Dealer Setup
& Adjustment Instructions
Zero-Turn Riders & Mowers
This Dealer Setup & Adjustment Instruction
covers the following products:
250 Z (Snapper)
Mfg. No.
Description
7800158 ERZT20441BVE2, 20HP European Rider with 44" Mower
Javelin (Simplicity)
Mfg. No.
Description
7800157 EJAV20441BVE2, 20HP European Rider with 44" Mower
ATTENTION SETUP PERSONNEL:
The safety warnings provided in this guide and in
the operator's manual included with the unit contain
important information that must be obeyed when
assembling, setting-up, operating, servicing, trans-
porting, or storing the unit.
These warnings are highlighted by the safety alert triangle sym-
bol shown above, which signifies that an important safety mes-
sage is being provided.
You must read, understand, and follow these warnings and
instructions, and use safe shop and work practices at all
times while working on or around this unit and all other
outdoor power equipment.
Sections and items denoted by the Setup symbol
provide the information necessary to fully assemble,
test, and prepare the units described above for
delivery to your customers.
Additional information concerning functional tests,
general adjustment procedures, and the location of
normal lubrication points are included in these
instructions.
10/2006
TABLE OF CONTENTS:
SAFETY RULES .................................................................2
Quick Setup List ................................................................5
Uncrating ............................................................................6
Battery Activation & Installation ......................................7
Check Fluid levels .............................................................8
Fill and Check Engine Oil.................................................8
Reduce and Check Tire Pressure ....................................8
Torque Mower Blades .......................................................9
Lubrication .........................................................................9
Perform Safety Checks ...................................................10
Functional Tests.............................................................10
Mower Blade Stopping Check........................................10
Seat Switch Connection .................................................10
Burnish PTO Clutch .......................................................10
Safety Interlock System .................................................11
Seat Adjustments ............................................................11
Motion Control Lever Adjustment..................................12
Operator Adjustment ......................................................12
Speed Balancing Adjustment .........................................12
Lever Friction Adjustment ..............................................12
Neutral Adjustments.......................................................13
Parking Brake Adjustment..............................................14
Front Suspension Adjustment .......................................14
PTO Clutch Adjustment ..................................................15
PTO Clutch Adjustment .................................................15
Blade Brake Check ........................................................15
Mower Deck Leveling ......................................................16
Roller Bar Leveling ..........................................................17
SERVICE PROCEDURES
Transmission Drive Belt Replacement ..........................18
Mower Belt Replacement ................................................19
Fuse Replacement ...........................................................19
1
Form No. 7101168
Revision 00
TP 300-5241-00-HZ-SN
