTION WARNING NOTE Areas monitored by BLIS Distance A = approx. 31 ft. (9.5 meters), Distance B = approx. 10 ft. (3 meters)
Page 195 04 Comfort and driving pleasure Blind Spot Information System* When does BLIS function Darkness WARNING headlights When you pass another vehicle: When you are passed by another vehicle: WARNING How BLIS functions in daylight and darkness Daylight shape...
Page 196 04 Comfort and driving pleasure Blind Spot Information System* Limitations NOTE Blind spot syst. service required Light reflected from a wet road surface The vehicle's own shadow against a large, light, smooth surface such as barriers between lanes on a highway Sunlight directly in the camera when the sun is low on the horizon Cleaning the BLIS camera lenses...
Page 197 READ BLIS system messages Text in the dis- System status play Blind spot syst. service required Blind spot syst. camera blocked Blind-spot info system ON 04 Comfort and driving pleasure Text in the dis- System status play Blind-spot info system off Blind spot syst.
Page 198 04 Comfort and driving pleasure Passenger compartment convenience Storage spaces...
Page 199 Jacket holder 04 Comfort and driving pleasure Passenger compartment convenience Tunnel console Cigarette lighter and ashtray* Glove compartment...
Page 200 04 Comfort and driving pleasure Passenger compartment convenience Vanity mirror Vanity mirror with lighting 12-volt sockets 12-volt socket in the front tunnel console 12-volt socket in the rear center console WARNING 12-volt socket in the cargo area* NOTE...
Page 201 04 Comfort and driving pleasure...
Page 204: During Your Trip
05 During your trip Driving recommendations General information Economical driving conserves natural resources Observe the following rules: Other factors that decrease gas mileage are: WARNING Driving with the tailgate open: Weight distribution affects handling Handling, roadholding...
Page 205 05 During your trip Driving recommendations Driving through water CAUTION WARNING WARNING Conserving electrical current Engine and cooling system...
Page 206 05 During your trip Driving recommendations Before a long distance trip NOTE Cold weather precautions...
Page 207 05 During your trip Driving recommendations...
Page 208 05 During your trip Refueling Fuel requirements Deposit control gasoline (detergent additives) NOTE Unleaded fuel NOTE Gasoline containing alcohol and ethers, "Oxygenated fuels" Alcohol – Ethanol Methanol...
Page 209 Octane rating Minimum octane Typical pump octane label Demanding driving NOTE Fuel Formulations 05 During your trip Refueling Use of Additives WARNING switched WARNING...
Page 210 05 During your trip Refueling Opening/closing the fuel filler door CAUTION Opening/closing the fuel cap Manually opening the fuel filler door...
Page 211 05 During your trip Refueling Heated oxygen sensors CAUTION Emission controls Three-way catalytic converter NOTE...
Page 212 05 During your trip Loading Introduction Power tailgate Automatic opening CAUTION NOTE Automatic closing NOTE WARNING...
Page 213 Interrupting automatic opening/closing opened closed Pinch protection opened closed Operating the tailgate manually Load anchoring eyelets 05 During your trip Loading WARNING...
Page 214 05 During your trip Loading Grocery bag holder* Grocery bag holder under the floor of the cargo area Roof loads Using load carriers...
Page 215 05 During your trip Cargo area Steel cargo grid* Installing the steel cargo grid NOTE Folding the grid up/down NOTE Installing the cargo grid...
Page 216 05 During your trip Cargo area Cargo area cover* Installing the cover Removing the cover Folding down the cargo area cover's rear flap ± NOTE Cargo net* Cargo net mounted in rear position...
Page 217 05 During your trip Cargo area WARNING Cargo net in rear position Cargo net in front position Mounting the cargo net CAUTION...
Page 218 05 During your trip Cargo area Removing and storing the cargo net...
Page 219 05 During your trip Towing a trailer Introduction WARNING NOTE...
