WELCOME TABLE OF CONTENTS CHAPTER 1. BEFORE USING YOUR PHONE ....9 hank you for choosing the up-to-date PS-300, our new INSIDE THE PACKAGE ............... 10 model, developed by top researchers to support the HANDSET DESCRIPTION ............11 FRONT VIEW ................... 11 CDMA2000 1X system through Qualcomm-manufactured SIDE VIEW ..................
Page 4
TABLE OF CONTENTS TABLE OF CONTENTS PHONE INFO................... 34 DISPLAY ..................63 MAKING AN EMERGENCY CALL ..........35 THEME ..................... 63 EMERGENCY NUMBER IN LOCK MODE ......... 35 STANDBY ..................63 EMERGENCY NUMBER USING ANY AVAILABLE SYSTEM .... 36 POWER ON ..................
Page 5
TABLE OF CONTENTS TABLE OF CONTENTS EVENT ..................78 CHAPTER 5. VOICE MAIL AND TEXT MESSAGE ..93 SETTING ..................78 TEXT MESSAGE ................. 94 RINGER ..................79 WRITE..................94 ALARM .................... 79 INBOX ..................96 SETTING ..................80 REPLY ................... 96 DATE ....................
Page 6
SAFETY INFORMATION FOR FCC RF EXPOSURE ......131 CAUTIONS ..................131 BODY-WORN OPERATION ............132 This chapter provides important information about using the VEHICLE MOUNTED EXTERNAL ANTENNA PS-300 including: (OPTIONAL, IF AVAILABLE) ............132 SAR INFORMATION ................133 PRECAUTIONS WHEN USING BATTERIES ........135 INSIDE THE PACKAGE CARE AND MAINTENANCE ..............
If any are missing or different, immediately phone book the CDMA2000 1X digital cellular telephone. retailer where you purchased the cellular telephone. The PS-300 90g (without battery) And the dimensions are 10.9cm X 4.65cm X 1.96cm. H FRONT VIEW H SIDE VIEW...
BEFORE USING BEFORE USING HANDSET DESCRIPTION DISPLAY INDICATORS H THE FUNCTION KEYS H DISPLAY INDICATORS Signal Strength Current signal strength: the more lines, Display Indicators the stronger the signal. See page 13 for a list of icons. Service Indicator Text & Graphic area Menu Indicates call is in progress, indicates the...
Page 9
BEFORE USING BEFORE USING DISPLAY INDICATORS BATTERY USAGE H BATTERY INSTALLATION Etiquette Mode As shown in the picture below, put the mold locators of the battery Phone will vibrate when call is received. into the holes located in the bottom of the unit. ³...
BEFORE USING BEFORE USING BATTERY USAGE BATTERY USAGE H BATTERY CHARGING • When you charge the battery with the phone power off, you will see a charging status screen. You cannot operate the phone until it is powered on. POWER CONNECTION •...
BATTERY HANDLING BEFORE USING BEFORE USING QUICK START INFORMATION H DO’s When you register with a network operator, you’ll be given a UIM card, on which you could find user’s registration • Only use the battery and charger approved by the manufac information (PIN, with additional services you may have turer.
MEMO CHAPTER 2 BASIC OPERATION This chapter addresses and explains the basic features of your cellular telephone including: TURNING THE PHONE ON / OFF ACCESSING THE MENU MENU SUMMARY BASIC FUNCTIONS DURING A CALL MAKING AN EMERGENCY CALL PS-300_060602.indd 20-21 PS-300_060602.indd 20-21 2006.6.2 5:36:19 PM 2006.6.2 5:36:19 PM...
TURNING THE PHONE BASIC OPERATION BASIC OPERATION ACCESSING THE MENU ON / OFF H TURNING THE PHONE ON Your phone can be customized via the menu. Each function can Your phone can be customized via the menu. Each function can be accessed by scrolling with the Navigation key or by pressing be accessed by scrolling with the Navigation key or by pressing the number that corresponds with the menu item.
BASIC OPERATION BASIC OPERATION MENU SUMMARY MENU SUMMARY H Left softkey tree - Menu MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH 3.1 Missed 3. Call 1.1 Add Name 1.1.1 Phone 1. Phone Book History 3.2 Received 1.1.2 UIM...
Page 15
BASIC OPERATION BASIC OPERATION MENU SUMMARY MENU SUMMARY H Side Hardkey 1 Tree(Camera) MAIN MENU 2ND DEPTH 3RD DEPTH 4TH DEPTH 2ND DEPTH MAIN MENU 3RD DEPTH 4TH DEPTH 6.2 Phone 6.2.1 Data Settings 6.2.1.1 Receive Mode 1. Take Photo 1.1 Quality 6.2.1.2 Data Speed 1.2 Resolution...
