RoadLazer
Tow-Behind System
U.S. Patent No. 5,368,232 and 5,947,385
Chinese Patent ZL97111289.4
Brazilian Patent No. PI9701899-6
- For the application of road marking and reflective coatings -
List of Models (see page 2)
2900 psi (20 MPa, 200 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Trailer Ratings
•
Gross Vehicle Weight Rating (GVWR)
2800 lb (1270 kg)
•
Gross Axle Weight Rating (GAWR)
1200 lb (544 kg) per axle with 5.70 x 8
tire, 8 x 3.75 5-45 rim at
100 psi (690 KPA) cold single.
Tire Ratings
Size: 5.70 x 8, Load Range D
Cold tire pressure: 100 psi (690 KPA)
Lug Torque: 90-120 ft-lb (122-163 N•m)
NOTE: This manual replaces the Operation Manual (3A1214)
for the standard RoadLazer
™
RoadPak
- For professional use only -
™
™
™
RoadPak
Line Striping System.
3A2091B
EN
ti18134a