Page 220 05 During your trip Towing a trailer Detachable trailer hitch (accessory) NOTE Removing the ball holder NOTE Installing the ball holder Trailer cable...
Page 221 Towing eyelet Location of the towing eyelet Attaching the towing eyelet CAUTION NOTE Attaching the towing eyelet 05 During your trip Emergency towing WARNING Precautions when the vehicle is in tow...
Page 222 05 During your trip Emergency towing NOTE CAUTION CAUTION Towing vehicles with front wheel drive/ All Wheel Drive In this case, the vehicle should be towed with the rear wheels on the ground if at all possible. CAUTION...
Page 223 05 During your trip...
Page 226: Maintenance And Specifications
06 Maintenance and specifications Volvo maintenance Introduction The Federal Clean Air Act – U.S Maintenance Applicable warranties – U.S/Canada Periodic maintenance helps minimize emissions Vehicle Event Data (Black Box)
Page 227 Owner maintenance Each time the car is refueled: Monthly: 06 Maintenance and specifications As needed: NOTE Hoisting the vehicle Maintaining your car Emission inspection readiness What is an Onboard Diagnostic System (OBD II)? How do states use OBD II for emission inspections?
Page 228 06 Maintenance and specifications Maintaining your car How can my vehicle fail OBD II emission inspection? How can I prepare for my next OBD II emission inspection?
Page 229 06 Maintenance and specifications Hood and engine compartment Opening and closing the hood Engine compartment, overview WARNING WARNING WARNING...
Page 230 06 Maintenance and specifications Engine oil Checking the engine oil CAUTION Checking and adding oil Location of the filler cap and dipstick NOTE If the engine is warm The oil level must be between the MIN and MAX marks on the dipstick Checking the oil...
Page 231 06 Maintenance and specifications Engine oil WARNING NOTE...
Page 232 06 Maintenance and specifications Fluids Coolant Location of the coolant reservoir CAUTION WARNING Brake fluid Location of the brake fluid reservoir Checking the level...
Page 233 Fluid type Replace WARNING DO NOT DRIVE 06 Maintenance and specifications Filling Power steering fluid Fluids WARNING CAUTION...
Page 234 06 Maintenance and specifications Replacing bulbs Introduction NOTE WARNING Headlight housing WARNING CAUTION...
Page 235 NOTE Removing the headlight housing START/STOP ENGINE CAUTION 06 Maintenance and specifications Reinserting the headlight housing Replacing bulbs Removing the cover to access the headlights and parking lights...
Page 236 06 Maintenance and specifications Replacing bulbs NOTE High beam, Halogen Low beam, Halogen...
Page 237 06 Maintenance and specifications Replacing bulbs Extra high beam Turn signals Side marker lights NOTE...
Page 238 06 Maintenance and specifications Replacing bulbs Location of taillight bulbs Front fog lights Rear fog light Taillight lens, right side...
Page 239 06 Maintenance and specifications Replacing bulbs Footwell lighting NOTE Brake lights and taillights License plate lighting NOTE...
Page 240 06 Maintenance and specifications Replacing bulbs Cargo area lighting NOTE Vanity mirror lighting Removing the mirror glass Reinstalling the mirror glass Specification, bulbs Lighting Output/volt- Bulb function age (W)
Page 241 Lighting Output/volt- Bulb function age (W) 06 Maintenance and specifications Replacing bulbs...
Page 242 06 Maintenance and specifications Wiper blades and washer fluid Wiper blades Replacing the windshield wiper blades Service position Cleaning...
Page 243 06 Maintenance and specifications Wiper blades and washer fluid Replacing the tailgate wiper blade Filling washer fluid Location of the washer fluid reservoir...
Page 244 06 Maintenance and specifications Battery Warning symbols on the battery NOTE WARNING Handling NOTE Maintenance...
Page 245 06 Maintenance and specifications Battery Changing WARNING Removal CAUTION...
Page 246 06 Maintenance and specifications Battery WARNING PROPOSITION 65 WARNING! Installation...