BASIC OPERATION BASIC OPERATION BASIC FUNCTIONS BASIC FUNCTIONS H MAKING A CALL H PAUSE FEATURE Pauses are used for automated systems (i.e., voice mail, calling ³ Enter a phone number. cards). Insert a pause after a phone number then enter another group of numbers.
BASIC OPERATION BASIC OPERATION BASIC FUNCTIONS BASIC FUNCTIONS H CALLER ID FUNCTION H ETIQUETTE MODE Identifies caller by displaying their phone number. If the caller’s Mutes key tones and activates the vibration mode to alert you of an name and number are already stored in your Phone books, they incoming call or message.
Page 18
BASIC OPERATION BASIC OPERATION DURING A CALL DURING A CALL H MESSAGES To display menu options during a call, press [OPTIONS]. Enables you to send a message (SMS) during a call. H MUTE (UNMUTE) (Refer to page 97 for more details.) The caller cannot hear you or any sounds from your side but you can still hear them.
MAKING AN BASIC OPERATION BASIC OPERATION DURING A CALL EMERGENCY CALL H VOICE PRIVACY The Emergency Call feature puts your phone in the Emergency Call Mode when you dial the preprogrammed emergency numbers, 120, Enhances voice privacy during a call. 666, 999.
MAKING AN BASIC OPERATION EMERGENCY CALL H EMERGENCY NUMBER USING ANY AVAILABLE SYSTEM The 120, 666, 999 call service is available even in the lock mode. ³ Enter Emergency number and press The call connects. The phone maintains the Emergency Mode. CHAPTER 3 MEMORY •...
STORING A PHONE STORING A PHONE MEMORY FUNCTION MEMORY FUNCTION NUMBER NUMBER The Phone books stores up to 500 entries. • Office Phone • Pager NUMBER Existing • Others ³ Enter phone number and press • E-mail Select “Phone” or “UIM”. •...
ENTERING LETTERS, ENTERING LETTERS, MEMORY FUNCTION MEMORY FUNCTION NUMBERS & SYMBOLS NUMBERS & SYMBOLS The input mode (Alpha editor) will be automatically activated The following illustrates the function assigned to each key in the Alpha Editor. when necessary to enter letters and numbers. As shown below, there are 4 available modes.
Page 23
ENTERING LETTERS, ENTERING LETTERS, MEMORY FUNCTION MEMORY FUNCTION NUMBERS & SYMBOLS NUMBERS & SYMBOLS H STANDARD INPUT MODE Arabic There are two modes in standard input mode : Abc mode, Arabic mode. Use the digit keys to enter letters, numbers and characters. ³...
Page 24
ENTERING LETTERS, ENTERING LETTERS, MEMORY FUNCTION MEMORY FUNCTION NUMBERS & SYMBOLS NUMBERS & SYMBOLS To change the input mode, press [Abc]. Select Arabic mode, by press and hold [Mode] and select “Arabic”. When you select this mode, the appears as a visual To enter a space, press confirmation.
Page 25
ENTERING LETTERS, ENTERING LETTERS, MEMORY FUNCTION MEMORY FUNCTION NUMBERS & SYMBOLS NUMBERS & SYMBOLS H T9 INPUT MODE H NUMERIC MODE There are standard input mode : Abc mode. Allows you to enter numbers. The T9 input mode incorporates a built-in-dictionary to determine a word based on the entered characters.
ENTERING LETTERS, MEMORY FUNCTION NUMBERS & SYMBOLS H SPEED DIAL In idle mode, calls can be placed to numbers stored in speed dial by pressing & holding the location number on the key pad. For a 2-digit location number, press the first number, then press and hold the second number.
MENU FUNCTION MENU FUNCTION PHONE BOOK PHONE BOOK H ADD NAME 3.1 To save the entry, press Adds a new entry. 3.2 To return to the previous page, press [BACK]. H FIND Retrieves an entry by name and calls by simply pressing PHONE You can review all the entries stored in your phone book list or find an entry quickly by entering a name or its character string.
MENU FUNCTION MENU FUNCTION PHONE BOOK PHONE BOOK BY NUMBER BY GROUP You can search for the data of saved in your phone’s memory. ³ Press [MENU] ³ Press [MENU] The list of phone numbers saved in your phone book will be displayed in numeric order.
MENU FUNCTION MENU FUNCTION PHONE BOOK PHONE BOOK H GROUP GROUP RINGER Phone entries into groups. Existing groups include No Group, ³ Select an existing group name with the Navigation Key. Family, Relatives, Friends, Business, Colleagues, School, Club, VIP, Others. Press [OPTIONS] to select “Default”, “Change”.
