21" cast deck walk behind mower european series 3 (20 pages)
Summary of Contents for Snapper 7800179
Page 1
* Actual sustained engine power will likely be lower due to operating limitations and environmental factors. Please refer to ‘Engine Power Rating Information’ for further details. Safety Instructions & Operator's Manual for 21” VARIABLE SPEED REAR DISCHARGE WALK BEHIND MOWERS Model No. Description 7800179 SPV21675 7800195 SPV21675E 7800231 NSPV21675 7800232 NSPV21675E...
Page 2
Thank You for purchasing this quality-built Snapper mower. We’re pleased that you placed your confidence in the Snapper brand. When operated and maintained according to the instructions in this manual, your Snapper mower will provide many years of dependable service.
If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-317-7833). PROTECTION FOR CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children.
Page 5
10. DO NOT test for spark by grounding spark plug next to spark plug hole; spark plug could ignite gas exiting engine. 11. Have machine serviced by an authorized SNAPPER dealer at least once a year and have the dealer install any new safety devices.
IMPORTANT The figures and illustrations in this manual are provided for reference only and may differ from your specific model. Contact your Snapper dealer if you have questions. Features and Controls Oil Fill Cap and Dipstick Fuel Filler Cap Recycling Cover...
Pre-Start Check List Make the following checks and perform the service required before each start-up. 1. Check the guards, deflectors, grass bag, and covers to make sure all are in place and securely tightened. 2. Check the blade control (A, Figure 1) and wheel drive control (B) to insure they work freely.
DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. WARNING www.snapper.com...
WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Cutting Height Adjustment 1.
Figure 11: Installing the grass bag Figure 12: Grass bag hooks WARNING Grass Catcher bags used on SNAPPER products are made of woven fabric, and are subject to deterioration and wear during normal usage. Check condition of bag before each use.
Maintenance - Introduction To retain the quality of the mower, use genuine SNAPPER replacement parts only. Contact a local SNAPPER dealer for parts and service assistance. For the correct part or information for a particular mower, always mention the model and serial number.
5. Lubricate all exposed metal with a light coating of oil to prevent corrosion. 6. Carefully fold the handles, “flexing” the control cables to prevent cable damage. 7. Store the mower in a shed or other dry area, protected from weather. www.snapper.com...
WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Wear heavy leather gloves when handling or working around cutting blades.
Tighten the jam nut. 5. Engage the lever and recheck the extended spring length. Repeat Step 4 as needed. Figure 20: Adjusting the transmission spring tension IMPORTANT: INCORRECT ADJUSTMENT CAN CAUSE PREMATURE WEAR AND/OR DAMAGE TO THE WHEEL DRIVE COMPONENTS. www.snapper.com...
WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Belt Service On self-propelled mowers, the engine belt transmits power from the engine to the transmission that powers the rear...
Figure 23: Battery connections WARNING Keep all sparks, flame and fire away from area when charging battery or when handling battery. Never use “BOOST” chargers on the battery. Digital Voltmeter 12.80v 12.40v 12.10v 11.90v Less than 11.80v www.snapper.com...
WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Rear Cover Removal and Installation To Remove the Rear Cover 1.
Check & Adjust Spring Adjustment Maintenance/Replacement Parts Blade Control Cable Wheel Drive Control Cable Cutter Blade (Double Wave) Drive Belt Parts Manual for Snapper 21” Variable Speed Walk Behind Mower REF. EACH Page 7 Page 11 Page 11 Engine Manual...
For ninety (90) days from purchase date for the original purchaser’s commercial, rental, or other non-residential use, SNAP- PER, through any authorized SNAPPER dealer will replace, free of charge, any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both.
Page 24
(temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine. Snapper Products 535 Macon Street McDonough, GA 30253...
Page 25
* La potencia sostenida real del motor será probablemente menor, debido a limitaciones operativas y factores ambientales. Para obtener más detalles, consulte 'Información sobre especificación de potencia del motor'. CORTACÉSPED DE VELOCIDAD VARIABLE, DE CONDUCTOR A PIE, DE DESCARGA TRASERA, DE 21" (53.2 cm) de Modelo Descripción 7800179 SPV21675 7800195 SPV21675E 7800231 NSPV21675 7800232 NSPV21675E...
Page 26
Gracias por comprar este producto de calidad Snapper. Nos complace que haya puesto su confianza en la marca Snapper. Cuando se maneja y mantiene de acuerdo a las instrucciones que aparecen en este manual, su producto Snapper brindará muchos años de servicio seguro.
Page 27
Índice Seguridad del operador ............4 Instrucciones importantees de seguridad del operador .
Ante cualquier duda respecto a su máquina que su concesionario no pueda solucionar para su satisfacción, llame o escriba al Customer Service Department, SNAPPER, McDonough, Georgia 30253. Phone: (1-800-317-7833). PROTECCIÓN PARA LOS NIÑOS Pueden ocurrir accidentes de trágicas consecuencias si el oper-...
Page 29
11. Solicite un servicio de mantenimiento para la máquina por parte de un distribuidor SNAPPER autorizado al menos una vez al año, y solicite al distribuidor que instale cualquier nuevo dispositi- vo de seguridad.
Las figuras e ilustraciones en este manual se suministran únicamente para referencia y podrían ser diferentes de su modelo específico. En caso de tener preguntas, comuníquese con su distribuidor Snapper. Características y controles Tapa de llenado de aceite y varilla medidora del...
