QUICK START GUIDE
Outdoor Collection
30607 Rev_A

Advertisement

Table of Contents
loading

Related Manuals for U-Line OFZ124

Summary of Contents for U-Line OFZ124

  • Page 1 QUICK START GUIDE Outdoor Collection 30607 Rev_A...
  • Page 2 1. U-Line Customer Care must be contacted immediately at +1.800.779.2547. 2. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.

  • Page 3: Table Of Contents

    General Installation Control Operation First Use Cleaning Warranty For more details, see the complete User Guide & Service Manual on u-line.com. plus eligible warranty warranty This product is eligible for an additional one-year warranty at no charge when you register your product on...

  • Page 4: Safety And Warning

    QUICK START GUIDE u-line.com Safety and Warning DANGER Please read all instructions before installing, operating, or servicing the appliance. Your product may contain R600a (Isobutane) which is a flammable hydrocarbon. To confirm, check serial tag inside of unit. It is safe for Use this appliance for its intended purpose only and follow regular use.

  • Page 5: Environmental Requirements

    QUICK START GUIDE u-line.com Environmental Requirements Electrical This unit is designed to operate between 50°F (10°C) and WARNING 100°F (38°C). Higher ambient temperatures may reduce the unit’s ability to reach low temperatures and/or reduce SHOCK HAZARD — Electrical Grounding ice production on applicable models.

  • Page 6: Water Hookup

    The water valve uses a standard 1/4" (6.35 mm) is under pressure at all times. Plastic may crack compression fitting. U-Line recommends using accessory or rupture with age and cause damage to your water hook up kit – part # 80-54674-00. The kit includes a home.
  • Page 7 QUICK START GUIDE u-line.com 3. Locate water valve inlet. 9. Install retaining clip. 4. Break away filler feature in bushing with flat screwdriver. CLEAR ICE MACHINES Remove 1. Turn off water supply and disconnect electrical supply screwdriver to product prior to attempting installation.
  • Page 8 QUICK START GUIDE u-line.com 4. On the back panel, 3. Thread water line through back panel hole (with break away filler feature bushing). in bushing with flat screwdriver. Remove screwdriver 5. Thread water line through back panel hole (with bushing) and connect to cold water supply line.

  • Page 9: Drain

    Proper Drain CAUTION A gravity drain may be used if: If your U-Line unit did not come with a factory Drain line has at least a 1" drop per 48" (approximately installed drain pump you must use a gravity 2 cm drop per 100 cm) of run.

  • Page 10: Door Swing

    (Optional Hook-Up) requirements for a gravity drain, you may have ordered a pre-installed U-Line P60 drain pump. Waste If you need to install a P60 drain pump into your unit, see Valve DRAIN PUMP section in the User Manual.

  • Page 11: Door Adjustments

    QUICK START GUIDE u-line.com Door Adjustments 5. Tighten bottom hinge screws. CRESCENT ICE MAKERS 6. Tighten top hinge screws and replace hinge cover. REVERSING THE DOOR HINGE COVER Location of the unit may make it desirable to mount the Hinge cover included with the literature bag is optional.
  • Page 12 QUICK START GUIDE u-line.com Install top hinge and door: 4. Remove door by tilting forward and lifting door off bottom hinge. Retain shoulder washers; they will be Top Hinge Right Side reused. 5. Remove three screws from hinge holes on the opposite side.
  • Page 13 QUICK START GUIDE u-line.com Door Adjustments 5. Tighten bottom hinge screws. 15” REFRIGERATORS AND CLEAR ICE MACHINES 6. Tighten top hinge screws and replace hinge cover. REVERSING THE DOOR HINGE COVER Location of the unit may make it desirable to mount the Hinge cover included with the literature bag is optional.
  • Page 14 QUICK START GUIDE u-line.com Remove bottom hinge: Install top hinge and door: 1. Remove bottom hinge from cabinet using 1/4” socket. Top Hinge Right Side Top Hinge Left Side Pivot Screw 1. Remove pivot screw from hinge, flip hinge over, and 2.
  • Page 15 QUICK START GUIDE u-line.com Door Adjustments 6. Tighten top hinge screws and replace hinge cover. 24” MODELS AND NUGGET ICE MACHINES REVERSING THE DOOR HINGE COVER Hinge cover included with the literature bag is optional. Location of the unit may make it desirable to mount the door on the opposite side of the cabinet.
  • Page 16 QUICK START GUIDE u-line.com Prepare door for reinstallation: 1. Remove gasket. This will reveal mounting holes for the magnet assembly. 2. Remove magnet assembly from door with T-10 TORX driver. Be sure to only remove the two screws holding the assembly to the door. Reinstall on the opposite end 3.