MENU FUNCTION MENU FUNCTION PHONE BOOK CALL HISTORY H PHONEBOOK COPY H MISSED Allows you to copy the number to another location, either Phone or Display information about the 30 most recently missed calls. Place a UIM. call to a missed call number by simply pressing ³...
MENU FUNCTION MENU FUNCTION CALL HISTORY CALL HISTORY H RECEIVED H DIALLED Displays information about the 30 most recently Received calls. Place Displays information about the 30 most recently Dialled calls. a call to a incoming call number by simply pressing Place a call to a outgoing call number by simply pressing ³...
MENU FUNCTION MENU FUNCTION CALL HISTORY PROFILES H CALL DURATION Customizes your cellular telephone and optimizes performance through a variety of settings. In this menu, shows details about the call, such as the number or name, if available, the time and date it was dialled, last call, or all H PROFILES calls.
MENU FUNCTION MENU FUNCTION PROFILES DISPLAY H THEME Messages : Sets the tone of the text message. (Tone 1~5) To select an LCD display: Voce mail : Sets the tone of the voice mail. (Tone 1~5) Ringer Volume : Sets the volume of the ringtone. (Mute/Level1~5) Key Volume : Sets the volume of the keytone.
MENU FUNCTION MENU FUNCTION DISPLAY DISPLAY H LANGUAGE POWER OFF Selects the language in which letters are displayed on screen. ³ Press [MENU] · Select Default to choose a pre-installed display, display, or Downloads or Saved to Phone to choose a display you have downloaded to your phone.
MENU FUNCTION MENU FUNCTION DISPLAY SETTINGS H CONTRAST H CALL To adjust the display contrast: CALL WAITING ³ Use to select a contrast level. Notifies you of an incoming call when you’re on a call by sounding a beep and displaying the caller’s phone number on the screen. •...
MENU FUNCTION MENU FUNCTION SETTINGS SETTINGS ANSWER MODE VOICE PRIVACY To select an answer mode: The voice Privacy feature encrypts the voice channel so that no one can eavesdrop on your phone conversations. ³ Press [MENU] ³ Press [MENU] Press and select “Send Key”, “Any Key”or “Slide Open” Select one of the Voice Privacy options: with the navigation key.
MENU FUNCTION MENU FUNCTION SETTINGS SETTINGS TONE LENGTH SIGNAL FADE ALERT To adjust tone length: ³ Press [MENU] , “Signal Fade Alert”. ³ Press [MENU] Select “On” or “Off” with the Navigation Key then Select “Normal” or “Long” with the Navigation Key press to save it.
MENU FUNCTION MENU FUNCTION SETTINGS SETTINGS SLIDE ALERT PHONE LOCK use this menu to select the tone that the phone sounds when you Prevents the phone from being used without entering the password open or close the phone. first. ³ Press ³...
MENU FUNCTION MENU FUNCTION SETTINGS SETTINGS CALL HISTORY Blocks access to call history. UIM LOCK Press [MENU] , then enter “Password”. Blocks access to UIM card. Press then select “Allow” or “Restrict” Press [MENU] , then enter “Password”. with the Navigation Key and press Press then select “Enable PIN”...
MENU FUNCTION MENU FUNCTION SETTINGS SETTINGS DELETE ALL CAMERA Clears all phone book, downloads, and photo gallery entries. Blocks access to camera. Press [MENU] , then enter “Password”. ³ Press [MENU] , then enter “Password”. Press then select “Allow” or “Restrict” with the Navigation Key and press The default password is the last 4 digits of your phone number.
MENU FUNCTION MENU FUNCTION ORGANISER ORGANISER H SCHEDULER RINGER Sets a scheduled plan and reminds you of that plan. To set a Ringer, press [OPTIONS], then select “Default” or “Change” using the Navigation Key. To save it press • Default : To set default ringer type. ADD EVENT •...
MENU FUNCTION MENU FUNCTION ORGANISER ORGANISER SETTING RINGER Use the Navigation Key to select a setting for the alarm To set a “Ringer” press [OPTIONS], then select (Once, Daily, Mon-Fri, Weekly, Monthly, Off ). “Default” or “Change” with Navigation Key. To save it press •...
MENU FUNCTION MENU FUNCTION ORGANISER ORGANISER H CALCULATOR LIST To access the calculator: To view a saved memo: ³ Press [MENU] The list of all memos, in saved order, is displayed. ³ Press [MENU] Select a notes then press To add a new memo, press [OPTIONS], “Add New”.
MENU FUNCTION MENU FUNCTION ORGANISER ORGANISER H STOPWATCH H WORLD CLOCK Simultaneously times up to six different events. To display the time and date in pre-programmed cities: To operate the Chronometer: ³ Press [MENU] ³ Press [MENU] Select a city. To measure a time period: 1.
MENU FUNCTION MENU FUNCTION ORGANISER CAMERA H SNAKE H TAKE PHOTO ³ Press to take a photo and save it. ³ Press [MENU] QUALITY H ICARUS ³ Press [CAMERA KEY] then [OPTIONS] · Select one of the following options: ³ Press [MENU] •...
MENU FUNCTION MENU FUNCTION CAMERA CAMERA MULTI SHOT FRAMES ³ Press [CAMERA KEY] ³ Press [CAMERA KEY] and then [OPTIONS] and then [OPTIONS] · Select one of the following options: FLASH • Off/2/3/4/5 ³ Press [CAMERA KEY] and then [OPTIONS] TIMER •...
MENU FUNCTION MENU FUNCTION CAMERA CAMERA H SETTINGS SET WALLPAPER To set for Standby, Power On, Power Off, Received Call and Dialled Call image. DATE & TIME ³ Press [CAMERA KEY] , and then [OPTIONS] ³ Press SET PHONEBOOK [CAMERA KEY] ³...
MEMO CHAPTER 5 VOICE MAIL AND TEXT MESSAGE This chapter addresses Voice Mail and Text Messaging or Picture message functions including: WHEN A NEW MESSAGE ARRIVES WRITE INBOX OUTBOX VOICE MAIL DRAFTS TEMPLATES DELETE ALL SETTINGS MSG. GROUP MSG COPY PS-300_060602.indd 92-93 PS-300_060602.indd 92-93 2006.6.2 5:36:59 PM...
Page 49
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE H TEXT MESSAGE Under “Message”, input a new TEXT message and press . (Please refer to page 40 for more details on TEXT MESSAGE entering letters, numbers and symbols.) • By pressing [OPTIONS], in the message input ³...
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE H INBOX Input any text message to go along with the forwarded message, then press To send the text message, press [OPTIONS], then select “Send” then press ³ Press SAVE TO TEMPLATES [MENU] or press ³...
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE H OUTBOX COPY TO UIM Manages sent text messages or messages waiting to be sent. ³ To copy the messages, select "COPY TO UIM". · You can copy the messages stored on the phone’s memory to the UIM card or UIM card to the phone’s ³...
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE H DRAFTS LOCK & UNLOCK Draft Folder contains any draft messages or saved messages. ³ To lock or unlock the text message, select If message composition is interrupted by a voice call or other interrupting event, the text of the current composition is “Lock &...
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE H TEMPLATES H SETTINGS Manages messaging features through various features. ³ Press [MENU] or press SAVE SENT MSG Select a message from the list. Press [OPTIONS]. ³ Press To add a new template message, select “Add New”. [MENU] To edit the template message you have selected, select press...
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE SIGNATURE DELIVERY ACK When this option is checked, you can attach your name, phone When this option is checked, the network informs you whether or number, a simple memo, or tag line as a signature. not your message has been delivered.
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE H MSG. GROUP STORAGE Allows the user to five group, each group in a directory can have up ³ Press [MENU] to 10 phone numbers. The user can add, change, and delete Msg. press Group.
VOICE MAIL AND TEXT MESSAGE VOICE MAIL AND TEXT MESSAGE CHANGE MSG. GROUP NAME DELETE MSG. GROUP ³ Press ³ Press [MENU] [MENU] Select an existing group name. Select the group name to be delete. · Press · Press [OPTIONS] then select “2. Rename”. [OPTIONS] then select “4.
VOICE MAIL AND TEXT MESSAGE H MSG COPY Allows you to copy the message to another location, either Phone or UIM. PHONE TO UIM CHAPTER 6 ³ Press [MENU] PACKET DATA You can copy all of the messages stored on the phone’s SERVICE memory to the UIM card.
Data service subscribers can purchase the USB cable from the service provider. USB Cable which connects PS-300 to PC is specially designed and should not be substituted by other modem cable. Select USB port where PS-300 is connected COM# and click “Properties”.
PACKET DATA SERVICE PACKET DATA SERVICE MODEM CONNECTION ³ Connect PS-300 to PC using USB cable as shown in the figure 1. Open Control Panel and Double click “Network and Dial-up Connections” icon. ¿ Go to “Advanced” tab, set “Extra initialization commands”...
