Camera recording
To stop recording momentarily [a]
Press START/STOP again. The "STBY" indicator appears in the viewfinder (Standby
mode).
To finish recording [b]
Press START/STOP again. Turn STANDBY down to LOCK and set the POWER switch
to OFF. Then, eject the cassette.
[a] [b]
STBY 0:35:20
START/STOP
START/STOP
START/STOP
Note
There is a little wear on the battery pack which is installed with the camcorder.
However, for getting remaining battery time indicated correctly, leave the battery pack
installed after use.
As an exception, be sure to remove the battery pack from the model having the built-in
light after use (CCD-TRV93 only).
To focus the viewfinder lens
If you cannot see the indicators in the viewfinder clearly, or after someone else has used
the camcorder, focus the viewfinder lens. Turn the viewfinder lens adjustment ring [a]
(CCD-TRV75/TRV85/TRV715/TRV815) or move the viewfinder lens adjustment lever
[b] (CCD-TRV93) so that the indicators in the viewfinder come into sharp focus.
[a] CCD-TRV75/TRV85/TRV715/
[b] CCD-TRV93
TRV815
Note on the lighting aperture
– CCD-TRV93 only
If direct sunlight enters the lighting aperture, the picture in the viewfinder appears
brighter. When this happens, colors in the viewfinder may change.