Page 247 06 Maintenance and specifications Fuses Replacing fuses Location of the fuse boxes WARNING...
Page 248 06 Maintenance and specifications Fuses Engine compartment...
Page 249 06 Maintenance and specifications Fuses Function Function Positions NOTE Function...
Page 250 06 Maintenance and specifications Fuses Function...
Page 251 06 Maintenance and specifications Fuses Under the glove compartment Function Function Positions Function...
Page 252 06 Maintenance and specifications Fuses Function...
Page 253 Cargo area Located behind the upholstery on the left side of the cargo area Positions Module (black). Func- tion 06 Maintenance and specifications Module (black). Func- tion Fuses Module (black). Func- tion...
Page 254 06 Maintenance and specifications Fuses Module (white). Func- tion Module (blue). Func- tion...
Page 255 06 Maintenance and specifications Wheels and tires Introduction Tire age CAUTION New Tires Improving tire economy...
Page 256 06 Maintenance and specifications Wheels and tires Summer and winter tires The arrows shows the direction of rotation of the tire Storing wheels and tires CAUTION WARNING Tire wear Tire rotation...
Page 257 06 Maintenance and specifications Wheels and tires Tread wear indicator Tire inflation NOTE Tire inflation placard on U.S. models Tire inflation...
Page 258 06 Maintenance and specifications Wheels and tires NOTE NOTE WARNING Tire inflation placard on Canadian models Checking tire pressure Cold tires The tires are considered to be cold when they have the same temperature as the sur- rounding (ambient) air.
Page 259 06 Maintenance and specifications Wheels and tires To check inflation pressure: Tire specifications Load ratings Speed ratings Speed ratings NOTE Load ratings...
Page 260 06 Maintenance and specifications Wheels and tires Tire inflation pressure table – U.S. models Tire size Cold tire pressure for up to 5 persons Tire inflation pressure table – Canadian models Tire size Cold tire pressure for up to 5 persons Optional tire pressure for up to 3 persons...
Page 261 Tire designations NOTE example only 06 Maintenance and specifications NOTE Wheels and tires M+S or M/ U.S. DOT Tire Identification Number (TIN) Tire Ply Composition and Material Used Maximum Load...
Page 262 06 Maintenance and specifications Wheels and tires Treadwear, Traction, and Temperature grades Glossary of tire terminology Tire information placard Tire Identification Number (TIN) Inflation pressure Standard load Extra load B-pillar Bead area of the tire Sidewall of the tire Tread area of the tire Maximum load rating Maximum permissible inflation pressure...
Page 263 Curb weight Capacity weight NOTE Permissible axle weight Gross vehicle weight (GVW) 06 Maintenance and specifications NOTE Steps for Determining Correct Load Limit Wheels and tires WARNING...
Page 264 06 Maintenance and specifications Wheels and tires Uniform Tire Quality Grading ALL PASSENGER VEHICLE TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS IN ADDITION TO THESE GRADES Quality grades can be found, where appli- cable, on the tire sidewall between the tread shoulder and maximum section width.
Page 265 CAUTION Snow tires, studded tires Tires for winter use: 06 Maintenance and specifications NOTE Wheels and tires Temporary Spare WARNING CAUTION...
Page 266 06 Maintenance and specifications Wheels and tires Changing a wheel Location of jack and tools Spare wheel WARNING CAUTION Taking out the spare wheel After use Removing the wheel cover Changing a tire:...
Page 267 06 Maintenance and specifications Wheels and tires WARNING WARNING Re-installing the wheel...
Page 268 06 Maintenance and specifications Wheels and tires Tighten the lug nuts Tire Sealing System* Introduction Accessing the tire sealing system NOTE...
Page 269 06 Maintenance and specifications Wheels and tires Tire sealing system–overview WARNING WARNING Precautions: First aid:...