  • Page 17: General Installation

    QUICK START GUIDE u-line.com General Installation INSTALLATION 1. Plug in the power/electrical cord. LEVELING INFORMATION 1. Use a level to 2. Gently push the unit into position. Be careful not to confirm the unit is entangle the cord or water and drain lines, if level.

  • Page 18: Control Operation

    QUICK START GUIDE u-line.com Control Operation REFRIGERATORS CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and hold for 5 seconds Unit will turn ON or OFF Press and release to leave interior After 3 hours, factory default is restored; light will turn Leave interior light on light on for 3 hours;...
  • Page 19 QUICK START GUIDE u-line.com Control Operation CLEAR ICE MACHINES CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn ON or OFF Adjust ice thickness See “Ice” section C symbol will flash briefly after 5 seconds.
  • Page 20 QUICK START GUIDE u-line.com Control Operation CONVERTIBLE FREEZER CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn ON or OFF Press and release to leave interior After 12 hours, factory default is restored; light will Leave interior light on light on for 12 hours;...
  • Page 21 QUICK START GUIDE u-line.com Control Operation NUGGET ICE MACHINES CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn ON or OFF. C symbol will flash briefly after 5 seconds. Press and hold for 5 seconds and...

  • Page 22: First Use

    To turn the unit on or off: unit is progressing towards the selected temperature. Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. U-Line recommends allowing the unit to reach set point before loading.

  • Page 23: Ice

    QUICK START GUIDE u-line.com During periods of limited use or high ambient temperatures, it is common for cubes to fuse together. CRESCENT ICE MAKERS Gently shake the bucket to break apart cubes. If not using the ice maker regularly, empty the ice bucket periodically to ensure fresh cubes.
  • Page 24 QUICK START GUIDE u-line.com CLEAR ICE MACHINES CAUTION ICE CUBE THICKNESS ADJUSTMENT Too large of an adjustment to the screw can Ice thickness adjustment should only be made cause the water to overflow the ice maker and one increment at a time. Allow ice maker can cause property damage.
  • Page 25 QUICK START GUIDE u-line.com Your clear ice machine is preset to produce ice between NUGGET ICE MACHINES the optimal dimensions illustrated below: The Nugget Ice Machine produces cylindrical bits of Cube Details compressed ice approximately ” x ”. 1/4" TO 1/2"...

  • Page 26: Cleaning

    Read and understand all labels printed on the package before use. Evaporator U-Line Ice Machine Cleaner is used to remove lime scale and other mineral deposits. Refer to the following steps to initiate the self-cleaning cycle. Standpipe Water trough 6.
  • Page 27 Due to variations in water quality or inadequate maintenance your unit may become excessively coated in lime scale or calcium. U-Line offers a cost effective refresh kit which replaces many interior components and will return your unit to like new condition. Refresh kits may be ordered from your local distributor and installed by your local service company.
  • Page 28 Clean water SafeCLEAN Plus™ Cleaner (Part No. 80-55266-00) Dispenser Tube – included with unit Need more cleaner? Visit u-line.com. 2. Press and release CAUTION will appear in the display b. Mix 4 ounces of SafeCLEAN Plus™ with 2 quarts of Use only SafeCLEAN Plus Cleaner.
  • Page 29 QUICK START GUIDE u-line.com b. Press and release will appear in the display a. Reinstall shield and close door - no further action is required b. The machine will circulate water and perform a series of final rinses for approximately 15 minutes.

  • Page 30: Warranty

    One Year Limited Warranty For one year from the date of original purchase, this U-Line product warranty covers all parts and labor to repair or replace any part of the product that proves to be defective in materials or workmanship. For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase.