Lista de comprobación antes del arranque Realice las siguientes revisiones y realice el servicio de manten- imiento requerido antes de cada arranque. 1. Revise los protectores, los deflectores, la bolsa de césped, y las cubiertas para garantizar que todo está en su sitio y apreta- do firmemente.
DETENGA el motor y la cuchilla. Desconecte el cable de la bujía y asegure el extremo del cable lejos de la bujía. El motor y los componentes están CALIENTES. Evite quemaduras graves, permita suficiente tiempo para que todos los componentes se enfríen. ADVERTENCIA www.snapper.com...
ADVERTENCIA NO intente realizar ningún mantenimiento, ajuste o servicio con el motor y la cuchilla en funcionamiento. DETENGA el motor y la cuchilla. Desconecte el cable de la bujía y asegure el extremo del cable lejos de la bujía. El motor y los componentes están CALIENTES.
Figura 12: Ganchos de la bolsa de césped ADVERTENCIA Las bolsas Receptoras de Césped en los productos SNAPPER están hechas de tela tejida, y son susceptibles a deterioro y des- gaste durante el uso normal. Revise la condición de la bolsa antes de cada uso.
Para conservar la calidad del cortacésped, sólo utilice piezas de repuesto genuinas de SNAPPER. Comuníquese con un distribuidor local de SNAPPER para obtener piezas y ayuda de servicio. Para obtener la pieza correcta o información para un cortacésped especí- fico, siempre mencione el modelo y número de serie.
5. Lubrique todo el metal expuesto con una capa delgada de aceite para evitar la corrosión. 6. Pliegue cuidadosamente el asidero, "flexionando" los cables (mecánicos) de control para evitar dañar el cable. 7. Guarde el cortacésped en un cobertizo u otra área seca, prote- gida contra el clima. www.snapper.com...
ADVERTENCIA NO intente realizar ningún mantenimiento, ajuste o servicio con el motor y la cuchilla en funcionamiento. DETENGA el motor y la cuchilla. Desconecte el cable de la bujía y asegure el extremo del cable lejos de la bujía. El motor y los componentes están CALIENTES.
Repita el Paso 4 según se requiera. Figura 20: Ajuste de la tensión del resorte de la transmisión IMPORTANTE: UN AJUSTE INCORRECTO PUEDE CAUSAR DESGASTE PREMATURO Y/O DAÑO A LOS COMPONENTES DEL SISTEMA DE TRACCIÓN DE LAS RUEDAS. www.snapper.com...
ADVERTENCIA NO intente realizar ningún mantenimiento, ajuste o servicio con el motor y la cuchilla en funcionamiento. DETENGA el motor y la cuchilla. Desconecte el cable de la bujía y asegure el extremo del cable lejos de la bujía. El motor y los componentes están CALIENTES.
ADVERTENCIA Mantenga toda chispa, llama y fuego alejados del área cuando se carga la batería o cuando se manipula la batería. Nunca utilice cargadores de "REFUERZO" (BOOST) en la batería. Digital Voltmeter 12.80v 12.40v 12.10v 11.90v Menos de 11.80v www.snapper.com...
ADVERTENCIA NO intente realizar ningún mantenimiento, ajuste o servicio con el motor y la cuchilla en funcionamiento. DETENGA el motor y la cuchilla. Desconecte el cable de la bujía y asegure el extremo del cable lejos de la bujía. El motor y los componentes están CALIENTES.
Cable de control del sistema de tracción de las ruedas Cuchilla del cortacésped (doble ondulación) Correa de transmisión Manual de piezas para la Cortadora de césped de velocidad variable con conductor a pie Snapper de 53.3 cm (21") REF. CADA Página 7...
1. Limpie los residuos. 2. Ajuste el cable de la transmisión. 3. Reemplace la correa de transmisión. 4. Comuníquese con un distribuidor SNAPPER autorizado. 1. Ajuste el cable de la transmisión. 2. Comuníquese con un distribuidor SNAPPER autorizado. 1. Limpie los residuos.
Por dos (2) años a contar de la fecha de compra de este producto para ser usado por el comprador original, SNAPPER, por inter- medio de cualquier concesionario autorizado SNAPPER reemplazará, gratuitamente (con la excepción de impuestos donde sean aplicables), cualquier pieza o piezas que después de ser examinadas por la fábrica en McDonough, Georgia, EE.UU., mostrara tener defectos en el material o en la fabricación o ambos.
Page 45
GUÍA PARA MANEJAR EN PENDIENTES APUNTE Y SOSTENGA ESTA GUÍA A NIVEL CON UN ÁRBOL VERTICAL, LA ESQUINA DE UNA ESTRUCTURA, UN POSTE DE ENERGÍA ELÉCTRICA O UNA VALLA. 10 GRADOS Para determinar si no es peligroso cortar el césped en una pendiente cuando maneja un tractor cortacésped: (1) desengrane la cuchilla(s), (2) ponga la máquina en marcha atrás, y (3) pruebe ascender la pendiente retrocediendo en línea recta.
Page 48
(temperatura, humedad, altitud), y variabilidad de motor a motor. Debido a limita- ciones de fabricación y capacidad, Briggs & Stratton podría sustituir motor de mayor potencia nominal por el motor de esta Serie. Snapper Products 535 Macon Street...