Page 270 06 Maintenance and specifications Wheels and tires Tire sealing system–temporarily repairing a flat tire Stage 1: NOTE Stage 2: WARNING Stage 1: Sealing the hole WARNING NOTE...
Page 271 WARNING WARNING 06 Maintenance and specifications WARNING NOTE Wheels and tires CAUTION WARNING...
Page 272 06 Maintenance and specifications Wheels and tires CAUTION NOTE WARNING Stage 2: Checking inflation pressure stage 1 CAUTION WARNING Replacing the sealing compound container NOTE...
Page 273 06 Maintenance and specifications Wheels and tires Inflating tires Tire Pressure Monitoring System (TPMS)–U.S models only NOTE USA – FCC ID: KR5S122780002 CAUTION WARNING TIRE PRESS. CHECK TIRES VERY LOW TIRE PRESSURE...
Page 274 06 Maintenance and specifications Wheels and tires NOTE TIRE PRESS SYST SERVICE REQUIRED NOTE Erasing warning messages WARNING...
Page 275 06 Maintenance and specifications Wheels and tires Changing wheels with TPMS NOTE CAUTION...
Page 276 06 Maintenance and specifications Vehicle care Washing the car WARNING Bird droppings NOTE CAUTION CAUTION Special laminated panoramic roof cau- tions: Exterior components...
Page 277 06 Maintenance and specifications Vehicle care CAUTION CAUTION Polishing and waxing Automatic car wash Chromed wheels: WARNING Exterior lighting...
Page 278 06 Maintenance and specifications Vehicle care CAUTION Protecting leather upholstery Cleaning the interior Upholstery care Fabric Cleaning leather upholstery Alcantera suede-like material Leather care...
Page 279 CAUTION Cleaning the seat belts Cleaning floor mats 06 Maintenance and specifications Spots on interior plastic, metal, or wood surfaces Touching up paintwork Paint code on the model plate Vehicle care Color code Minor stone chips and scratches NOTE...
Page 280 06 Maintenance and specifications Vehicle care Minor scratches on the surface Repairing stone chips...
Page 281 06 Maintenance and specifications Label information Location of labels...
Page 282 06 Maintenance and specifications Label information List of labels Vehicle Emission Control Information. Model plate. Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Min- istry of Transport (CMVSS) standards (Canada). Loads and Tire Pressures. Vehicle Identification Number (VIN).
Page 283 06 Maintenance and specifications Specifications Dimensions Dimension In. (mm)
Page 284 06 Maintenance and specifications Specifications Dimension In. (mm) Weights Category Canada...
Page 285 06 Maintenance and specifications Specifications Category Canada Engine specifications Specification/Model 3.2 6-cyl. 3.2 6-cyl. 3.0T...
Page 286 06 Maintenance and specifications Specifications Specification/Model 3.2 6-cyl. 3.2 6-cyl. 3.0T...
Page 287 Engine oil Oil additives must not be used. Oil viscosity 06 Maintenance and specifications Viscosity chart Extreme engine operation Specifications American Petroleum Institute (API) symbol...
Page 288 06 Maintenance and specifications Specifications Oil volume Engine model Other fluids and lubricants Fluid System Oil volume between MIN and Volume (incl. filter) Volume Specification...
Page 289 Fluid System Electrical system General information Performance, battery 06 Maintenance and specifications Volume WARNING PROPOSITION 65 WARNING! CAUTION Specifications Specification...
Page 290 06 Maintenance and specifications Volvo programs Volvo On Call Roadside Assistance In the U.S. In Canada Technician certification...
Page 291 06 Maintenance and specifications...
Page 292 07 Index 1, 2, 3 ...
Page 293 07 Index...
Page 294 07 Index...
Page 295 07 Index...
Page 296 07 Index...
Page 297 07 Index...
Page 298 07 Index...
Page 299 07 Index...
Page 300 07 Index...
Page 302 Kdakd 8Vg 8dgedgVi^dc...

This manual is also suitable for:

Xc60

Volvo 2010 XC60 Owner's Manual

Quick Links

Related Manuals for Volvo 2010 XC60

Summary of Contents for Volvo 2010 XC60

Page 54: Locks And Alarm

Page 72: Your Driving Environment

Page 122: Comfort And Driving Pleasure

Page 204: During Your Trip

Page 226: Maintenance And Specifications

This manual is also suitable for:
