Section 1 - Familiarization - Snapper R1962519B Safety Instructions & Operator's Manual

Section 1 - FAMILIARIZATION

ROPE
START HANDLE
RECOIL
ROPE
GUIDE
KNOB
FUEL FILLER
CAP
1.1 INTRODUCTION
This manual has been prepared for the operators of
the SNAPPER WALK BEHIND MOWERS. Its
purpose, aside from recommending operating and
routine service requirements, is to promote safety
through the use of accepted operating practices.
Read, Understand and Follow the "IMPORTANT
SAFETY INSTRUCTIONS" on Pages 2 - 4 of this
manual and all safety messages on the mower and
attachments before operating the mower.
AIR CLEANER
RECYCLING
COVER
PRIMER
(SEE INSET)
BLADE CONTROL
KNOB
FIGURE 1.1
1.2 NOMENCLATURE
The nomenclature information above, Figure 1.1,
shows the essential parts of the SNAPPER WALK
BEHIND MOWERS.
operators of the mower become thoroughly familiar
with the controls, parts and operation of the mower
before operating.
engine are found in the separate engine owner's
manual. Study these manuals before operating and
keep both handy for future reference.
6
PRIMER BULB
OIL FILL CAP &
DIPSTICK
MUFFLER
CUTTING DECK
CUTTING HEIGHT
ADJUSTMENT
BUSHINGS
It is recommended that all
Specific details involving the
