Owner's Manual
Full-Motion Ceiling Mount
Español 9 • Français 17 • Русский 25 • Deutsch 33
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY.
SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!
WARNING
• When mounting, make sure that the supporting surface will safely support the combined load of
the equipment and all attached hardware and components.
• If mounting to ceiling joists or rafters, make sure mounting screws are anchored into the center of
the joists or rafters. Do not use in gypsum board ceilings without anchoring into ceiling joists.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
75x75
100x100
200x200
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
MODEL: DCTM
Copyright © 2014 Tripp Lite. All rights reserved.
37"
MAX
1
80 lbs
(36 kg)
MAX