Page 60
3.3 Enter any arbitrary number in “Telephone number” “Next” button. and click “Next”. 3.3 If you have more than one dial-up device on your computer, select the device that is connected to PS-300 with USB Cable. (Curitel Packet Service (COM#)) PS-300_060602.indd 116-117 PS-300_060602.indd 116-117 2006.6.2 5:37:12 PM...
PACKET DATA SERVICE PACKET DATA SERVICE » Enter “User name” and “Password” as appropriate. 3.4 Click “Finish” when the setup is completed. ¿ Enter any arbitrary number in “Phone Number”. ´ Click “Connect”. DIAL-UP NETWORKING ³ Go to “Start” e “Settings” e “Control Panel” e “Network and Dial-up Connections”.
³ Go to “Start” e “Settings” e “Control Panel” “Properties”. e “Phone And Modem Options” e “Modems”. Select USB port (COM#) where PS-300 is connected and click “Properties” button. - Check if “Maximum Port Speed” is “115200” on “General” tab.
Page 63
PACKET DATA SERVICE PACKET DATA SERVICE ´ Click “Dial”. H INTERNET ACCESS PACKET DATA SERVICE ³ Setup “Dial-Up Networking” as in appendix I. · Go to “Properties e General e Configure e Connection Advanced” and type “AT+CRM=1”. » Enter “User name” and “Password” as appropriate. ¿...
MEMO CHAPTER 7 SAFETY AND WARRANTY This chapter addresses the safety guidelines and precautions to follow when operating your cellular telephone. Before operating your cellular telephone, please be aware of all the safety details. This chapter contains the terms and conditions of services and the warranty for your cellular telephone.
SAFETY INFORMATION SAFETY INFORMATION SAFETY SAFETY FOR WIRELESS FOR WIRELESS AND WARRANTY AND WARRANTY HANDHELD PHONES HANDHELD PHONES H DRIVING SAFETY Read This Information Before Using Your Handheld Talking on the phone while driving is extremely dangerous Portable Cellular Telephone and is illegal in some states.
SAFETY INFORMATION SAFETY INFORMATION SAFETY SAFETY FOR WIRELESS FOR WIRELESS AND WARRANTY AND WARRANTY HANDHELD PHONES HANDHELD PHONES H ELECTRONIC DEVICES POSTED FACILITIES Most modern electronic equipment is shielded from RF Turn your cellular telephone OFF where posted notices so energy.
DO NOT disassemble the phone or its accessories. If service or damage the phone, or result in violation of FCC regulations. repair is required, return unit to an authorized Pantech cellular Do not use the phone with a damaged antenna. If a service center.
SAFETY INFORMATION SAR INFORMATION SAFETY SAFETY FOR FCC RF EXPOSURE AND WARRANTY AND WARRANTY BODY-WORN OPERATION THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. This device was tested for typical body-worn operations Your wireless phone is a radio transmitter and receiver. It is with the back of the phone kept 2.0 cm.
• Use only Pantech-approved batteries and recharge your FCC ID : PP4PC-7300SU battery only with Pantech approved chargers. When a Additional information on Specific Absorption Rates (SAR) charger is not in use, disconnect it from the power source. can be found on the CTIA-The Wireless Association TM Do not leave the battery connected to a charger for more (CTIA) web-site at http://www.ctia.org/wireless_...
PRECAUTIONS WHEN CARE AND SAFETY SAFETY USING BATTERIES MAINTENANCE AND WARRANTY AND WARRANTY • Do not leave the battery in hot or cold places, such as in a Your phone is a product of superior design and car in summer or winter conditions or you will reduce the craftsmanship and should be treated with care.
CARE AND TROUBLESHOOTING SAFETY SAFETY MAINTENANCE AND WARRANTY AND WARRANTY • Do not use harsh chemicals, cleaning solvents, or strong To save the time and expense of an unnecessary service call, per- form the simple checks in this section before contacting a service detergents to clean the phone.
• this may be the result of one of the following three cases. that a non-Pantech accessory has created the problem with your 1. your charger may be out of order. Contact your nearest unit the Warranty with not apply. In addition if the unit has already dealer.
(d) The Product has been used with or connected to an accessory (i) not supplied by PANTECH or its affiliates, (ii) not fit for use with the Product or (iii) used otherwise than in the manner intended.
Page 74
Safety Information 1 . SAFETY INFORMATION FOR FIXED WIRELESS TERMINALS .POTE NTIALLY EXPLOSIVE ATMOSPHERES Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cauls e an explosion or fire resulting in bodily injury or even death.
Page 75
U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Interference in a residential installation This equipment generates, uses, and can radiate radio frequency energy and, if Not installed and used in accordance with the instructions, may cause harmful Interference to radio communications.
